  • Page 1 RADIANCE DSHOT VERSION Flight controller USER MANUAL Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...

  • Page 2: What's New Radiance Dshot Version

    Introduction The Furious FPV Radiance FC (Flight Controller) provides a blaze of feature packed brilliance that equates to the perfect fit for models utilizing their own PDB (power distribution board). Functionality is the key, but innovation is our specialty. The Radiance FC stacks with 4 in 1 ESC’s for perfect CG, allowing optimized acro flight.
  • Page 3 Board Layout Dimensions...

  • Page 4: Connect With Receiver

    Connection * Warning: Radiance DShot Version can support up to 5s Lipo battery but make sure other devices also support it. Connect with Receiver:  Using XSR FrSky Receiver...
  • Page 5  Using SPD15 Receiver  Using Spektrum Satellite Receiver...

  • Page 6: Connect With Video Transmitter

    Connect with Video Transmitter:  Using Tramp HV With Piggy V2 OSD...
  • Page 7 With Only Camera...

  • Page 8: Using Tbs Unify Pro

     Using TBS Unify Pro With Piggy V2 OSD...
  • Page 9 With Only Camera...

  • Page 10: Using Fx Fx799T

     Using FX FX799T With Piggy V2 OSD...
  • Page 11 With Only Camera...

  • Page 12: Connect With Other Devices

    Connect with other devices:...
  • Page 13 Connect with ESC 4 in 1 Aikon SEFM 30A: You can buy ESC Aikon SEFM 30 4 in 1 right here: https://goo.gl/IOYBEr...
  • Page 14 Connect with ESC 4 in 1 Cicada 35x4 35A: You can buy ESC Sunrise Cicada 35x4 35A right here: https://goo.gl/s08OaI...

  • Page 15: Basic Setup

    Basic setup Please, follow carefully these next steps, and always remove your propellers when you’re configuring your quad Step 1: Plug USB cable and connect Radiance with the computer then open BetaFlight Step 2: Configure Ports. (1) Turn on MSP of UART 1 to use OSD. (2) Turn on Serial Rx of UART 2 to use Receiver Mode (3) Select SmartPort of UART 3 to use S.Port of Receiver.
  • Page 16 Step 4: Select Serial- based receiver in Receiver Mode If you are using SBus, iBus or a Spektrum Satellite, you will need to pick your Serial Receiver Provider. Follow this table: RX Type Serial Receiver Provider DSM2 Satellite SPEKTRUM1024 DSMX Satellite SPEKTRUM2048 FrSky RX SBUS...
  • Page 17 Step 5: Go to Receiver tab to configure the receiver and select the channel mapping compatible with your transmitter. Ex: Choose 3 mapping (JR/ Spektrum/ Graupner) if you use FrSky Receiver. Step 6: Go to Modes to set ARM range and choose auxiliary functions Aux. * Note: the Aux number associated with the switch you will use for arming, other modes function...
  • Page 18 Tips How to configure your Spektrum RX with your flight controller: In Betaflight Configurator:  Go to the Ports tab  Enable “Serial RX” on the UART 2 Click “Save”. Then go to the Configuration tab. Under the section labeled “Receiver”, pick SPEKTRUM2048.
  • Page 19 Finally, go to the Receiver tab. Pull down the drop down that says “Channel Map” and select the “JR / Spektrum / Graupner” option. Once again, click “Save”. How to turn on bind mode Safety warning: never plug battery to the quad during setup. Connect quadcopter to the computer and go to Command-line interface (CLI) tab.
  • Page 20 Note – if you are using a DSM2 receiver, change “set spektrum_sat_bind=9” to “set spektrum_sat_bind=5” Reboot your flight controller by unplugging the flight controller from your PC then plugging it back in. Your RX should go into bind mode by now as the LED on the RX will be blinking rapidly. How to set up OSD via BetaFlight Serialpassthrough: Note: ...
  • Page 21 Step 4: Go to the CLI tab and type the following: serialpassthrough (port) (baud) At here, my OSD connected to UART1 so you need to type: serialpassthrough 0 115200 NOTE: Betaflight labels serial ports starting from 0 not 1 yet most flight controllers label UART’s starting with 1.
  • Page 22 Step 6: Disconnect and close Betaflight but leave all the connections as they are. Step 7: Open up your software you use to configure it. In my case it was MW OSD GUI. Step 8: Select the port you noted in Betaflight being used to connect to your flight controller and connect.
