Super II Variable Speed Pump
™
SELF-PRIMING SWIMMING POOL PUMP
INSTALLATION AND OPERATING
INSTRUCTION MANUAL
Your Hayward variable speed self-priming centrifugal pump has been quality-built and
engineered to give you many years of efficient, dependable, corrosion
free service.
The advanced design reduces operation and maintenance to simple,
common-sense procedures.
Secure pump to base
with screws or bolts to reduce vibration and pipe stress.
E
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Super II Variable Speed Pump
30-LITINSB012 Rev-B
