Introduction

The arbor press is designed for riveting, swaging, bending, punching, and flattening. The arbor press can
be used to press on or remove close-fitting bearings and bushings. It is suited for the production
environment as well as machine shops, automobile repair shops, and home workshops.
The anvil has four slots that are available for a variety of pressing operations.

Specifications

Stock# ..................................... 333605 .............. 333610 ................. 333620 ................ 333630 ................. 333650
Model# ..................................... AP0-M ............... AP1-M .................. AP2-M ................. AP3-M .................. AP5-M
Pressure (ton) ........................... ½ Ton ................. 1 Ton ................... 2 Ton ................... 3 Ton ..................... 5Ton
Capacity over Table (in.) ............. 4-3/4 ........................ 5 .................... 7-1/2 .................. 11-1/2 ......................... 17
Diameter of Work (in.) ................. 6-5/8 ........................ 8 .................. 10-3/4 .................. 11-3/8 ......................... 17
Anvil Diameter (in.) ...................... 3-1/2 .................. 3-1/2 ................ 6-11/16 ................ 6-11/16 ..................... 9-3/4
Size of Ram (in.) ................ 3/4 x 7-7/8 ............ 1 x 9-1/8 ............. 1-1/4 x 13 ............ 1-1/2 x 18 ............. 2 x 27-1/2
Ram Bore (in.) ................................ 3/8 ..................... 1/2 ........................ 1/2 ....................... 1/2 ........................ 1/2
Ram Travel (in.) ........................... 4.72 ..................... 5.9 ...................... 9.05 ..................... 12.6 ...................... 18.1
Base Size (in.) ....................... 4 x 9-1/2 ............ 5 x 9-1/2 ...... 6-3/8 x 15-3/4 ............ 8-1/2 x 18 ............. 9-7/8 x 26
Overall Dimensions:
Length (in.) ............................ 9-5/16 .................. 9-1/2 .................. 15-3/4 .................. 18-1/8 ......................... 27
Width (in.) ................................ 6-5/8 .................. 7-1/2 ......................... 10 .................. 10-1/4 ......................... 13
Height (in.) ........................... 10-3/8 ...................... 12 .................. 17-1/2 .................. 22-1/2 ................... 31-1/2
Net Weight (lb.) ......................... 17-1/2 ................ 25-1/2 .................. 67-1/2 ...................... 108 ....................... 262
Shipping Weight (lb.) ....................... 19 ................ 26-1/2 .................. 69-1/2 ...................... 116 ................. 296-1/2
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, JET reserves the right to change specifications at any time and without prior
notice, without incurring obligations.
Read and understand the entire contents of this manual before attempting
assembly or operation! Failure to comply may cause serious injury!
