DEMO MANUAL DC2685A
QUICK START PROCEDURE
Table 1. DC2684A 4PV# Jumper Settings
JUMPER SETTING
4PV# (JP2) LO
HI
Table 2. DC2684A Auto Mode Maximum Delivered Power Capabilities
Jumper Settings
PM1 PM0 Max Port Power
(JP4) (JP3) (Single-Signature)
LO LO
LO HI
HI LO
HI HI
4
OPERATION
Port powered only when both
pairsets present a valid signature
Any pairset presenting a valid
signature is powered
Max Pairset Power
(Dual-Signature)
40W 13W
51W 25.5W
62W 25.5W
71.3W 35.6W
Figure 3. DC2685A Kit Connections
Table 3. DC2685A Power Supply Voltage Range per PSE Type
IEEE TYPE
Type 3
Type 4
Table 4. DC2685A Address Settings
SW3
AD3
LO
LO
HI
HI
Supply Voltage Range
51V to 57V
53V to 57V
ADDRESS
AD2
LO 20h
HI 24h
LO 28h
HI 2Ch
UG-1339 Rev 0
