LCD Display Overview
The Z1 display offers useful information on device settings. Below is a brief overview
of the information available using the built-in LCD. For more information, please refer
to the Z1 User Guide.
1. Treatment pressure display
2. Ramp progress indicator (if ramp set)
3. Ramp time remaining (if ramp set)
4. Battery status (if present)
5. AC Power indicator (if connected)
6. General Status Display
7. Fault indicator (if fault occurs)
8. Reminder indicator (if excessive air
leakage occurs)
If you encounter problems consult the Z1 User Guide or contact your
health care provider or Breas.
To register your device, fill out and return the included Registration
Form.
Breas Medical AB
Företagsvägen 1
SE 435 33 Mölnlycke
SWEDEN
Z1™ is a trademark of Human Design Medical, LLC.
Patent Pending. © Copyright 2013, Breas Medical AB. All rights reserved.
Z1 Getting Started Guide
Doc. HD40-0005-02 En L-3
Z1
™
Getting Started Guide
Advertisement
Table of Contents
Related Manuals for Breas Z1
Summary of Contents for Breas Z1
- Page 1 LCD Display Overview ™ Getting Started Guide The Z1 display offers useful information on device settings. Below is a brief overview of the information available using the built-in LCD. For more information, please refer to the Z1 User Guide. 1. Treatment pressure display 2.
- Page 2 IMPORTANT: The “REMINDER” indicator will display on the Z1 if an air leak is detected between the Z1 outlet and the mask. This may also display at times when the mask is not being worn properly. This common condi- tion should clear once all connections are secure, the mask is properly worn, and therapy has begun.
