1
Serializing the Lock and Key
TOSIBOX
Lock
®
B
TOSIBOX
®
Key
Deploying into Broadband Networks
2a
2G/3G/4G,
DSL
x
Firewall & NAT Friendly
Remote user
Internet /xDSL router
Lock 100
Quick Start Guide v2.8
Copyright © Tosibox Oy, 2015
A
AC Adapter
2G/3G/4G,
Firewall & NAT Friendly
WAN
A)
Connect the AC adapter to the Lock and wait for 2
minutes.
B)
Serialize the Key to the Lock by inserting the Key
into the USB port of the Lock. When the LED on the
Key stops blinking, the serialization is complete.
2a
C)
Go to
if deploying into broadband networks or
if deploying into mobile networks.
2b
DSL
x
TOSIBOX
Lock
®
A)
Connect an internet-connected ethernet cable to
the Lock's WAN port.
B)
Plug the devices into the Lock's LAN ports (LAN
1-3 or connect wirelessly via WLAN). If the devices
have static IP addresses, please see "Deploying
the Lock" in the user manual.
Advertisement
Table of Contents
Related Manuals for Tosibox Lock 100
Summary of Contents for Tosibox Lock 100
- Page 1 Lock 100 Quick Start Guide v2.8 Copyright © Tosibox Oy, 2015 Serializing the Lock and Key TOSIBOX Lock ® Connect the AC adapter to the Lock and wait for 2 minutes. Serialize the Key to the Lock by inserting the Key into the USB port of the Lock.
- Page 2 ® HiLink versions are not supported. For more information and latest supported modem models visit: help.tosibox.com. Note: Please see “Connecting the Lock to an existing network in client mode” in the TOSIBOX ® user manual (p.13) for information on deploying Locks as a DHCP client into existing networks. For other deployment configurations not contained within this guide, please see the TOSIBOX ®...
