1
Matching the Lock with the Key
TOSIBOX
Lock
®
TOSIBOX
Key
®
Deploying into Broadband Networks
2a
PC
TOSIBOX
Mobile
Client
Quick Start Guide v2.9
Copyright © Tosibox Oy, 2017
AC Adapter
VPN tunnel through Internet
®
TOSIBOX
Key
®
WAN
Internet /xDSL router
Lock 100
1.
Connect the AC adapter to the Lock and wait for 2
minutes.
2.
Insert the Key into the USB port of the Lock. When
the LED on the Key stops blinking, (after approx.
10 seconds) the matching is complete and you can
remove the Key from the USB port.
2a
3.
Go to
(ethernet) or
networks.
1.
Connect an Internet-connected ethernet cable to
the Lock's WAN port.
2.
Plug the devices into the Lock's LAN ports (LAN
1-3 or connect wirelessly via WLAN). If the devices
have static IP addresses, please see
Lock
in the TOSIBOX
if deploying into broadband networks
if deploying into mobile
2b
L
W
®
TOSIBOX
A
A
Lock
N
N
Firewall
user manual.
®
HMI
PLC
Camera
PC
Deploying the
