Tosibox 350 Quick Start Manual

Matching your TOSIBOX
1
with the Key
1. Connect the operating voltage of 5-35 V DC to the device and wait for 1 minute.
2. Insert the Key into the USB port of the device. When the LED on the Key turns off,
(after approx.10 seconds) the matching is complete, and you can remove the Key from
the USB port.
3a
3. Go to
setting up wireless connection. If deploying Endpoint devices as DHCP client into
existing networks, please see the TOSIBOX user manual.
Set Up Router
2
1. Connect ethernet cable into LAN port of Tosibox Endpoint device and the other end of the
cable into LAN port of your computer.
2. Visit LAN IP address in your browser to set up your device. The LAN IP address can be
found from the bottom of the end-point device.
3. Log in using "admin" account. The password can be found from the bottom of the device.
4. TOSIBOX® Endpoint device needs an Internet connection to function. Go
3a
to if deploying into broadband networks (ethernet) or
connection.
Update the device software immediately when you are connected to the Internet.
!
Go to Settings > Software update. If there is a software update available for the device, start the
update by clicking Start software update.
Connect to the Internet using
3a
Ethernet connection
1. Connect your TOSIBOX® Endpoint device from the WAN port to the Internet with a fixed
Ethernet cable.
2. When the INTERNET LED is lit on the front plate of the end point device, the Internet
connection is working. If the light is not lit, investigate possible connectivity issues.
Set up wireless connection
3b
Connect the device to the Internet using internal
Modem
You can connect the device to the Internet with
an internal Modem. Before inserting or removing
the SIM card, disconnect the device power
supply.
1. Install the antenna
2. Insert a SIM card
3. Select Network > Internal Modem and
fill in the APN according to your mobile
operator settings. Enter PIN code if
necessary. Click Save.
Position the antennas in orthogonal pattern, i.e. in such a way that they form
!
90 degrees angle between each other.
Quick Start Guide
Copyright © Tosibox Oy, 2025
if you are connecting to the Internet using Ethernet connection or
350, 375
Endpoint device
®
Connect the device to the Internet using
wireless LAN
1. Attach WLAN antenna to the device.
2. Open the service connection to the device
and log in with your credentials.
3. Configure wireless LAN settings at
"Network > WLAN".
4. When the WIFI LED is lit on the front plate
of the Device, the WLAN connection is
working.
3b
if deploying into wireless
3b
if
