1
Matching the Lock with the Key
1.
Connect the operating voltage of 12-48 V DC to the Lock and wait for 1 minute. In case you have
a product version with Power Source kit, use the conversion cable. It converts the AC adapter's
coaxial connector output to stripped wires that are needed to power the Lock 500. Follow the polarity
symbols in the front panel. Use + and - terminals to power the device.
2.
Insert the Key into the USB port of the Lock. When the LED on the Key turns off, (after approx.
10 seconds) the matching is complete, and you can remove the Key from the USB port.
3.
Go to
2a
networks (Lock 500i only). If deploying Locks as DHCP client into existing networks, please see
the TOSIBOX
Deploying into Broadband Networks
2a
PC
TOSIBOX
®
Mobile
Client
1.
Connect an Internet-connected ethernet cable
to the Lock's WAN port.
2.
Plug the devices into the Lock's LAN ports (LAN
1-3). If the devices have static IP addresses,
please see
user manual.
Lock 500/500i
Quick Start Guide
Copyright © Tosibox Oy, 2021
TOSIBOX
Lock 500/500i
®
Power source Kit
(optional)
if deploying into broadband networks (ethernet) or
user manual.
®
VPN tunnel through Internet
®
TOSIBOX
Key
Deploying the Lock
in the TOSIBOX
WAN: Internet/xDSL router
USB Connection
2b
if deploying into mobile
W
TOSIBOX
A
Lock
N
Firewall
®
TOSIBOX
®
Key
HMI
PLC
L
®
A
N
Camera
PC
