Matching your TOSIBOX
1
1.
Connect the operating voltage of 5-35 V DC to the Node and wait for 1 minute.
2.
Insert the Key into the USB port of the Node. When the LED on the Key turns off, (after
approx.10 seconds) the matching is complete, and you can remove the Key from the
USB port.
3a
3.
Go to
setting up wireless connection. If deploying Nodes as DHCP client into existing

Set Up Router

2
1.
Connect ethernet cable into LAN port of TOSIBOX® Node and the other end of the cable
into LAN port of your computer.
2.
Visit 10.10.10.254 in your browser to set up your device.
3.
Log in using "admin" account. The password can be found from the bottom of the Node.
4.
TOSIBOX® Node needs an Internet connection to function. Go to
broadband networks (ethernet) or
Update the device software immediately when you are connected to the Internet.
!
Go to Settings > Software update. If there is a software update available for the device, start the
update by clicking Start software update.
Connect to the Internet using
3a
Ethernet connection
1.
Connect your TOSIBOX® Node from the WAN port to the Internet with a fixed Ethernet
cable.
2.
When the INTERNET LED is lit on the front plate of the Node, the Internet connection is
working. If the light is not lit, investigate possible connectivity issues.

Set up wireless connection

3b
Connect the device to the Internet using internal
Modem
You can connect the device to the Internet with
an internal Modem. Before inserting or removing
the SIM card, disconnect the device power
supply.
1.
Install the antenna
2.
Insert a SIM card
3.
Select Network > Internal Modem and
fill in the APN according to your mobile
operator settings. Enter PIN code if
necessary. Click Save.
Position the antennas in orthogonal pattern, i.e. in such a way that they form
!
90 degrees angle between each other.
Quick Start Guide
Copyright © Tosibox Oy, 2023
if you are connecting to the Internet using Ethernet connection or
350, 375
Node with the Key
®
3b
if deploying into wireless connection.
Connect the device to the Internet using
wireless LAN
1.
Attach WLAN antenna to the device.
2.
Open the service connection to the device
and log in with your credentials.
3.
Configure wireless LAN settings at
"Network > WLAN".
4.
When the WIFI LED is lit on the front plate
of the Device, the WLAN connection is
working.
3b
if
3a
if deploying into
