- Page 1 Bulletin M0097C EN - Rev.1 CUBE CUBE DISPENSERS DISPENSERS FOR PRIVATE USE FOR PRIVATE USE USE AND MAINTENANCE MANUAL ENGLISH...
- Page 2 PERSONNEL WHO USE THE DISPENSER AND THE TECHNICAL SUPPORT PERSONNEL MUST BE FAMILIAR WITH THE FIRST AID AND SAFETY RULES DESCRIBED IN THIS MANUAL. Keep this technical manual in a place that is familiar and accessible to all the personnel who have access to the dispenser.
-
Page 3: Table Of Contents
(Translated from Italian) TABLE OF CONTENTS EC Declaration of conformity ....Meter accuracy ........Permitted uses ........First aid rules ........... Uses not permitted ....... Persons who have ingested toxic liquids ..........C) Installation ........... Persons who have suffered electric shock . Packaging content ...... -
Page 4: Ec Declaration Of Conformity
The documentation is at the disposal of the competent authority following motivated The documentation is at the disposal of the competent authority following motivated request at Piusi S.p.A. or following request sent to the email address: doc_tec@piusi.com request at Piusi S.p.A. or following request sent to the email address: doc_tec@piusi.com The person authorised to compile the technical file and draw up the declaration is Otto Varini as legal representative. -
Page 5: First Aid Rules
CUBE is shipped inside stackable cardboard packaging. DIMENSIONS OF PACKAGING: h. = 480mm / w. = 380mm / d. = 380mm TOTAL WEIGHT: Cube 56/33 = 21.3 Kg Cube DC 12V = 22 Kg PACKAGING WEIGHT: 1.8 Kg Cube 70/33 = 24.0 Kg Cube DC 24V = 22 Kg 1.8 Kg... -
Page 6: Rules For Demolition And Disposal
(Translated from Italian) RULES FOR DEMOLITION AND DISPOSAL The components must be given to companies that specialise in the disposal and recycling of industrial waste and, in par ticular, the DISPOSAL OF PACKAGING: The disposal of other par ts such as pipes, rubber The packaging consists of biodegradable cardboard seals, plastic components and cables should be which can be delivered to companies for normal... -
Page 7: Cube Dispenser
(Translated from Italian) Equipment and features are: EN 60034-5, flange-mounted directly to the • Self-priming rotary vane pump with pump body (version Panther Dc). incorporated by-pass valve. • Four meters of anti-static rubber tube for fuel. • Motor with protection grade IP55 and •... -
Page 8: Components Of Cube Dispensers
(Translated from Italian) Components of CUBE dispensers The pictures aside show the CUBE components. In particular, those components that distinguish the various models of the CUBE product line are numbered and described. Drawing Ref. Description Pump-Motor Unit Meter Technical specifications Absorption Power Flow rate... -
Page 9: Cinstallation
(Translated from Italian) INSTALLATION Packaging content Opening Reset knob Cube Put the knob on the guide Valve/filter kit and push thoroughly Nozzle Tube Screw off the screws not illustrated Pulling out the tube support hook Installing the tube and nozzle use a suitable dope for the threads Installation general warnings Installation general warnings... -
Page 10: Mechanical Installation
(Translated from Italian) Mechanical installation Before beginning the installation, verify that depending on the fixing position of the no packing material has been trapped in the CUBE. The tube coming from the tank must tubing. be aligned to the threaded inlet of the pump Prepare suitable stilts or fixing brackets filter which is located under the CUBE. -
Page 11: Electrical Connections
(Translated from Italian) Electrical Connections The electrical connections must be performed The maximum acceptable variations from the electrical parameters are: in a workmanlike manner by skilled personnel, respecting the regulations in effect in the • voltage ± 5 %. country of installation. •... -
Page 12: Calibrating The Meter
(Translated from Italian) ! Recommendations and warnings If this phase is excessively prolonged, stop the pump and verify that: - the pump is not running completely dry; - the suction tubing is air-tight and completely immersed in the fluid to be pumped; - the suction filter is not clogged;... -
Page 13: D) Instructions For Use
(Translated from Italian) INSTRUCTIONS FOR USE ! Recommendations and warnings • Transfer of fuel must always occur in the presence and under the control of the Operator. • Keep the dispensing nozzle closed until it is inserted in the container to be filled. •... -
Page 14: E) Maintenance
(Translated from Italian) MAINTENANCE Opening and Closing the CUBE - Screw off and remove the three cross-head screws on the left side of the CUBE (Fig. 4.1, screws A). - Screw off and remove the three cross-head screws on the right side of the CUBE (Fig. 4.1, screws B). - Raise the CUBE higher part. -
Page 15: Troubleshooting
(Translated from Italian) Troubleshooting Problem Possible Causes Possible Solutions Set the starting handle to position ON. Reset the external residual current Lack of electric power circuit-breaker. Check the electrical connections. Fuses burned out Replace the fuses in the electric panel Motor not turning Faulty switch on the Change the switch... -
Page 16: Spare Parts For The Cube
(Translated from Italian) Spare parts for the CUBE CUBE CUBE DC-56... - Page 17 (Translated from Italian) MANUFACTURER: PIUSI S.p.A. DOCUMENT TYPE: General description and instructions for its installation, activation, use and maintenance EDITION: Bullettin M0097C Rev.1 PRODUCT: Diesel fuel dispenser for private use with meter MODEL: All of the models of the CUBE product line,...
- Page 18 NOTES...
- Page 19 NOTES...
- Page 20 Authorized reseller’s stamp M0097C EN - Rev.1...
