SuperServer
®
5019A-12TN4
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperServer 5019A-12TN4

Summary of Contents for Supermicro SuperServer 5019A-12TN4

  • Page 1 SuperServer ® 5019A-12TN4 USER'S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

  • Page 3: About This Manual

    About this Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 5019A-12TN4. Installation and maintenance should be performed by experienced technicians only. Please refer to the 5019A-12TN4 server specifications page on our website for updates on supported memory, processors and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Rear Features ........................11 1.5 Motherboard Layout ......................12 Quick Reference Table ......................13 Chapter 2 Server Installation 2.1 Overview ..........................15 2.2 Preparing for Setup ......................15 Choosing a Setup Location ....................15...
  • Page 5 SuperServer 5019A-12TN4 User's Manual Motherboard Battery ......................24 Installing an Expansion Card ....................25 3.4 Chassis Components ......................28 Front Bezel ........................28 Hard Drives ........................28 Hard Drive Configuration Options ..................30 Hard Drive Carrier Indicators ..................31 System Cooling .........................32 Installing Fans ........................32 Power Supply ........................33 Power Supply Failure ....................33...
  • Page 6 Preface 6.7 Boot ............................85 6.8 Save & Exit .........................87 Appendix A BIOS Error Codes Appendix B Standardized Warning Statements for AC Systems Appendix C System Specifications Appendix D UEFI BIOS Recovery...

  • Page 7: Contacting Supermicro

    SuperServer 5019A-12TN4 User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    1U 200W Multi-output 80Plus Gold power supply PWS-203-1H 1.2 Unpacking the System Inspect the box the SuperServer 5019A-12TN4 was shipped in and note if it was damaged in any way. If any equipment appears damaged, please file a damage claim with the carrier who delivered it.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the 5019A-12TN4. Please refer to Appendix C for additional specifications. System Features Motherboard A2SDi-LN4F Chassis SC504-203B Intel® Atom SoC C3850 Processor Socket Type FCBGA1310 Memory...

  • Page 10: Server Chassis Features

    Indicates network activity on the LAN2 port when flashing. NIC1 LED Indicates network activity on the LAN1 port when flashing. On the SuperServer 5019A-12TN4, this LED indicates SATA drive activity when HDD LED flashing. Indicates power is being supplied to the system's power supply units. This LED Power LED should normally be illuminated when the system is operating.

  • Page 11: Front Features

    Chapter 1: Introduction Front Features The SC504-203B is a mini 1U chassis See the illustration below for the features included on the front of the chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Control Panel See previous page for details. Rear Features The illustration below shows the features included on the rear of the chassis.

  • Page 12: Motherboard Layout

    SuperServer 5019A-12TN4 User's Manual 1.5 Motherboard Layout Below is a layout of the A2SDi-LN4F with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4.

  • Page 13: Quick Reference Table

    Chapter 1: Introduction • Jumpers/components/LED indicators not indicated are used for internal testing only. • Use only the correct type of onboard CMOS battery, as specified by the manufacturer. In order to avoid possible explosion, do not install the onboard battery upside down. Quick Reference Table Jumper Description...
  • Page 14 SuperServer 5019A-12TN4 User's Manual Connector Description JTGLED1 LAN5/LAN6 Acitivity LED Header JTPM1 Trusted Platform Module/Port 80 Connector LAN1 ~ LAN4 LAN1 - LAN4: GbE LAN (RJ45) Ports SLOT7 CPU PCI-E 3.0 x4 Slot SRW1, SRW3, SRW4 M.2 Holding Screws Unit ID Button USB0/1 Back panel Universal Serial Bus (USB) 3.0 Ports...

  • Page 15: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 16: Server Precautions

    SuperServer 5019A-12TN4 User's Manual • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 17: Circuit Overloading

    Chapter 2: Server Installation Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 18: Installing The Server Into A Rack

    SuperServer 5019A-12TN4 User's Manual 2.3 Installing the Server into a Rack You should now have rails attached to both the chassis and the rack. The next step is to install the server into the rack. 1. Confirm that chassis includes the four mounting screws required to mount the chassis into a rack 2.

  • Page 19: Installing The Server Into A Telco Rack

    Chapter 2: Server Installation Installing the Server into a Telco Rack The SuperServer 5019A-12TN4 supports Telco Rack installation. The compact design of the SC504 chassis allows it to be installed into a Telco rack without the use of rails. 1. To install the chassis into a Telco style two-post rack, use two L-shaped brackets on either side of the chassis (four total).

  • Page 20: Chapter 3 Maintenance And Component Installation

    SuperServer 5019A-12TN4 User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.
  • Page 21 Chapter 3: Maintenance and Component Installation Figure 3-1. Removing the Chassis Cover...

  • Page 22: Motherboard Components

    Note: Visit the product page on the Supermicro website for possible updates to memory support (www.supermicro.com). Caution: Exercise extreme caution when installing or removing memory modules to prevent any possible damage to the DIMMs or slots.

  • Page 23: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Install the desired number of SODIMMs into the memory slots, starting with DIMMA1, DIMMB1, then DIMMA2, DIMMB2. 2. Align the key on the bottom of the SODIMM module against the receptive point on the memory slot.

  • Page 24: Motherboard Battery

    SuperServer 5019A-12TN4 User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1.

  • Page 25: Installing An Expansion Card

    The SC504 chassis includes a PCI slot for an optional full-height, half-length expansion card. A riser card is required in order to connect the expansion card to the motherboard. For further information on expansion on cards and risers cards, visit the Supermicro website at www.supermicro.com Expansion Card Clip Figure 3-4.
  • Page 26 SuperServer 5019A-12TN4 User's Manual Expansion Card Clip PCI Slot Cover Riser Card Slot Figure 3-5. Installing the Expansion Card and Riser Card 4. Outside of the chassis, put the expansion card and the riser card together by inserting the expansion card into the riser card.
  • Page 27 Chapter 3: Maintenance and Component Installation 5. Simultaneously insert the PCI slot bracket of the expansion card into the open PCI slot and insert the riser card in to the riser card slot on the motherboard. Figure 3-7. Replacing the Expansion Card Clip 6.

  • Page 28: Chassis Components

    SuperServer 5019A-12TN4 User's Manual 3.4 Chassis Components Front Bezel If your system has an optional bezel attached to the front of the chassis, you will need to remove it to gain access to the drive bays. 1. Unlock the front of the chassis and then press the release knob.
  • Page 29 Chapter 3: Maintenance and Component Installation 5. Expansion cards must be installed after installing the 2.5" hard drives. 6. Connect the hard drive wiring, reinstall the chassis cover and power cord, then power up the server Note: The bracket part number is MCP-220-00044-0N. Mounting a Drive in a Drive Carrier 1.

  • Page 30: Hard Drive Configuration Options

    SuperServer 5019A-12TN4 User's Manual Hard Drive Configuration Options 2.5" and 3.5" hard drives are supported in the following configurations: Two 2.5" HDDs In a Double Bracket, Four HDD's Total, No Expansion Card One 3.5" Hard Drive and one Low Profile Expansion Card Two 2.5"...

  • Page 31: Hard Drive Carrier Indicators

    Hard Drive Carrier LED Indicators State/Condition Indication Green Blinking Indicates drive activity Solid on Drive failure Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www. supermicro.com/products/nfo/files/storage/SBB-HDDCompList.pdf...

  • Page 32: System Cooling

    SuperServer 5019A-12TN4 User's Manual System Cooling Two 4-cm counter-rotating fans provide the cooling for the system. An additional (optional) fan may be installed in the SC504 chassis Each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions. This counter-rotating action generates exceptional airflow and is effective in dampening vibration levels.

  • Page 33: Power Supply

    This enables it to automatically sense and operate at a 100v to 240v input voltage. In the unlikely event that the power supply module fails, the system will shut down and you will need to replace the power supply module. New units can be ordered directly from Supermicro (see contact information in the Preface).
  • Page 34 SuperServer 5019A-12TN4 User's Manual Power Supply Mounting Thru Holes Rear Mounting Screws Insert Bottom Mounting Screws from Underside Figure 3-9. Installing the Power Supply 4. Remove the failed power supply from the chassis. 5. Align the mounting thru holes on the new power supply with the mounting holes in the chassis and re-attach the new power supply to the chassis using the four screws which were previously set aside.

  • Page 35: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A serverboard layout indicating component locations may be found in Chapter 1.

  • Page 36: Headers And Connectors

    SuperServer 5019A-12TN4 User's Manual 4.2 Headers and Connectors Fan Headers There are four 4-pin fan headers on the motherboard. Pins 1-3 are backward compatible with traditional 3-pin fans. The onboard fan speeds are controlled by Thermal Management (via Hardware Monitoring) in the BIOS. When using Thermal Management setting, please use all 3-pin fans or all 4-pin fans.

  • Page 37: Chassis Intrusion

    It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Refer to the table below for pin definitions. Note: Please go to the following link for more information on TPM: http://www.supermicro. com/manuals/other/TPM.pdf Trusted Platform Module Header...
  • Page 38 SuperServer 5019A-12TN4 User's Manual Power SMB (I C) Header The Power System Management Bus (I C) connector at JPI C1 monitors the power supply, fan, and system temperatures. See the table below for pin definitions. Power SMB Header Pin Definitions...
  • Page 39 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com. UID Switch...

  • Page 40: Ports

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 41 Chapter 4: Motherboard Connections Power Fail The Power Fail LED connection is located on pins 5 and 6. Refer to the table below for pin definitions. PWR Fail Pin Definitions (JF1) Pins Definition 3.3V Power Fail OH/Fan Fail LED Connect an LED cable to pins 7 and 8 of JF1 to use the Overheat/Fan Fail and UID LED connections.
  • Page 42 SuperServer 5019A-12TN4 User's Manual HDD LED The HDD LED connection is located on pins 13 and 14 of JF1. Attach a cable here to indicate the status of HDD-related activities, including IDE, SATA activities. Refer to the table below for pin definitions.

  • Page 43: Rear I/O Ports

    Chapter 4: Motherboard Connections Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Rear I/O Ports Description Description IPMI LAN Port LAN1 USB1 LAN4 USB0 LAN2 LAN3 VGA Port The onboard VGA port is located on the I/O back panel.
  • Page 44 SuperServer 5019A-12TN4 User's Manual Universal Serial Bus (USB) Ports There are two USB 3.0 ports (USB0/1) on the I/O back panel. The motherboard also has two front access USB 2.0 headers (USB2/3 and USB4/5). The onboard headers can be used to provide front side USB access with a cable (not included).

  • Page 45: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 46 SuperServer 5019A-12TN4 User's Manual VGA Enable/Disable JPG1 allows you to enable or disable the VGA port using the onboard graphics controller. The default setting is Enabled. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled LAN Port Enable/Disable Change the setting of jumper JPL1 to enable or disable the LAN ports 1 ~ 4.

  • Page 47: Led Indicators

    Chapter 4: Motherboard Connections SMBus to PCI Slots Jumpers JI C1 and JI C2 allow you to connect the System Management Bus (I C) to the PCI-E/PCI slots. Both jumpers must be set to the same setting (JI C1 controls the clock and C2 controls the data).
  • Page 48 SuperServer 5019A-12TN4 User's Manual IPMI LAN LEDs A dedicated IPMI LAN is also included on the motherboard. The amber LED on the right of the IPMI LAN port indicates activity, while the green LED on the left indicates the speed of the connection.

  • Page 49: Chapter 5 Software

    You must first configure RAID settings (if using RAID) before you install the Windows OS and the software drivers. To configure RAID settings, please refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Installing the Windows OS for a RAID System 1.

  • Page 50: Driver Installation

    SuperServer 5019A-12TN4 User's Manual 5.2 Driver Installation The Supermicro FTP site contains drivers and utilities for your system at ftp://ftp.supermicro. com. Some of these must be installed, such as the chipset driver. After accessing the FTP site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 51: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via Email or Simple Network Management Protocol (SNMP).

  • Page 52: Ipmi

    SuperServer 5019A-12TN4 User's Manual 5.4 IPMI The A2SDi-LN4F support the Intelligent Platform Management Interface (IPMI). IPMI is used to provide remote access, monitoring and management. There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, please visit our website at:...

  • Page 53: Chapter 6 Bios

    Chapter 6: BIOS Chapter 6 BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the A2SDi-LN4F motherboard(s). The is stored in a flash chip and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 54: Main Menu

    SuperServer 5019A-12TN4 User's Manual 6.2 Main Menu When you first enter AMI BIOS Setup Utility, you will see the Main Menu screen. You can always return to the Main Menu by selecting the Main tab on the top of the screen with the arrow keys.

  • Page 55: Advanced Settings Menu

    Chapter 6: BIOS BIOS Version This item displays the version of the BIOS ROM used in the system. Build Date This item displays the date when the version of the BIOS ROM used in the system was built. Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 56: Boot Feature

    SuperServer 5019A-12TN4 User's Manual Boot Feature  Quiet Boot Use this feature to select the screen display between POST messages or the OEM logo at bootup. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages. The options are Disabled and Enabled.
  • Page 57 Chapter 6: BIOS • L1 Cache RAM • L2 Cache RAM EIST (GV3) EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency to reduce power consumption and heat dissipation. The options are Disable and Enable. BIOS Request Frequency Use this feature to instruct how much frequency will be delivered to the processor.
  • Page 58 SuperServer 5019A-12TN4 User's Manual Enhanced Halt State (C1E) This feature is not available if the EIST and CPU C State features are disabled. Select Enable to enable Enhanced Halt State support, which will significantly reduce the CPU's power consumption by minimizing the CPU's clock cycles and voltage use during a Halt State. The options are Disable and Enable.

  • Page 59: Chipset Configuration

    Chapter 6: BIOS Virtualization Technology Select Enable to use Intel Virtualization Technology to allow one platform to run multiple operating systems and applications in independent partitions, creating multiple virtual systems in one physical computer. The options are Disable and Enable. Extended APIC (Advanced Programmable Interrupt Controller) Based on the Intel Hyper-Threading technology, each logical processor (thread) is assigned 256 APIC IDs (APIDs) in 8-bit bandwidth.

  • Page 60: North Bridge Configuration

    SuperServer 5019A-12TN4 User's Manual North Bridge Configuration  The following memory information will be displayed: • MRC Version • Total Memory • Memory Frequency VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to VMM through the DMAR ACPI Tables. This feature offers fully-protected I/O resource-sharing across the Intel platforms, providing the user with greater reliability, security and availability in networking and data-sharing.
  • Page 61 Chapter 6: BIOS Patrol Scrub Enable Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected in a memory module and send the correction to the requestor (the original source). When this item is set to Enable, the IO hub will read and write back one cache line every 16K cycles if there is no delay caused by internal processing.

  • Page 62: South Bridge Configuration

    SuperServer 5019A-12TN4 User's Manual Scrambler This feature scrambles data in the memory and makes it inaccessible. The options are Disabled and Enabled. Slow Power Down Exit Use this feature to enable or disable the slow exit after the precharge power down. The options are Disable dand Enabled.

  • Page 63: Sata Configuration

    Chapter 6: BIOS SATA Configuration  mSATA Selection Two interface options are available, either mSATA or mSATA/Mini PCIe.  SATA0 SATA 0 Enable controller This item enables or disables the onboard SATA controller supported by the processor. The options are Enabled and Disabled. SATA 0 LPM (Link Power Management) When this item is set to Enabled, the SATA AHCI controller manages the power usage of the SATA link.
  • Page 64 SuperServer 5019A-12TN4 User's Manual  SATA1 SATA 1 Enable controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip. The options are Enabled and Disabled. SATA 1 LPM (Link Power Management) When this item is set to Enabled, the SATA AHCI controller manages the power usage of the SATA link.

  • Page 65: Intel Server Platform Services

    Chapter 6: BIOS Intel Server Platform Services  This feature displays the following ME information: • General ME Configuration • Operational Firmware Version • ME Firmware Type • Backup Firmware Version • Recovery Firmware Version • ME Firmware Features • ME Firmware Status #1 •...
  • Page 66 SuperServer 5019A-12TN4 User's Manual Maximum Read Request Select Auto for the system BIOS to automatically set the maximum size for a read request for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

  • Page 67: Super Io Configuration

    Chapter 6: BIOS Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. *If "Network Stack" is enabled, the following four features are available for configuration: IPv4 PXE Support Use this feature to enable Ipv4 PXE Boot Support.

  • Page 68: Serial Port Console Redirection

    SuperServer 5019A-12TN4 User's Manual Serial Port Console Redirection  COM1 COM 1 Console Redirection Select Enabled to enable COM Port 1 for Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking. The options are Enabled and Disabled.
  • Page 69 Chapter 6: BIOS COM1 Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 70 SuperServer 5019A-12TN4 User's Manual SOL Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 71 Chapter 6: BIOS Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to configure Console Redirection settings to support Out-of- Band Serial Port management. EMS (Emergency Management Services) Console Redirection Select Enabled to use a COM port selected by the user for EMS Console Redirection. The options are Disabled and Enabled.

  • Page 72: Acpi Settings

    SuperServer 5019A-12TN4 User's Manual Stop Bits ACPI Settings  Use this feature to configure Advanced Configuration and Power Interface (ACPI) power management settings for your system. WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) platform and...
  • Page 73 Chapter 6: BIOS SHA256 PCR Bank Use this item to disable or enable the SHA256 Platform Configuration Register (PCR) bank for the installed TPM device. The options are Disabled and Enabled. Pending operation Use this item to schedule a TPM-related operation to be performed by a security device for system data integrity.

  • Page 74: Iscsi Configuration

    SuperServer 5019A-12TN4 User's Manual iSCSI Configuration  iSCSI Initiator Name This feature allows the user to enter the unique name of the iSCSI Initiator in IQN format. Once the name of the iSCSI Initiator is entered into the system, configure the proper settings for the following items.
  • Page 75 Chapter 6: BIOS Blink LEDs This feature allows the user to specify the duration for LEDs to blink. The range is from 0 ~ 15 seconds. The default setting is 0. This section displays the following port information: • UEFI Driver •...

  • Page 76: Event Logs

    SuperServer 5019A-12TN4 User's Manual 6.4 Event Logs Use this menu to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options PCIe ELog Support Use this feature to enable or disable PCIe error logging suport. The options are Disabled and Enabled.

  • Page 77: View Smbios Event Log

    Chapter 6: BIOS Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup. The options are No, Yes, Next reset, and Yes, Every reset. When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full.

  • Page 78: Ipmi

    SuperServer 5019A-12TN4 User's Manual 6.5 IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI STATUS This item indicates the status of the IPMI firmware installed in your system.

  • Page 79: Bmc Network Configuration

    Chapter 6: BIOS Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.
  • Page 80 The Disable option is for applications that require faster power on time wthout using Supermicro Update Manager (SUM) or extended IPMI features. The BMC network configuration in the BIOS setup is also invalid when IPMI Function Support is disabled.

  • Page 81: Security

    Chapter 6: BIOS 6.6 Security Use this menu to configure the security settings for the system. Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup or upon entering the BIOS Setup utility. The options are Setup and Always.

  • Page 82: Key Management

    SuperServer 5019A-12TN4 User's Manual  Secure Boot Platform Mode - Setup Secure Boot - Not Active Vendor Keys - Not Active Enable Secure Boot Select Enable for secure boot support to ensure system security at bootup. The options are Disabled and Enabled.
  • Page 83 Chapter 6: BIOS  Platform Key (PK) This feature allows the user to configure the settings of the platform keys. Set New Select Yes to load the new platform keys (PK) from the manufacturer's defaults. Select No to load the platform keys from a file. The options are Yes and No. ...
  • Page 84 SuperServer 5019A-12TN4 User's Manual  OsRecovery Signatures Set New Select Yes to load the DBR from the manufacturer's defaults. Select No to load the DBR from a file. The options are Yes and No. Append Select Yes to add the DBR from the manufacturer's defaults list to the existing one. Select...
  • Page 85 Chapter 6: BIOS 6.7 Boot Use this menu to configure Boot Settings: Fixed BOOT ORDER Priorities This option prioritizes the order of bootable devices that the system to boot from. Press <Enter> on each entry from top to bottom to select devices. •...
  • Page 86 SuperServer 5019A-12TN4 User's Manual  UEFI Application Boot Priorities • Boot Option # - This feature sets the system boot order of detected devices. The options are [the list of detected boot device(s)] and Disabled.  UEFI NETWORK Drive BBS Priorities •...
  • Page 87 Chapter 6: BIOS 6.8 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Save Options Save Changes and Reset When you have completed the system configuration changes, select this option to save all changes made and reset the system.
  • Page 88 SuperServer 5019A-12TN4 User's Manual Default Options Restore Optimized Defaults To set this feature, select Restore Optimized Defaults and press <Enter>. These are factory settings designed for maximum system performance but not for maximum stability. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>. This enables the user to save any changes to the BIOS setup for future use.

  • Page 89: Bios Error Codes

    Appendix A: BIOS Error Codes Appendix A BIOS Error Codes A-1 BIOS Error Beep (POST) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 90 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 91: Warning Definition

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 92 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.

  • Page 93: Installation Instructions

    SuperServer 5019A-12TN4 User's Manual !‫تحذٌز‬ ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 94: Circuit Breaker

    Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. ‫מתח‬...
  • Page 95 SuperServer 5019A-12TN4 User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.

  • Page 96: Power Disconnection Warning

    Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...

  • Page 97: Equipment Installation

    SuperServer 5019A-12TN4 User's Manual ‫امداد‬ ‫وحدة‬ ‫من‬ ‫سهك انكهرباء‬ ‫وإزانت‬ ‫انطاقت‬ ‫مصادر‬ ‫من جميع‬ ‫اننظاو‬ ‫يجب فصم‬ ‫قبم‬ ‫انطاقت‬ ‫الجهاز‬ ‫مكىناث‬ ‫نتثبيج أو إزانت‬ ‫ههيكم‬ ‫ن‬ ‫انمناطق انداخهيت‬ ‫انىصىل إنى‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...

  • Page 98: Restricted Area

    Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫הציוד או לתת שירות עבור הציוד‬ ‫אי להתקין, להחליף את‬ ‫צוות מוסמך בלבד רש‬ ‫هذا...
  • Page 99 SuperServer 5019A-12TN4 User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...

  • Page 100: Battery Handling

    Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...

  • Page 101: Redundant Power Supplies

    SuperServer 5019A-12TN4 User's Manual ‫فعليل‬ ‫بطريقة غير صحيحة‬ ‫البطارية‬ ‫انفجار في حالة اسحبذال‬ ‫من‬ ‫هناك خطر‬ ‫اسحبذال البطارية‬ ‫به الشرمة المصنعة‬ ‫أوصث‬ ‫مما‬ ‫أو ما يعادلها‬ ‫بنفس النىع‬ ‫فقط‬ ‫حعليمات الشرمة الصانعة‬ ‫المسحعملة وفقا ل‬ ‫جخلص من البطاريات‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 102 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.

  • Page 103: Backplane Voltage

    SuperServer 5019A-12TN4 User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.

  • Page 104: Comply With Local And National Electrical Codes

    Appendix B: Standardized Warning Statements ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.

  • Page 105: Product Disposal

    SuperServer 5019A-12TN4 User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬ ‫تركيب المعدات‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.

  • Page 106: Hot Swap Fan Warning

    Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫חוקי המדינה‬ ‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות ו‬ ‫القىانين...
  • Page 107 SuperServer 5019A-12TN4 User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.

  • Page 108: Power Cable And Ac Adapter

    Brand entstehen. Elektrische Geräte und Material Safety Law verbietet die Verwendung von UL-oder CSA-zertifizierte Kabel, UL oder CSA auf der Code für alle anderen elektrischen Geräte als Produkte von Supermicro nur bezeichnet gezeigt haben. ¡Advertencia! Al instalar el producto, utilice los cables de conexión previstos o designados, los cables y adaptadores de CA.
  • Page 109 Het gebruik van andere kabels en adapters kan leiden tot een storing of een brand. Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertificeerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen.

  • Page 110: System Specifications

    SuperServer 5019A-12TN4 User's Manual Appendix C System Specifications Processors Single Intel® Atom SoC C3850 Processor processor in an FCBGA1310 Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel C236 chipset BIOS 128 Mb AMI®...
  • Page 111 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Directive 2012/19/EU...
  • Page 112 Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 113 Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www. supermicro.com to download the BIOS image into a USB flash device and rename it "Super. ROM".
  • Page 114 SuperServer 5019A-12TN4 User's Manual Warning: Please stop pressing the <Ctrl> and <Home> keys immediately when you see the screen (or a similar screen) below; otherwise, it will trigger a system reboot. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 115 Appendix D: UEFI BIOS Recovery Note: Do not interrupt the BIOS flashing process until it has completed. 6. After the BIOS recovery process has completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a bootable USB flash drive. 8.
