- Page 1 SHI Series Pure Sine Wave Inverter (SHI2000 AND SHI3000) User’s Manual The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. Before using the inverter, you need to read and save the safety instructions.
-
Page 2: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Important Safety Instructions ....2 3. Inverter Operation ........4 4. Functions ............ 5 5. Troubleshooting ........12 6. Maintenance and Warranty ....14 7. Technical Specification ......15... -
Page 3: Introduction
1. Introduction Thanks for purchasing SHI series inverters. The product is a pure sine wave inverter which can convert 24/48Vdc to 220/230Vac 50/60Hz based on full digital and intelligent design. It features high reliability, high efficiency, concise outline, small volume, full protection functions, easy installation and operation. -
Page 4: Important Safety Instructions
2. Important Safety Instructions As an AC power supply equipment, the inverter‟s output voltage is with the same level as that of household power plug. Mind the AC output terminals, or you may get an electric shock and result in life danger! Attentions: ... - Page 5 and keep enough space around the inverter. The protective grounding must be connected to the ground. The cross section of wire should not be less than 4mm A fuse or breaker should be used between battery and inverter, the value of fuse or switch should be twice of the inverter rated input current.
-
Page 6: Inverter Operation
3. Inverter Operation Connect the input and output terminals accurately. Turn on the power using the ON / OFF switch on the front panel. In order to avoid the protections resulted from the surge power, please turn on AC loads one by one after the output of the inverter is normal. Please check it as below: ... -
Page 7: Functions
4. Functions DC Input DC Input Ventilation Terminal Terminal DC Input Panel Positive Negative Protective Grounding AC Output Panel Input Level Indicator RS485 Port AC Outlet① Load Level Indicator Fault Indicator AC Outlet② Switch Node Mode Switch ON/OFF Switch... - Page 8 Note：1.When the load current is less than 10A, use "AC outlet ①" or “AC outlet ②"; If the load current is greater than 10A, must use “AC outlet ②". 2.The cross section of wire should not be more than 4mm , and it is recommended to use stranded wire, when using "...
- Page 9 Input Level: Display Input Voltages LED Status ＜21 ＜42 RED Slow Blink 21～22 42～44 ORANGE 22～24 44～48 GREEN 24～29 48～58 ORANGE Fast Blink 29～32 58～64 ＞32 ＞64 RED Fast Blink Load Level: Display AC Loads LED Status AC Load ＜20% ORANGE GREEN...
- Page 10 Alarms Alarms Status Overload or Short circuit, No Output Over or Low input voltage, No Output Buzzer Sounds Over temperature, No Output Inverter Fault, No Output The buzzer stops after 20S. Protections Overload or Output Short Circuit Protection Overload ＞250% 125%...
- Page 11 Input Low Voltage Protection The output is switched off when the input voltage is lower than low voltage protect value, and auto-switched on when the input voltage reach low voltage recover value. User can also manually restart the inverter to switch on output by the „ON/OFF switch‟, when the input voltage is higher than low voltage protect value.
- Page 12 heating. And it automatic restarts when the temperature recovers to the normal level. Others Saving Mode When the switch is on “Saving” side, the inverter will enter into the Saving Mode. It will shut off the output if the loads value is less than 50VA.
- Page 13 Switch Node The inverter can be control by the other equipment through the switch node. When the switch node is link, it equal to ON/OFF switch is on. The connection between the switch node and the ON/OFF switch as follow diagram: ON/OFF Switch NEG(-)
-
Page 14: Troubleshooting
5. Troubleshooting WARNING： High voltage is inside the inverter, do not open or disassemble it! Attempting to service the unit yourself may cause the risk of electrical shock or fire! Problem Possible Solution Cause Input LED blink, Input voltage is Measure the input fault red LED too high or too... - Page 15 load and line. If the LED keeps red, the inverter has inside faults and should be returned to the factory. Fault orange Inverter Made sure the DC input abnormal terminals is tight, the input voltage between 21.6V and 30V (43.2~60V for 48V product) and restart the inverter.
-
Page 16: Maintenance And Warranty
6. Maintenance and Warranty The casing of the inverters may be cleaned regularly with a damp cloth (not wet) to prevent accumulation of dust and dirt. The screws on the DC input terminals must be tightened. The warranty period of the inverter is 2 year since the date of origin- al shipping. -
Page 17: Technical Specification
7. Technical Specification Technical Data Types SHI2000-22 SHI2000-42 Nominal Battery Voltage Input Voltage 21.6 ~32Vdc 43.2 ~64Vdc Range ≤0.7A(24Vdc) ≤0.5A(48Vdc) No Load Current Output Wave Pure Sine Wave Output Voltage 220Vac± 3% / 230Vac± 10% Continuous Power 2000W Power 10 sec... - Page 18 Types SHI3000-22 SHI3000-42 Nominal Battery Voltage Input Voltage 21.6 ~32Vdc 43.2 ~64Vdc Range ≤1.0A(24Vdc) ≤0.7A(48Vdc) No Load Current Output Wave Pure Sine Wave Output Voltage 220Vac± 3% / 230Vac± 10% Continuous Power 3000W Power 10 sec 4500W Power 3 sec 6000W Surge Power 6900W...
- Page 19 Environmental Parameters Working Temperature -20℃~+50℃ Storage Temperature -35℃~ +70℃ Humidity < 95%(N.C.) < 5000 m (Derating to operate according to Altitude IEC62040 at a height exceeding 1000 m) Others Insulation Resistance Between DC input terminals and metal case: ≥550MΩ;...
- Page 20 BEIJING EPSOLAR TECHNOLOGY CO., LTD. Tel: +86-10-82894112 / 82894962 Fax: +86-10-82894882 E-mail: info@epsolarpv.com Website: http://www.epever.com/...
