OWNER'S MANUAL
WASHING
MACHINE
MINI WASHER
Before beginning installation, read these instructions carefully. This
will simplify installation and ensure that the product is installed
correctly and safely. Leave these instructions near the product after
installation for future reference.
EN ENGLISH
WTP2071*
MFL69482511
Rev.05_062417
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTP2071 series and is the answer not in the manual?

Questions and answers

Related Manuals for LG WTP2071 series

Summary of Contents for LG WTP2071 series

  • Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. EN ENGLISH WTP2071* www.lg.com MFL69482511 Rev.05_062417 Copyright © 2017 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS This manual may contain images or content different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ............3 IMPORTANT SAFETY INSTRUCTIONS .............3 INSTALLATION ................9 Parts ......................9 Accessories ....................9 Specifications ....................10 Installation Place Requirements ..............

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 4 Installation •Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. •This appliance should only be transported by two or more people holding the appliance securely. •Do not install the appliance in a damp and dusty place.
  • Page 5 •If the power cord is damaged or the hole of the socket outlet is loose, do not use the power cord and contact an authorized service centre. •This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted.
  • Page 6 Improper use can cause a fire or explosion. •In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. •Do not push down the drawer excessively, when the appliance...
  • Page 7 •Do not use flammable gas and combustible substances (benzene, gasoline, thinner, petroleum, alcohol, etc.) near the appliance. •If the drain hose or inlet hose is frozen during winter, use it only after thawing. •Keep all washing detergents, softener and bleach away from children.
  • Page 8 Maintenance •Do not spray water inside or outside the appliance to clean it. •Disconnect the power cord before cleaning the appliance. •Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the socket outlet.

  • Page 9: Installation

    INSTALLATION Parts Door/Lid Drum Lint Filter Control Panel Drawer Water Supply Hose Power Plug Water Drain Hose Leveling Feet Accessories Water supply hose Connecting Water drain hose Water supply hose Water drain hose (for cold water) supply hose connector connector Cable ties Anti-slip sheets Spanner...

  • Page 10: Specifications

    Specifications Maximum 2.5 kg Wash Load Power Supply 220 - 240 V~, 50 Hz Size 700 mm (W) x 770 mm (D) x 360 mm (H) Product Weight 48.7 kg Permissible 0.1 - 0.8 MPa (1.0 - 8.0 kgf / cm²) Water Pressure •...

  • Page 11: Installation Place Requirements

    Installation Place • Do not install the appliance in rooms where freezing temperatures may occur. Frozen Requirements hoses may burst under pressure. The reliability of the electronic control unit may be impaired Location at temperatures below freezing point. • Ensure that when the appliance is installed, it is easily accessible for an engineer in the 25 cm event of a breakdown.

  • Page 12: Unpacking And Removing Packing Materials

    Unpacking and Removing Stacking Mini Washer Packing Materials Make sure the leveling feet on the Main Lift the appliance off the foam base. front-loading washing machine are fully wound in before stacking. Place the Main • If you must lay the appliance down to front-loading washing machine on top of the remove the carton base, always protect the Mini Washer.

  • Page 13: Connecting The Supply Hose

    • This Mini Washer will not work as a standalone the connection to taps is sufficiently tight but not unit. overtightened. • This Mini Washer can only be used and operated when stacked under the matching LG front loading washing machine. Hose connector Connecting the Supply Hose Rubber seal •...
  • Page 14 Connecting Hose to Water Tap Push the adapter onto the end of the tap so that the rubber seal forms a watertight connection. Tighten the four fixing screws. Connecting Screw-Type Hose to Tap with Thread Screw the hose connector onto the cold water supply tap.
  • Page 15 Connecting the Cold inlet hoses Remove the guide plate if the tap is too large to fit the adapter. to both Washing Machines Connect the water supply hose connector Guide plate to the water supply hose of the Main front-loading washing machine. Open the accessory installation package of this Mini Washer to find the Connector/Adaptor and the short connection hose.

  • Page 16: Installing The Drain Hose

    Installing the Drain Hose Using the Drain Hose Connector • The drain hose should not be placed higher Connect the drain hose of the front-loading than 100 cm above the floor. Water in the washing machine and the Mini Washer to appliance may not drain or may drain slowly.

  • Page 17: Leveling The Appliance

    If the appliance rocks, level the unbalance. appliance again. NOTE • You can obtain anti-slip sheets from an LG Service Centre or a Hardware store.

  • Page 18: Operation

    OPERATION Using the Appliance Choose the desired washing cycle. • Press the cycle button repeatedly until the Sort laundry and load items. desired cycle is selected. • Sort laundry by fabric type, soil level, colour and load size as needed. Open the door and load items into Mini Washer.

  • Page 19: Sorting Laundry

    Sorting Laundry Caring before loading. • Do not wash items that contain support or memory wire such as Bras as it may Look for the care label on your clothes. damage other clothes as well as the • This will tell you about the fabric content of washing machine and cause noise and your garment and how it should be washed.

  • Page 20: Closing The Door And Drawer

    Close the washing machine Lid until it clicks. • If power failure occurs during product operation, the door cannot be opened. Provide the power again or contact the LG service centre. Push the drawer completely closed. CAUTION • Do not let your hands get stuck between the door and the washing machine, as this can cause injury.

  • Page 21: Adding Cleaning Products

    Adding Cleaning Products Adding Detergent Measure the detergent with the detergent Detergent Dosage dispenser (rubber cup supplied with the washer) pour it into the tub. • Detergent should be used according to the instruction of the detergent manufacturer and selected according to type, colour, soiling of the fabric and washing temperature.

  • Page 22: Adding Fabric Softener

    Adding Softeners Adding Water Softener • A water softener, such as anti-limescale (e.g. Calgon) can be used to cut down on the use Adding Fabric Softener of detergent in extremely hard water areas. CASE 1. When the machine chimes during Dispense according to the amount specified the wash: on the packaging.

  • Page 23: Control Panel

    Control Panel Power Button Display • Press the Power button to turn the • The display shows the cycle status and estimated time remaining. washing machine on. • : Drawer lock indicator • : Lid lock indicator Start/Pause Button • : Child lock indicator •...

  • Page 24: Programme Table

    Programme Table Washing Programme All programmes are cold water only. Programme Description Note Use this programme to wash • Pressing the Start/Pause button without lightly soiled normal items, selecting a programme will cause the Light Soil Light Soil except delicate fabrics such as programme to begin immediately using the wool or silk.
  • Page 25 Programme Description Note • Use quantity of detergent that is appropriate for load size. • Do not wash white or brightly colored laundry with darkly colored laundry that can discharge colors and contaminate clothes. Use this programme to wash • Washing can remove stains more effectively. performance garments that are Active Wear •...

  • Page 26: Option Programme

    Option Programme Child Lock Use this option to disable the controls. This Extra Rinse feature can prevent children from changing cycles or operating the appliance. Use this option to increase the number of rinsing programmes. Locking the Control Panel Press the Power button. Press and hold the Child Lock button for three seconds.

  • Page 27: Smart Functions

    Use this function if you need an accurate for analysis. diagnosis by an LG Electronics service centre when the product malfunctions or fails. Use this function only to contact the service representative, not during normal operation.

  • Page 28: Maintenance

    MAINTENANCE Cleaning the Interior WARNING • Unplug the washing machine before cleaning • Use a towel or soft cloth to wipe around the to avoid the risk of electric shock. Failure to washing machine door opening and door glass. follow this warning may result in serious injury, •...

  • Page 29: Tub Clean

    Tub Clean Cleaning the Water Inlet Filter Use this option to keep the drum clean by • Turn off the water supply tap if the washing sterilizing germs within the drum when the machine is to be left for any length of time (e.g. alert appears on the display, or as required.

  • Page 30: Cleaning The Lint Filter

    Cleaning the Lint Filter NOTE • If the lint filter is damaged, contact an LG The filter is an important part for efficient service centre. washing performance result, so it needs special • Do not operate the washing machine without care from you.
  • Page 31 How to Manage the machine in Step 3. When the Drain Pump is Frozen Freezing conditions • icon may blink on the display when drain pump problems occur, take the following measures. Step 1. When the Door is Frozen Pour 15 ℓ warm water below 50–60 °C in the •...

  • Page 32: Troubleshooting

    TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason...
  • Page 33 Symptoms Reason Solution Supply hose connection is • Check hoses and drain hose connectors loose at the tap, washing for leaks, cracks and splits. machine, or drain hose • Tighten hose connections. connector. • The washing machine pumps out water very rapidly.
  • Page 34 Symptoms Reason Solution • Make sure the inlet filter on the fill valve Filter clogged. is not clogged. Refer to the filter cleaning instructions. • Check that supply hose is not kinked or Supply hose may be kinked. clogged. • Make sure that cold water tap is turned on Insufficient water supply.
  • Page 35 Symptoms Reason Solution Control panel has powered off • This is normal. Press the Power button to due to inactivity. turn the washing machine on. Washing machine is • Make sure cord is plugged securely into a unplugged. working outlet. Water supply is turned off.
  • Page 36 Symptoms Reason Solution Kinked drain hose. • Ensure that the drain hose is not kinked. • Make sure that the drain hose is no higher Washing machine Drain located higher than 100 than 100 cm above the bottom of the will not drain water cm above the floor.

  • Page 37: Error Messages

    Error Messages Symptoms Reason Solution • Close the drawer and press Start/Pause button to start the cycle. Drawer is not closed properly. • If the drawer is closed and the drawer lock error message is displayed, call for service. • Open the drawer and make sure the latch area is free of clothing or other obstructions.
  • Page 38 • The stacking switch will not operate Stacking switch is not properly if the unit is stacked under a working properly. non-LG appliance, or an LG appliance manufactured before 2009. • Thaw out the supply hose using a hot Drain hose, supply hose or water cloth.
  • Page 39 Memo...
