Summary of Contents for LG WT-WHE10SV

  • Page 9 尺 尺 寸 寸 D’ H’...
  • Page 10 2 cm 2 cm...
  • Page 14 max. 3 m max. 6 cm...
  • Page 41 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. www.lg.com Copyright © 2019 LG Electronics Inc. All Rights Reserved...

  • Page 43: Table Of Contents

    Control Panel ....................21 Washing Programme ..................22 Option Programme..................24 Manual Washing .....................26 Special Functions....................27 SMART FUNCTIONS..............28 LG ThinQ Application ..................28 Smart Diagnosis ....................31 MAINTENANCE ................32 Cleaning the Washing Machine ..............32 Cleaning the Water Inlet Filter.................33 Cleaning the Drain Pump Filter (Optional) ............33 ..............34...

  • Page 44: Safety Instructions

    SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 45 Technical Safety If the power cord is damaged or the hole of the socket outlet is loose, do not use the power cord and contact an authorized service centre. The water pressure must be between 30 and 800 kPa. Installation Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.
  • Page 46 Improper use can cause fire or explosion. In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. Do not use or store flammable or combustible substances (ether, benzene, alcohol, chemical, LPG, combustible spray, insecticide, air freshener, cosmetics, etc.) near the appliance.
  • Page 47 If, during spinning, opening the door does not stop the drum within about 15 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre. Do not use a plug socket and wiring equipment for more than their rated capacity.
  • Page 48 Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.

  • Page 49: Installation

    INSTALLATION Parts Door Tempered Glass Dispenser Drawer Bleach Dispenser Drum Leveling Feet Drain hose Water Supply Hose Appearance and specifications may change without notice to improve the quality of the product. Accessories Tie strap (Optional) Anti-rat cover 2 water supply hoses Drain hose Screw for Anti-rat cover (depending on the...

  • Page 50: Specifications

    Specifications Model WT-WHE10SV WT-WHE90SW Power Supply 220 V~, 50 Hz Size 540 mm (W) x 540 mm (D) x 945 mm (H) Product Weight 38 kg Allowable Water Pressure 0 - 800 kPa Max. Capacity 10 kg 9 kg Appearance and specifications may change without notice to improve the quality of the product.

  • Page 51: Installation Place Requirements

    Installation Place If it is impossible to avoid positioning the appliance next to a gas cooker or coal burning Requirements stove, an insulation (85x60 cm) covered with aluminum foil on the side facing the cooker or stove must be inserted between the two Location appliances.

  • Page 52: Connecting The Supply Hose

    Connecting the Supply Connecting Hose to Water Tap Hose Connecting Screw-Type Hose to Tap Before connecting the water supply hose to the with Thread water tap, check the hose type and then choose the correct instruction. Screw the hose connector onto the water supply tap.
  • Page 53 Push the adapter onto the end of the tap Remove the guide plate if the tap is too large so that the rubber seal forms a watertight to fit the adapter. connection. Tighten the four fixing screws. Guide plate G G uid ide de p p p la lat ate te Push the adapter onto the end of the tap Push the supply hose vertically upwards...

  • Page 54: Installing The Drain Hose

    Installing the Drain Hose Connecting Hose to Appliance Attach the hot water line to the hot water inlet on Before connecting the drain hose, check your drain the back of the washing machine. Attach the cold hose model and choose the correct instruction. water line to the cold water inlet on the back of the washing machine.
  • Page 55 Non-pump Model Positioning the Drain Hose The length of the drain hose should not exceed Push the elbow hose toward the body of the 3 m. washing machine. Do not place the drain hose on a threshhold of 6 cm or more. max.

  • Page 56: Leveling The Appliance

    Leveling the Appliance Assembling the Anti-Rat Cover (Optional) If the floor is uneven, turn the adjustable feet as required (Do not insert pieces of wood etc. under Insert the Anti-Rat cover to the assembling hole the feet). Make sure that all four feet are stable from the front or back of the washing machine.

  • Page 57: Operation

    OPERATION Using the Appliance Choose the desired wash programme. Press the button Before the first wash, select a washing programme repeatedly until the desired programme is , add a half load of detergent), selected. allow the washing machine to wash without clothing.

  • Page 58: Sorting Laundry

    Sorting Laundry Caring before loading. Combine large and small items in a load. Load large items first. Look for a care label on your clothes. Large items should not be more than half This will tell you about the fabric content of the total wash load.

  • Page 59: Adding Cleaning Products

    Adding Cleaning Products NOTE Do not let the detergent harden. Doing so may lead to blockages, poor rinse performance or Detergent Dosage odour. Full load : According to manufacturer’s Detergent should be used according to the recommendation. instruction of the detergent manufacturer and selected according to type, colour, soiling of the Part load : 3/4 of the normal amount fabric and washing temperature.
  • Page 60 Adding Fabric Softener Adding Liquid Bleach Do not exceed the maximum fill line. Overfilling Check clothing care label for special can cause early dispensing of the fabric instructions and separate the laundry to be softener, which may stain clothes. Close the bleached.

  • Page 61: Control Panel

    Control Panel For Steam Models Button Button Press the Programmes are available according to button to turn the washing machine on. laundry type. The appliance will automatically turn off Lamp will light up to indicate the selected once a certain time has passed after the programme.

  • Page 62: Washing Programme

    Washing Programme This programme is a powerful, high temperature Wash cycles are designed for the best wash programme designed specifically to reduce certain performance for each type of load. Select the allergens. programme that best matches the load contents for maximum wash performance and fabric care. Stains that can be easily removed with this Press the button to select the...
  • Page 63 Use this programme to pretreat immediate stain Use this programme to wash delicate fabrics such without handwash. It is necessary for clothes as lingerie and woolens. Before washing, check which could smell bad without prompt laundry. the care label for the washing instructions. This programme uses a slow spin to extract water from laundry, so the laundry has more moisture than normal.

  • Page 64: Option Programme

    Option Programme Press the button to change spin strength. Press button to Press the button to adjust indicate remaining time. water level. It can be changed during operation. To use the function This machine detects the quantity of laundry When you select , you automatically, then sets water level.
  • Page 65 This option can be selected to wash heavily Press the soiled clothes by soaking in water for some buttons to select hot water, time to remove dirt and grime. cold water, or hot and cold water (warm water). It can be changed during operation. Press the is selected, washing will be button.

  • Page 66: Manual Washing

    Manual Washing When you need a rinse/spin, spin, rinse, or wash cycle only, these can be set manually. only only only Press the button. Press the Press the Press the Press the button. button. button. button. Rinse and spin are Rinse and spin are Press the Press the...

  • Page 67: Special Functions

    Special Functions Use this option to disable the controls. This feature can prevent children from changing programmes or operating the appliance. Locking the Control Panel Press and hold the buttons simultaneously for 3 seconds. CL and the remaining time are alternatively shown on the display while they are locked.

  • Page 68: Smart Functions

    SMART FUNCTIONS • The application is subject to change for appli- ance improvement purposes without notice to The LG ThinQ application allows you to users. communicate with the appliance using a • Functions may vary by model. smartphone. Communicate with the appliance from a Check the distance between the appliance smartphone using the convenient smart features.
  • Page 69 • If the appliance is having trouble connecting Put the laundry into the drum and add to the Wi-Fi network, it may be too far from detergent into the detergent dispenser drawer. the router. Purchase a Wi-Fi repeater (range • If desired, add bleach or fabric softener to the appropriate areas of the dispenser.
  • Page 70 LG Electronics will also provide open source code • Launch the application and select to you on CD-ROM for a charge covering the cost feature in the menu.

  • Page 71: Smart Diagnosis

    Follow the instructions below to use the audible diagnosis method. • Launch the application and select feature in the menu. provided in the application. Press the button to turn on the appliance. • Do not press any other buttons. Place the mouthpiece of your smartphone close to the c or d logo.

  • Page 72: Maintenance

    MAINTENANCE WARNING This function is a special function to help to clean Unplug the washing machine before cleaning to the inside of the washing machine. Perform this avoid the risk of electric shock. Failure to follow cycle regularly. this warning may result in serious injury, fire, electric shock, or death.

  • Page 73: Cleaning The Water Inlet Filter

    Cleaning the Water Inlet Cleaning the Drain Pump Filter Filter (Optional) Turn off the supply taps to the machine if the The drain filter collects threads and small washing machine is to be left for any length of objects left in the laundry. Check regularly that time (e.g.
  • Page 74 Caution on Freezing During Winter When frozen, the product does not operate normally. Make sure to install the product where it will not freeze during winter. In case the product must be installed outside on a porch or in other outdoor conditions, make sure to check the following.

  • Page 75: Troubleshooting

    TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason...
  • Page 76 Symptoms Reason Solution Dispenser compartment is overfilled causing bleach or softener to dispense immediately. Bleach or softener dispensed ALWAYS measure bleach to prevent overfilling. too soon. Close the dispenser drawer slowly. Bleach or softener was added Always use the dispensers to ensure that directly to the wash load in laundry products are properly dispensed at the Staining...
  • Page 77 Symptoms Reason Solution This is normal. Press the Control panel has powered button to turn off due to inactivity. the washing machine on. Washing machine is Make sure cord is plugged securely into a unplugged. working outlet. Water supply is turned off. Turn both hot and cold taps fully on.
  • Page 78 Find the Wi-Fi network connected to your that you are trying to connect smartphone and remove it, then register your to is incorrect. appliance on LG SmartThinQ. Turn off the Mobile data of your smartphone Mobile data for your and register the appliance using the Wi-Fi smartphone is turned on.

  • Page 79: Error Messages

    Error Messages Symptoms Reason Solution The door is not closed Close the door completely. If the error code is properly. not released, call for service. Check nothing is caught under the door, including shipping materials or clothing. Door lock switch error. Close the door completely.
  • Page 80 Symptoms Reason Solution Unplug the washing machine and wait 60 Control error. seconds. Reconnect power and try again. If the error code is not released, call for service. Water level is too high due to Close the water taps, unplug the washing a faulty water valve.
  • Page 81 Memo...
  • Page 82 Memo...
  • Page 83 Memo...
