DEMO MANUAL DC2116A
Quick start proceDure
Table 1. Power Input and Output Connections
NOMENCLATURE
VDD
GND
VOUT
GND
Table 2. Test Points
NOMENCLATURE
INTVCC
TIMER
PG
ISET
IMON
GND
VOUT
UV
OV
VDD
GND
SENSE
FLT
GATE
GND
Table 3. LED Indicators
NOMENCLATURE
FAULT
POWER BAD
INPUT POWER
OUTPUT POWER
Table 4. Jumpers
NOMENCLATURE
AUTORETRY
TIMER DURATION
2
CONNECTOR
E13
E14
E6
E7
TURRET
E1
E2
E3
E4
E5
E8
E9
E10
E11
E12
E15
E16
E17
E18
E19, E20, E21
PART DESIGNATOR
D1 (Red)
D2 (Red)
D3 (Green)
D4 (Green)
PART DESIGNATOR
JP1
JP2
DESCRIPTION
12V In
12V In Return
12V Out
12V Out Return
DESCRIPTION
INTV
monitor
CC
TIMER pin monitor
PG pin monitor
I
pin monitor
SET
I
pin monitor
MON
V
return monitor
OUT
V
monitor
OUT
UV pin monitor
OV pin monitor
V
monitor
DD
V
return monitor
DD
SENSE pin monitor
FLT pin monitor
GATE pin monitor
Ground
DESCRIPTION
Indicates Overcurrent Fault
V
Not Up to Full Voltage
OUT
Input Voltage Present
Output Voltage Present
DESCRIPTION
ON Position for Autoretry
1.2ms or 2.0ms Timer Duration
dc2116afa
