TSI Instruments Quest The Edge Quick Start Manual page 2

Edge Display and Keypad
Microphone and Windscreen
Measurement Display
Turning on
1. Turn on the Edge by pressing and releasing the
Resetting
Resetting (or clearing the data) is performed by either using the TSI Quest Detection Management
Software DMS when downloading or setting up parameters. Another option is from the Edge's shortcut
reset menu.
+ To reset from the keypad ensure the Edge is off, then:
1. Press key.
2. Press and hold
screen appears. The shortcut menu will appear
(see right).
3. Press the up arrow until the reset icon
4. Press and hold the
were deleted.
A 3, 2, 1 countdown and a shaded bar indicates reset.
5. To exit, press down arrow until
2
Run/Stop Key
Down Arrow
and keys when the splash
key until it shows the files
icon is selected. Press
key.
Reset Icon
Contrast Icon
is selected.
key.
LED Indicator
+ Red - indicates dose has exceeded the
alarm level
+ Amber - indicates stopped
+ Green - indicates measuring
Up Arrow
On/Off/Enter Key
Exit Icon
