TSI Instruments Quest The Edge Quick Start Manual page 3

Calibrating
A calibration may be performed before and/or after a dosimetry test.
1. Remove the windscreen while the Edge is turned on and stopped.
2. Slide the Edge into the cavity of the calibrator, ensuring the
adapter ring is inserted into the calibrator.
3. Turn on the calibrator. Set the calibrator to 114 dB and 1000 Hz
(if applicable).
4. "CAL" will flash on the Edge display automatically detecting the
calibration screen.
5. Press the key to trigger the calibration screen.
6. To adjust the calibration value on the display, repeatedly press the
up/down arrows to match 114.0 dB.
7. Press key to exit.
Viewing and/or navigating data
1. Press the up/down arrow keys to navigate through the
measurements and parameters.
Setting up the Edge
All the Edge parameters are setup via TSI Quest Detection Management Software DMS in the Instrument
Communication panel or button from the DMS start screen.
3
