- Page 1 FA982500TX Moreno Fireplace Tower For assistance with assembly, contact: -Mission Oak Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#:...
-
Page 2: Parts List
Moreno Fireplace Tower-Mission Oak Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Quantity of 4 Quantity of 1 Quantity of 7 Flat washer Allen Wrench 1/4” Screw ∮1/4”x3/4” ∮5/32”x1-1/4”L Quantity of 14 Quantity of 4 Quantity of 2 Screw Shelf Holder Anti-Tipping Hardware ∮1/8”x1/2”L Quantity of 1 Firebox (in a separate carton) Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
- Page 4 Moreno Fireplace Tower- Mission Oak Assembly Instructions Figure 1 Insert cam locks (2) into holes on ( 2) vertical panel (I). Screw cam bolts (1) into holes on right side panel (C). Attach vertical panel (I) Do not over tighten cam bolts, to right side panel (C) by inserting wood please stop when you feel them tighten.
- Page 5 Figure 3 Insert cam locks (2) into holes on cross panel (H). Screw cam bolts (1) into holes on top panel (A). Attach cross panel (H) to top panel (A) by inserting wood dowel (3) and cam bolts (1) into corresponding holes until cross panel (H) and top panel (A) meet.
- Page 6 Figure 5 Use screws (9) and wood dowels (3) to connect bottom cross panel (G) to bottom panel (F). Tighten screws (9) with Philips screwdriver. Figure 6 Insert cam locks (2) into holes on assembled unit from figure 3 and assembled unit from figure 5.
- Page 7 Figure 7 Repeat last step to attach left side panel (B) to assembled unit from figure 6. Figure 8 Attach back panel (J) to assembled unit with screws (10). Tighten screws (10) with Phillips screwdriver. Insert firebox (13) into the back of the unit.
- Page 8 Figure 9 Insert shelf holders (11) into holes on side panels. Place adjustable shelf (K) onto the shelf holder (11). Make sure the shelf holder (11) holds the shelf (K) firmly. Figure 10 Attach anti-tipping hardware (12) to the back of the upper back panel (D) as shown in figure 10.
- Page 9 Figure 11 Now your Moreno fireplace tower is ready for use.
- Page 10 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
