"CARTWRIGHT"CONVERTIBLE FIREPLACE
FA928500TX-Mission Oak
FA928600TX-IVORY
FA928700TX-ESPRESSO
ASSEMBLY INSTRUCTION
ATTENTION:
The Extension panel not be loaded with more than 6 LBS
For assistance with assembly contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
www.seidal.com
Advertisement
Related Manuals for SEI FA928500TX-Mission Oak
Summary of Contents for SEI FA928500TX-Mission Oak
- Page 1 "CARTWRIGHT"CONVERTIBLE FIREPLACE FA928500TX-Mission Oak FA928600TX-IVORY For assistance with assembly contact: FA928700TX-ESPRESSO Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com ASSEMBLY INSTRUCTION www.seidal.com ATTENTION: The Extension panel not be loaded with more than 6 LBS...
-
Page 2: Parts List
"CARTWRIGHT"CONVERTIBLE FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 3 "CARTWRIGHT"CONVERTIBLE FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 4 "CARTWRIGHT"CONVERTIBLE FIREPLACE Assembly Instructions INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES OF (2) LEFT SIDE PANEL& (4) )RIGHT SIDE PANEL,THEN USE （C） CAM LOCK TO CONNECT (2)LEFT SIDE PANEL&(4)LEFT FRONT PANEL , (3)&(5) CONNECT PLS DO THE SAME STEP AS (2)&(4).
- Page 5 "CARTWRIGHT"CONVERTIBLE FIREPLACE Assembly Instructions ATTACH MIDDLE FRONT PANEL(6) TO LEFT MIDDLE SIDE PANEL(7) & RIGHT MIDDLE SIDE PANEL(8) SLIPPING WOOD DOWEL(B) & CAM BOLT(A) UNTIL MIDDLE FRONT PANEL(6) & LEFT MIDDLE SIDE PANEL (7) & RIGHT MIDDLE SIDE PANEL (8)MEET.SECURE BY ROTATING CAM LOCK (C) COUNTERCLOCKWISE WITH PHILLIPS SCREWDRIVER Figure 4...
- Page 6 "CARTWRIGHT"CONVERTIBLE FIREPLACE Assembly Instructions PUSH SUPPORT WOOD SLIDE TO LET THE CORNER PANEL PARALLEL WITH THE TOP PANEL. USING 6 SMALL WOOD SCREWS (J) FASTEN PRE-INSTALLED HINGES WITH CORNER PANEL (10). Figure 7 PUSH (12) INSERT TO THE RELATED PLACE OF MAIN BODY ,THEN INSERT (I)WOOD SCREW THROUGH (11)INSERT FIXED BAR TO LOCK TIGHTLY.
- Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
