- Page 1 "ELKMONT" FIREPLACE FA928200TX-SALEM ANTIQUE OAK ASSEMBLY INSTRUCTION For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Wood Screw
"ELKMONT" FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 3 "ELKMONT" FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 "ELKMONT" FIREPLACE Assembly Instructions INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES OF (2) LEFT SIDE PANEL& (3) )RIGHT SIDE PANEL,THEN USE （C） CAM LOCK TO CONNECT (2)LEFT SIDE PANEL&(4)LEFT FRONT PANEL , (3)&(5) CONNECT PLS DO THE SAME STEP AS (2)&(4) Figure 1 INSERT （A）...
- Page 5 "ELKMONT" FIREPLACE Assembly Instructions INSERT (B) WOOD DOWEL INTO THE RELATED HOLE OF (7) BASE ,AFTER ASSEMBLED FIGURE 3 ,THEN INERT IT INTO THE RELATED PLACE OF THE MAIN BODY THEN ISERT (D)WOOD SCREW TO THE RELATED HOLES TO CONECT (3) SIDE FRONT PANEL.FINALLY USE SCREWDRIVER TO LOCK TIGHTLY.
- Page 6 "ELKMONT" FIREPLACE Assembly Instructions PUSH (12) INSERT INTO THE RELATED SPACE OF THE BODY,THEN USE (11) INNER FIXED BAR TO LOCK TIGHTLY BY USE (D)WOOD SCREW. Figure 7 Figure 8...
- Page 7 Please contact the retailer that you purchased from for returns. We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com and we might feature it on our site or use it to model one of our inspirational photos...
