"CLAREMONT" CONVERTIBLE MEDIA FIREPLACE
FA931000TX-CHERRY
FA931400TX-IVORY
FA931500TX-BLACK
FA931600TX-BROWN MAHOGANY
For assistance with assembly contact:
FA931700TX-GLAZED PINE
Southern Enterprises Inc.
Customer Service 1-800-633-5096
Assembly Instructions
service@seidal.com
www.seidal.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SEI CLAREMONT FA931000TX-CHERRY
Summary of Contents for SEI CLAREMONT FA931000TX-CHERRY
- Page 1 “CLAREMONT” CONVERTIBLE MEDIA FIREPLACE FA931000TX-CHERRY FA931400TX-IVORY FA931500TX-BLACK FA931600TX-BROWN MAHOGANY For assistance with assembly contact: FA931700TX-GLAZED PINE Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
-
Page 2: Parts List
“CLAREMONT” CONVERTIBLE MEDIA FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below . - Page 3 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Assembly Instructions INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES,THEN USE（C）CAM LOCK TO CONNECT (5) SUPPORT PANELS&(6) SHELF PANEL. FINALLY PLACE (R) COVER IN CAM LOCK. Figure 1 INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES,THEN USE（C）CAM LOCK TO CONNECT (3)FRONT SIDE...
- Page 5 CLAREMONTCONVERTIBLE MEDIA FIREPLACE Assembly Instructions INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES,THEN USE （C） CAM LOCK TO (1) CONNECT TOP PANEL . FINALLY PLACE (R) COVER IN CAM LOCK. Figure 4 INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES,THEN USE（C）CAM LOCK TO CONNECT (7) BASE .
- Page 6 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Assembly Instructions USE （M）WOOD SCREW CONNECT (8) UPPER BACK PNAEL . Figure 7 AFTER ASSEMBLE FIGURE(7) USE（K）WOOD SCREW & (Q) HINGE TO CONNECT (10)DOORS . INSERT (P) SHELF HOLDER TO THE RELATED HOLES,THEN PUT (9) ADJUSTABLE SHELF PANELS ON THE （P）SHELF HOLDERS.
- Page 7 Figure 9 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Assembly Instructions PUSH (R) INSERT TO THE RELATED PLACE OF MAIN BODY. Figure 10 INSERT THE (L) WOOD SCREW INTO THE RELATED HOLES OF (11) INNER FIXED BAR ,THEN USE SCREWDRIVER TO LOCK IT TIGHTLY.
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
- Page 9 parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
