- Page 4 1. Insert cam locks(C) into predrilled holes on left side block fire panel(8) & right side block fire panel (9) . Screw cam bolt(A) into predrilled holes on lower block fire panel(10). Attach lower block fire panel(10) to left side block fire panel(8) &...
- Page 5 3. Attach assembled unit in the step 2 to right front panel (6) & left front panel(5) by slipping wood dowel(B) into corresponding predrilled holes until assembled unit in the step 2 & right front panel (6) & left front panel(5) meet. Inserting flat head screw (D) and tightening with Phillips screwdriver (not included).
- Page 6 5. Insert wood dowel(B) into predrilled holes on assembled unit in the step 4.Insert base (2) into assembled unit in the step 4. 6. Inserting flat head screw (D) and tightening with Phillips screwdriver (not included),as shown in the step 6.
- Page 7 7. Attached top panel(1) by inserting flat head screw (D) and tightening with Phillips screwdriver(not included). 8. Insert firebox(12) to the related place of assembled unit. Attached wood holder (11) by inserting flat head screw(D) and tightening with Phillips screwdriver(not included). Now your new fireplace is ready to use.
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product .
