- Page 1 FA942700TX LAKE AUSTIN FIREPLACE -ESPRESSO For ssistance with assembly contact: Southern Enterprises Inc. ASSEMBLY INSTRUCTION Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#11246...
- Page 2 LAKE AUSTIN FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 3 LAKE AUSTIN FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 4 LAKE AUSTIN FIREPLACE Assembly Instructions INSERT CAM BOLT(A) & WOOD DOWEL(B) INTO THE RELATED HOLES OF LEFT SIDE PANEL(2)& RIGHT SIDE PANEL(3),THEN USE CAM LOCK （C） TO CONNECT LEFT SIDE PANEL(2) & LEFT FRONT PANEL(4) , RIGHT SIDE PANEL(3) & RIGHT FRONT PANEL(5) TOGETHER.
- Page 5 LAKE AUSTIN FIREPLACE Assembly Instructions INSERT CAM BOLT（A）,WOOD DOWEL(B) INTO THE RELATED HOLES OF FRONT SIDE PANEL(7)，THEN USE CAM LOCK(C) TO CONNECT FRONT UPPER PANEL(6), FRONT LOWER PANEL(8) WITH FRONT SIDE PANEL(7) TOGETHER. Figure 3 INERT WOOD DOWEL(B) TO THE RELATED HOLES TO CONNECT FINISHED PART IN FIGURE 2 &...
- Page 6 LAKE AUSTIN FIREPLACE Assembly Instructions INSERT CAM BOLT（A）,WOOD DOWEL(B) INTO THE RELATED HOLES, THEN USE CAM LOCK（C） TO CONNECT TOP PANEL(1) TOGETHER. Figure 5 INSERT FLAT HEAD SCREW (I) INTO THE RELATED HOLES TO LOCK THE PANEL TIGHTLY. Figure 6...
- Page 7 LAKE AUSTIN FIREPLACE Assembly Instructions PUT FIREBOX (11) INTO THE MAIN BODY FROM THE BACK， THEN USE FLAT HEAD SCREW （1） TO SECURE THE FIREBOX WITH INSERT FIXED BAR (10) Figure 7 NOW YOUR NEW FIREPLACE IS READY TO USE Figure 8...
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
