- Page 4 1.Insert cam locks(C) into predrilled holes on side panel (2L).Screw cam bolt(A) into predrilled holes on side front panel (3L). Attach side front panel (3L) to side panel (2L) by slipping wood dowel(B) & cam bolt(A) into corresponding predrilled holes until side front panel (3L) &...
- Page 5 3.Insert cam locks(C) into predrilled holes on lower block fire panel(5).Screw cam bolt(A) into predrilled holes on side block fire panel (6L&R). Attach side block fire panel (6L&R) to lower block fire panel(5) by cam bolt(A) into corresponding predrilled holes until sidde block fire panel (6L&R) &...
- Page 6 5.Insert wood dowel(B) into predrilled holes on base(7).Insert assembled unit in the step 4 into assembled unit in the step 2. 6.Inserting flat head screw (I) and tightening with Phillips screwdriver(not included),as shown in the step 6.
- Page 7 7.Attached top panel(1) by inserting flat head screw (I) and tightening with Phillips screwdriver(not included). 8.Insert inside frame(8) into assembled unit in the step 7.Inserting flat head screw (I) and tightening with Phillips screwdriver(not included)
- Page 8 9.Insert firebox(10) to the related place of assembled unit.Attached wood holder (9) by inserting flat head screw(I) and tightening with Phillips screwdriver(not included). 10. Now your new fireplace is ready to use.
- Page 9 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product .
