"WALDEN"PETITE FIREPLACE
FA9101 - PLANTATION OAK
FA9102 – CLASSIC MAHOGANY
FA9103 - ANTIQUE WHITE
For assistance with assembly contact:
FA9104 - BLACK
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
Assembly Instructions
www.seidal.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the walden FA9101 and is the answer not in the manual?

Questions and answers

Summary of Contents for SEI walden FA9101

  • Page 1 "WALDEN"PETITE FIREPLACE FA9101 - PLANTATION OAK FA9102 – CLASSIC MAHOGANY FA9103 - ANTIQUE WHITE For assistance with assembly contact: FA9104 - BLACK Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com...
  • Page 2 "WALDEN"PETITE FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
  • Page 3 "WALDEN"PETITE FIREPLACE” Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
  • Page 4 "WALDEN"PETITE FIREPLACE” Assembly Instructions INSERT 2PCS WOOD DOWEL(B) AND 2PCS CAM BOLT(A) ONTO PREDRILLED HOLES OF RIGHT/ LEFT FRONT PANELS (2&3). THEN INSERT 2PCS CAM-LOCKS (C) INTO BIG HOLES ON BACK OF MIDDLE FRONT PANEL (1) WITH SLOT FOR SCREWDRIVER FACING OUTWARD.
  • Page 5 "WALDEN"PETITE FIREPLACE” Assembly Instructions PUT THE TOP FRAME(7) ONTO ASSEMBLED FRAME UPRIGHTLY,THEN INSERT 10PCS FLAT HEAD LONG SCREW(D) ONTO CORRESPONDING PLACE TO ASSEMBLE TOP FRAME AND PREASSEMBLED UNIT TOGETHER AS FIGURE 4 SHOWN. Figure 4 INSERT 4PCS WOOD DOWELS (B) INTO PREDRILLED HOLES ON EDGES OF LEFT AND RIGHT BACK PANELS (10) AND FIT INTO...
  • Page 6 PANELS (10). AS FIGURE 7 SHOWN. Figure 7 We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com we might feature it on our site or use it to model one of our inspirational photos.
  • Page 7 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI. The fireplace mantel will fit both gel fuel and electric firebox inserts. Depending on the insert ordered only one insert will be included.
