- Page 1 LOWERY FIREPLACE FA966800TX--ESPRESSO For assistance with assembly contact: Assembly Instructions Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com wwww.seidal.com...
- Page 2 PACKAGE CONTENTS...
- Page 3 PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Top Panel Front Lower Panel Bottom Panel Small Central Pilaster(L/R) Side Panel(L/R) Shelf Frame Big Outside Pilaster(L/R) Wood Holder Front Upper Panel Firebox(sold in separate box) HARDWARE CONTENTS(shown actual size) Wood Dowel Cam Bolt Qty.22 Qty.22 Cam Lock...
- Page 4 SAFETY INFORMATION Please read and undersand this entire manual before attempting to assemble,operate or install the product.If you have any questions regarding the product,please call customer service at 800-633-5096 or in dallas 972-869-0111/ 9am - 4pm Mon-Fri. WARNING ．Products is heavy and should be assembled near its desired location. ．It is recommended that two people move the finished product to prevent injury.
- Page 5 ASSEMBLY INSTRUCTIONS Insert cam lock (C) into corresponding holes on side panels (3L&3R) . Make sure the arrow points towards the hole of the edge. Screw cam bolt (B) and insert wood dowel (A) into corresponding holes on big outside pilasters (4L&4R). Attach the pilasters to the side panels correspondingly and tighten them with phillips head screwdriver (not included)
- Page 6 ASSEMBLY INSTRUCTIONS Insert one wood dowel (A) into the hole on the bottom panel as shown. Attach the front frame assembled in step 1 to the small central pilasters from the back with the flat head screw (D) as shown.Tighten them with phillips head scrwedriver (not included).
- Page 7 ASSEMBLY INSTRUCTIONS Place the fireplace instrument on the right positions onto the shelf frame. Hold the instrument from the back with wood holder (9) and flat head scerw (D). Make sure the flange of the instrument traps into the groove of the wood holder. Tighten the holders with phillips head screwdriver (not included) as shown.
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item:Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.Replacement, if available, will be honored within this time frame.
