Inputs - Haulotte HA16PX Technical Training Manual

2 2 . . 7 7 . . 3 3 . . I I N N P P U U
SA 1
02 - 9
SA 2
03 - 2
SA 3
03 - 3
SA 4
03 - 5
SA 5
03 - 6
SA 6
03 - 9
SA 7
03 - 10
SA 8
03 - 12
SA9
03 - 13
SA 11
03 - 15
SA12
03 - 16
SA 13
05 - 17
TRAINING MANUAL DIAGNOSTIC Level 2
2420339030
T T S S
COMMANDS
Selection (upper/lower control box)
28.7 Accelerator (605)
29.11 Differential lock (807)
Basket rotation
30.3 SA4a left (3100)
30.4 SA4b right (3110)
Basket compensation (upper control box)
30.5 SA5a lift (401)
30.6 SA5b descent (402)
Jib (lower control box)
4.6 SA6b lift (406)
4.9 SA6a descent (405)
jib (upper control box)
30.9 SA7a lift (410)
30.8 SA7b descent (409)
Telescopic boom extension (lower control box)
4.15 SA8a retraction (411)
4.14 SA8b extension (412)
Telescopic boom extension (upper control box)
30.10 SA9a retraction (418)
30.11 SA9b extension (419)
Selection of drive speed
29.10 Low speed: 805=1 and 804=0
29.9 Medium speed: 805=0 and 804=0
High speed: 805=0 and 804=1
Steering rear axle
29.7 SA12a right (707)
29.8 SA12b left (708)
Boom (lower control box)
28.1 SA13a lift (504)
28.2 SA13b descent (505)
