Summary of Contents for IBASE Technology SI-60E-6H

Page 1 SI-60E-6H User Manual SI-60E-6H User Manual...
Page 2 SI-60E-6H User Manual Revision Release Date V1.0 2017/08/04 V1.1 2017/12/21...
Page 3 IBASE Technology Inc. Copyright © 2017 IBASE Technology Inc. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of IBASE Technology INC.
Page 4: Table Of Contents
SI-60E-6H User Manual Table of Contents Setting up your system ......................v Care during use ........................vi Acknowledgments ......................... vii CHAPTER 1 INTRODUCTION ................... 1 1.1 General Description ......................1 1.2 System Specifications ...................... 2 1.2.1 Hardware specifications ....................2 1.2.2 Dimensions ........................
Page 5: Setting Up Your System
IBASE Technology Inc. Safety Information Your SI-60E-6H is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions Setting up your system •...
Page 6: Care During Use
SI-60E-6H User Manual Care during use • Do not walk on the power cord or allow anything to rest on it. • Do not spill water or any other liquids on your system. • When the system is turned off, a small amount of electrical current still flows.
Page 7: Acknowledgments
FINTEK is a registered trademark of FINTEK Electronics Corporation. • REALTEK is a registered trademark of REALTEK Electronics Corporation. • All other product names or trademarks are properties of their respective owners. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 8: Chapter 1 Introduction
4 Gen. Intel Core graphics. The SI-60E-6H integrates six (6) HDMI ports with independent video output and one DVI-I for console. Additionally, SI-60E-6H has two quad-channel DDR3L-1600 sockets to provide up to 32GB of memory. It also has dual Gigabit Ethernet, dual extended SSD drive, Intel AMT for remote control and IBASE’s...
Page 9: System Specifications
SI-60E-6H User Manual 1.2 System Specifications 1.2.1 Hardware specifications Model Name SI-60E-6H System Mainboard MBD60E 4th Generation Intel® Core™ i7/i5/i3 and Pentium® QC/DC processors; Up to 3.5GHz Memory 4x DDR3 1600 MHz, Max. 32GB I/O Interface 6x HDMI with independent video output 1x DVI-I for console 4x USB 3.0 ports...
Page 11: I/O View
SI-60E-6H User Manual 1.2.3 I/O view SI-60E-6H front side SI-60E-6H rear side Note: Be sure to press the EDID button shortly so as to clear the EDID register if any connected display/monitor is unable to be recognized, or when the image...
Page 12: Packing List
Wireless; 3.75G UMTS/HSPA & GPS Module 3G+GPS [ZU200] RoHS (A008WIRELESS00510P) Wireless; 3.75G UMTS/HSPA [NAVISYS WW-350U] WW-350U RoHS (A008WIRELESS00530P) Cable; SMA IPX Cable For 3G 30CM [RF11030A] Cable RoHS (A012INTENAL010000P) Antenna 3G [ANT0921Q2P] RoHS (A055ANT0921Q2P000P) Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 13: Hardware Installation
SI-60E-6H User Manual 1.4 Hardware Installation 1.4.1 Mounting installation 1. Please install SI-60E-6H to the intended location using 4x M4*0.7*6L screws, as shown in the picture.
Page 14: Installing The Storage
IBASE Technology Inc. 1.4.2 Installing the storage 1. Remove the two screws on the HDD cover and draw the HDD out. 2. Install the HDD/SSD to the HDD bracket with 4 screws. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 15: Replacing The Hdmi Module
SI-60E-6H User Manual 1.4.3 Replacing the HDMI module 1. Release the screw(s) on the HDMI module. 2. Pull out the HDMI module and replace with a new one.
Page 16: Installing The Rackmount
IBASE Technology Inc. 1.4.4 Installing the rackmount 1.Install the system to the intended location using M3 screws as shown in the picture below. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 17: Chapter 2 Motherboard Introduction
SI-60E-6H User Manual CHAPTER 2 MOTHERBOARD INTRODUCTION 2.1 Introduction MBD60E Jumpers and Connectors...
Page 19: Installations
SI-60E-6H User Manual 2.2 Installations 2.2.1 Installing the memory The MBD60E board supports Four DDR3 memory modules for a maximum total of 32GB in DDR3 SODIMM memory type. Installing and Removing Memory Modules To install the DDR3 modules, locate the memory slot on the board and perform the following steps: 1.
Page 20: Setting The Jumpers
JBAT1: Clear CMOS Contents JBAT1 Setting Function Pin 1-2 Normal Short/Closed Pin 2-3 Clear CMOS Short/Closed JP1: COM2 RS232 RI/+5V/+12V Power Setting Setting Function Pin 1-3 +12V Short/Closed Pin 3-4 Short/Closed Pin 5-3 Short/Closed Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 21 SI-60E-6H User Manual JP2: COM1 RS232 RI/+5V/+12V Power Setting Setting Function Pin 1-3 +12V Short/Closed Pin 3-4 Short/Closed Pin 5-3 Short/Closed JP3: Flash Descriptor Security Override (Factory use only)
Page 22: Connectors On Mbd60E
Data set ready Request to send Clear to send Ring indicator Not Used J2: ATX +12V Jack Pin # Signal Name Ground Ground DC_IN DC_IN J3: For SPI Debug tools Pin Header Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 23 SI-60E-6H User Manual J4, J5, J6, J7 DDR III Socket J8: MCU Flash Connector (factory use only) J9: Debug Port Connector (Factory use only) J10: Reset Pin Header J11: Mini PCIe Slot (Full size with SIM Card)
Page 24 Signal Name Pin # Pin # Signal Name 3.3V 3.3V -12V 3.3V Ground Ground PS-ON Ground Ground Ground Ground Ground Power good 5VSB +12V +12V Ground +3.3V J14: SIM Card Slot Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 25 SI-60E-6H User Manual CN1: COM1 / DVI-I Connector Signals of COM1 Connector: Signal Name Pin # RS-232 R2-422 RS-485 DATA- DATA+ Ground Ground Ground CN2: Audio Jack CN3: RTL8111G-CG /USB3.0 Connector...
Page 26 CN5/6:SATA 3 Connector CPU_FAN1: CPU Fan Power Connector Pin # Signal Name Ground +12V Rotation detection Control GPU_FAN1: GPU Fan Power Connector Pin # Signal Name Ground +12V Rotation detection Control Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 27 SI-60E-6H User Manual SYS_FAN1: System Fan1 Power Connector Pin # Signal Name Ground +12V Rotation detection SW1: Power On Button LED1: PWR (Green)/ HDD LED (Red) PCIE1, PCIE2, PCIE3: HDMI Signal from AMD E8860 to IDD104...
Page 28: Chapter 3 Bios Setup
These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 29 SI-60E-6H User Manual Main Settings Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit System Language [English] → ←Select Screen ↑↓Select Item System Date [Tue Enter: Select +- Change Opt. 01/20/2009]...
Page 30 +- Change Opt. ► AMT Configuration F1:General Help F2:Previous Values ► USB Configuration F3: Optimized Defaults F4: Save & Exit ► F81846 Super IO Configuration ESC: Exit ► F81846 H/W Monitor Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 31 SI-60E-6H User Manual ACPI Settings Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit ACPI Settings → ←Select Screen ↑↓Select Item Enter: Select S3 only (Suspend to …) ACPI Sleep State +- Change Opt.
Page 32 Enable/Disable Security Device. NOTE: Your Computer will reboot during restart in order to change State of the Device. Pending operation Schedule an Operation for the Security Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 33 SI-60E-6H User Manual Wake up event settings Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit → ←Select Screen ↑↓Select Item Wake on PCIE Wake Event Disabled Enter: Select +- Change Opt.
Page 34 Hardware Prefetcher Disabled +- Change Opt. F1: General Help Adjacent Cache Line Prefetch Disabled F2: Previous Values F3: Optimized Defaults EIST Enabled F4: Save & Exit Turbo Mode Enabled ESC: Exit Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 35 SI-60E-6H User Manual Hyper-threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When Disabled only one thread per enabled core is enabled. Active Processor Cores Number of cores to enable in each processor package.
Page 36 (2) AHCI Mode. (3) RAID Mode. SATA Controller Speed Indicates the maximum speed the SATA controller can support. Port 0 Enable or Disable SATA Port Hot Plug Designates this port as Hot Pluggable. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 37 SI-60E-6H User Manual Shutdown Temperature Configuration Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit → ← Select Screen ↑↓Select Item APCI Shutdown Temperature Disabled Enter: Select +- Change Opt. F1:General Help...
Page 38 AMT Configuration OEMFLag Bit 2: Enable/Disable MEBx selection screen. Hide Un-Configure ME Configuration OEMFlag Bit 6: Hide Un-Configure ME without password Confirmation Prompt Un-Configure ME OEMFlag Bit 15: Un-Configure ME without password. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 39 SI-60E-6H User Manual Amt Wait Timer Set timer to wait before sending ASF_GET_BOOT_OPTIONS. Activate Remote Assistance Process Trigger CIRA boot. USB Configure Enable/Disable USB Configure function. PET Progress User can Enable/Disable PET Events progress to receive PET events or not.
Page 40 Maximum time the device will take before it properly reports itself to the Host Controller. ‘Auto’ uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 41 SI-60E-6H User Manual F81846 Super IO Configuration Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit F81846 Super IO Configuration → ← Select Screen F81846 Super IO Chip F81846 ↑↓Select Item ►...
Page 42 The values are read-only values as monitored by the system and show the PC health status. Smart SYS_FAN1/CPU_FAN1 Function This field enables or disables the smart fan feature. Disabled (default) 50 ℃ 60 ℃ 70 ℃ 80 ℃ Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 43 SI-60E-6H User Manual Chipset Settings This section allows you to configure and improve your system and allows you to set up some system features according to your preference. Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced...
Page 44 The control of Extended Synch on SB side of the DMI Link. PCIe-USB Glitch W/A PCIe-USB Glitch W/A for bad USB device(s) connected behind PCIE/PEG port. Subtractive Decode Enable or disable PCI Express Subtractive Decode. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 45 SI-60E-6H User Manual USB Configuration Main Advanced Chipset Boot Security Save & Exit USB Configuration → ←Select Screen ↑↓Select Item USB Precondition Disabled Enter: Select +- Change Opt. xHCI Mode Auto F1:General Help F2:Previous Values F3: Optimized Defaults F4: Save & Exit...
Page 46 ↑↓Select Item Enter: Select Primary Display +- Change Opt. F1:General Help Primary PEG Auto F2:Previous Values Primary PCIE Auto F3: Optimized Defaults F4: Save & Exit Internal Graphics Disabled ESC: Exit Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 47 SI-60E-6H User Manual Primary Display Select which of IGFX/PEG/PCI graphics device should be Primary Display or select SG for switchable Gfx. Primary PEG Select PEG0/PEG1/PEG2/PEG3 Graphics device should be Primary PEG. Primary PCIE Select PCIE0/PCIE1/PCIE2/PCIE3/PCIE4/PCIE5/PCIE6PCIE7 Graphics device should be Primary PCIE.
Page 48 Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. Boot Mode select Select boot mode LEGACY/UEFI Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 49 SI-60E-6H User Manual FIXED BOOT ORDER Priorities Sets the system boot order CSM parameters This section allows you to configure the boot settings. Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit...
Page 50 +- Change Opt. Maximum length F1:General Help F2:Previous Values F3: Optimized Defaults F4: Save & Exit Administrator Password ESC: Exit User Password Administrator Password Set Administrator Password User Password Set User Password Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 51 SI-60E-6H User Manual Save & Exit Settings Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Exit Discard Changes and Exit Save Changes and Reset Discard Changes and Reset Save Options →...
Page 52: Chapter 4 Drivers Installation
Installation Utility before proceeding with the drivers installation. 4.1 Intel Chipset Software Installation Utility 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products. 2. Click Intel(R) Chipset Software Installation Utility. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 53 SI-60E-6H User Manual 3. When the Welcome screen to the Intel® Chipset Device Software appears, click Next to continue. 4. Click Accept to accept the software license agreement and proceed with the installation process.
Page 54 5. On the Readme File Information screen, click Install to continue the installation. 6. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 55: Amd Radeon E8860 Graphics Driver
SI-60E-6H User Manual 4.2 AMD Radeon E8860 Graphics Driver 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products. Click AMD Radeon E8860 Graphics Driver. 2. When the Welcome screen appears, click Next to continue.
Page 56 IBASE Technology Inc. 4. Click Install to continue the installation process. 5. Select Express and the installation location and click Next. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 57 SI-60E-6H User Manual 6. Click Accept to accept the End User License Agreement. 7. Setup complete. Click Finish to restart the computer and for changes to take effect.
Page 59: Realtek High Definition Audio Driver
SI-60E-6H User Manual 4.3 Realtek High Definition Audio Driver 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products. 2. Click Realtek High Definition Audio Driver.
Page 60 3. On the Welcome to the InstallShield Wizard screen, click Yes to proceed with and complete the installation process. 4. The InstallShield Wizard Complete. Click Finish to restart the computer and for changes to take effect. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 61: Intel® I21X Gigabit Network Driver
SI-60E-6H User Manual 4.4 Intel® I21x Gigabit Network Driver 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products. 2. Click Intel® I21x Gigabit Network Driver.
Page 63 SI-60E-6H User Manual 5. Click the checkbox for Drivers in the Setup Options screen to select it and click Next to continue. 6. The wizard is ready to begin installation. Click Install to begin the installation.
Page 65: Intel® Management Engine(Me) Driver
4.5 Intel® Management Engine(ME) Driver Follow the steps below to install the Intel Management Engine. 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products.and then Intel® Management Engine(ME) Driver. 2. When the Welcome screen for Intel® Management Engine Components, click the...
Page 66 IBASE Technology Inc. 3. Click Yes to to agree with the license agreement. 4. When the Setup Progress screen appears, click Next. Then, click Finish when the setup progress has been successfully installed. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 67 SI-60E-6H User Manual...
Page 68: Intel® Usb 3.0 Extensible Host Controller Driver
IBASE Technology Inc. 4.6 Intel® USB 3.0 eXtensible Host Controller Driver 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products. Click Intel® USB 3.0 eXtensible Host Controller Driver. 2. When the Welcome screen to the InstallShield Wizard for Intel® USB 3.0 eXtensible Host Controller Driver, click Next.
Page 69 SI-60E-6H User Manual 3. Click Yes to to agree with the license agreement and continue the installation. 4. On the Readme File Information screen, click Next to continue the installation of the Intel® USB 3.0 eXtensible Host Controller Driver.
Page 71: Realtek Rtl8111G Lan Driver
SI-60E-6H User Manual 4.7 Realtek RTL8111G LAN Driver 1. Insert the DVD that comes with the board. Click System and then SI-60E-6H Series Products. Click Realtek RTL8111G LAN Driver. 2. In the Welcome screen, click Next.
Page 72 IBASE Technology Inc. 3. When the Ready to Install the Program screen appears, click Install to continue. 4. When InstallShield Wizard is complete, click Finish. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 73: Appendix
Windows 7 / 8.1 • Driver Installation: AMD Eyefinity technology with SI-60E-6H enables a single GPU to support up to 6 independent displays output simultaneously. Before using the AMD Eyefinity functions on SI-60E-6H, you must install both AMD VGA driver and...
Page 75 SI-60E-6H User Manual AMD Eyefinity Configuration Step 1: Click AMD Eyefinity Multi-Display for Video wall display configuration setting. Step 2: Click Create Eyefinity Display Group.
Page 76 Step 3: Click Show More for information on the available Mixed Mode. If the box does not show on your screen, your device does not support Mixed Mode. Step 4: Click Use a new arrangement, then click Next. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 77 SI-60E-6H User Manual Step 5: Select a display to start the display group arrangement, and click Next. Step 6: Select a layout for the display group from the dropdown list. Click Next.
Page 78 3 x 1 Portrait Display Group • 1 x 2 Landscape Display Group • 1 x 3 Landscape Display Group • 1 x 2 Portrait Display Group • 1 x 3 Portrait Display Group Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 79 SI-60E-6H User Manual For 4 displays output: For 5 displays output: • • 4 x 1 Landscape Display Group 5 x 1 Portrait Display Group • 4 x 1 Portrait Display Group • 1 x 5 Landscape Display Group •...
Page 80 2 x 3 Landscape Display Group • 1 x 6 Landscape Display Group • 2 x 3 Portrait Display Group • 3 x 2 Landscape Display Group • 3 x 2 Portrait Display Group Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 81 SI-60E-6H User Manual Step 7: Click Start arrangement to synchronize the display arrangement in the AMD Catalyst Control Center with your actual physical setup. Then click Next and go to Step...
Page 82 Then the next display is identified by displaying the blue background. Continue this process until all displays have been identified and assigned to their corresponding position within the grid. Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 83 SI-60E-6H User Manual Step 9: Once all settings are done, the display group in the wizard should reflect your physical setup. If not, click Restart arrangement to start arrangement again. To continue, click Next. If your device does not support the Mixed Dimension feature, go to Step 12.
Page 85 SI-60E-6H User Manual Step 11: Choose a resize mode: Full mode, Fit mode, or Expand mode and click Next. • Fill mode will utilize the full real estate of each display in the configuration by stretching the desktop as necessary.
Page 87: I/O Port Address Map
SI-60E-6H User Manual B. I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address...
Page 88: Interrupt Request Lines (Irq)
Intel(R) 8 Series/C220 Series SATA AHCI Controller - 8C02 IRQ 19 Intel(R) Active Management Technology - SOL (COM3) IRQ 22 High Definition Audio Controller IRQ 23 Intel(R) 8 Series/C220 Series USB EHCI #1 - 8C26 Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 89: Watchdog Timer Configuration
SI-60E-6H User Manual D. Watchdog Timer Configuration The WDT is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock.
Page 90 Set_F81846_Reg(0xF6, interval); //set timer bBuf = Get_F81846_Reg(0xFA); bBuf |= 0x01; Set_F81846_Reg(0xFA, bBuf); //enable WDTO output bBuf = Get_F81846_Reg(0xF5); bBuf |= 0x20; Set_F81846_Reg(0xF5, bBuf); //start counting //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81846_LD(0x07); Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 91 SI-60E-6H User Manual //switch to logic device 7 bBuf = Get_F81846_Reg(0xFA); bBuf &= ~0x01; Set_F81846_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81846_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81846_Reg(0xF5, bBuf); //disable WDT //---------------------------------------------------------------------------...
Page 92 (ucDid == 0x07) //Fintek 81866 goto Init_Finish; F81846_BASE = 0x00; result = F81846_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81846 (void) outportb(F81846_INDEX_PORT, F81846_UNLOCK); outportb(F81846_INDEX_PORT, F81846_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81846 (void) outportb(F81846_INDEX_PORT, F81846_LOCK); Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
Page 93 SI-60E-6H User Manual //--------------------------------------------------------------------------- void Set_F81846_LD( unsigned char LD) Unlock_F81846(); outportb(F81846_INDEX_PORT, F81846_REG_LD); outportb(F81846_DATA_PORT, LD); Lock_F81846(); //--------------------------------------------------------------------------- void Set_F81846_Reg( unsigned char REG, unsigned char DATA) Unlock_F81846(); outportb(F81846_INDEX_PORT, REG); outportb(F81846_DATA_PORT, DATA); Lock_F81846(); //--------------------------------------------------------------------------- unsigned char Get_F81846_Reg(unsigned char REG) unsigned char Result; Unlock_F81846();...
Page 94 F81846_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81846_UNLOCK 0x87 #define F81846_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81846(void); void Set_F81846_LD( unsigned char); void Set_F81846_Reg( unsigned char, unsigned char); unsigned char Get_F81846_Reg( unsigned char); //--------------------------------------------------------------------------- #endif //__F81846_H Copyright © 2016 IBASE Technology Inc. All Rights Reserved.
