Setting Up

ENC 1202 Panels

3 Setting Up
3.1 ENC 1202 Panels
Front Panel
1 8 XLR connectors—Line Outputs 1~8
Rear Panel
[2]
2 PRIMARY Dante port
3 SECONDARY Dante port
4 RJ45 port (Line In 1~4)
5 Cooling fan. Never obstruct this area.
6 POWER 1 connector
7 POWER 2 connector
8 Grounding screw
ENC 1202
[1]
[3] [4] [5]
Version 1.0
[6] [7] [8]
