Configuring the Unit via its Web Interface
Routing
Status
Shows the connection status:
NONE
DYNAMIC
SUBSCRIBE SELF
MANUAL
STATIC
NO TX
UNRESOLVED
Flow
To maximize the efficiency of the network, Dante bundles groups of 4 individual connec-
tions into so-called "flows". This behavior can be changed with "Dante Channels Per Flow"
(p. 25).
This item displays information about the flow to which this channel belongs. The informa-
tion is displayed as follows: {flow-id} ({samplingrate}/{encoding})
Example: 1 (48000/PCM32).
ENC 1202
This input on the ENC 1202 is not connected to any Dante output. No
subscription available.
This input is connected and in use. "Dynamic" is the default setting for
point-to-point subscriptions.
This input is connected to one of the ENC 1202's outputs.
A manually configured flow—indicates an AES67 subscription.
A static configured flow—indicates a multicast-flow subscription.
The TX (transmitting) channel on the external device is not active.
The selected transmitting device is not visible on the network (it may
have been removed or turned off).
