Configuring the Unit via its Web Interface
Status
DEVICE INFO
The "Device Info" section lists basic information about the ENC 1202.
Device Name
Dante Redundancy
Dante Preferred Master Clock
Uptime
Temperature Power Supply
Temperature CPU
VERSIONS
The "Versions" section lists the software, firmware and hardware versions.
Dante Model ID
Dante Software
Dante Firmware
ENCHORUS Software
ENCHORUS Firmware
ENC 1202
Shows the device's name.
The ENC 1202's two LAN ports can be used in Switched or
Redundant mode. This can be selected using "Dante Redun-
dancy after Reboot" (p. 24).
You can define the ENC 1202 as preferred Master Clock
source (ON) or turn off this setting (OFF). This can be
selected using the "Dante Preferred Master Clock" (p. 24)
parameter.
Indicates for how long the unit has been running without
interruption.
Indicates the temperature of the power supply.
Indicates the temperature of the central processing unit.
The ENC 1202's model ID is "105".
The Brooklyn II module's firmware version. This module provides
a complete Dante interface with up to 64 channels. See Audinate's
website (www.audinate.com/products/manufacturer-products/
dante-brooklyn-ii).
The field-programmable gate array's (FPGA) firmware version.
The installed software version.
The installed firmware version.
Version 1.0
