3.4 Application Examples
Use as Press Box
One or several ENC 1202 units can be used to set up a scalable audio distribution system
for the press: one of the 4 line inputs of the first unit serves as input that feeds the 8 Line
Outs.
The RX Dante 01 input of the second and subsequent ENC 1202 units is also patched to
the respective 8 line outputs.
Tip: To save time when using multiple units, configure the second ENC 1202, save its set-
tings, use "Download Config" on page 16, and then "Restore Config" on page 16
to "copy" those settings to the third, fourth, etc., ENC 1202 units.
Dante
TX
Expandable
Fixed Installation and Power Amp Rack
The Enchorus ENC 1202 provides a Delay function for each of the 8 line outputs, with a
delay time of up to 2.7 seconds. So does the ENC 1101 (for its AES3 outputs). This can be
used to correct timing differences just before the power amplifiers, without the need for
an additional delay line controller, etc. For fixed installations, this is probably the easiest
way to create a speaker matrix.
Mixer
L
1
D D
e e
l l
a a
y y
1 2 3 4 5 6 7 8
8x Line Outs
L R
Recording
The Enchorus ENC 1202 acts as matrix and ENC 1101 as signal distributor for the power
amp rack. If the power amplifiers only have analog inputs, a second ENC 1202 can be
used instead of the ENC 1101.
ENC 1202
ENC 1202
Dante
RX
R
2 3 4
Mixer
D D D
e e e
l l l
a a a
y y y
1 2
Side
Fill
Dante TX
L R
Rear
Fill
Version 1.0
ENC 1202
Dante
TX
RX
Dante RX
1 2
1 2
D D D
e e e
l l l
a a a
y y y
1 2 3 4 5 6 7 8
L R
PA far
L R
PA near
ENC 1202
Mixer Out
(audio signal
for the press)
TX
Power amp rack
3 4
Mixer
D
e
l
a
y
Page 13
