Dacor EDWH24S Installation Instructions

DISHWASHER MODELS: EDWH24S, IDWH24, RDW24I and RDW24S
Introduction
The handle included with this kit is designed for installation on the dishwasher models listed
above:
•
On models EDWH24S and RDW24S, the handle attaches directly to the front of
dishwasher using mounting hardware that is already attached to the front of the
dishwasher.
•
On models IDWH24 and RDW24I, the included handle is designed to attach to glass
panel kits APIDWPBK or APIDWPMV that fit on the front of the dishwasher door. The
handle mounting hardware for this type of installation is included with the glass panel kit.

Tools and Materials Required

The following items are not provided with the
kit and are required for proper installation.
•
3/32" Allen wrench (not supplied)
Parts Included
Epicure Style Handle Kits
ADWE24HCH (chrome):
Handle Part # 106909
ADWE24HB (black gloss):
Handle Part # 106909BG
Epicure and Millennia
®
Handle Kits
CAUTION: To avoid damage to the dishwasher or handle
components, do not use power tools. Use hand tools
only for assembly.
Installation instructions on back
Style
®
Millennia Style Handle Kits
ADWM24H* (Polished finish):
Handle Part # 106908
ARDWM24H (Brushed finish):
Handle Part # 105784
* ADWM24H discontinued - subject to availability
INSTALLATION
INSTRUCTIONS
Part No. 106906 Rev. E
