2 Spectrometer Overview

The OIW-EX Series fitted with a Spectrometer enhances the functionality of the standard unit
by incorporating an optical spectrum analyser unit which allows for enhanced analyses of the
produced water in the sample chamber.
The following OIW-EX Series models all have Spectrometer fitted as standard:
• OIW-EX1000,
• OIW-EX1000P and
• OIW-EX4000.
Advanced Sensors software suite includes SpAn. The SpAn software tool simplifies the
analysis of multiple optical scans.
As with all data logs generated by the OIW-EX Series of products the spectrum analyser files
are created in generates industry standard .csv file format allowing the user the flexibility to
analyse the data in a tool of their choosing.
The following sections will detail the operation of the spectrum analyser unit and will provide
details on how to use the SpAn software – details will also be provided on the file format
should the use wish to analyse the data with alternative tools.
