Timer Controls/Features - Orbit B-Hyve User Manual

Timer Controls/Features

Your timer was built to make installation
easy and fast, while providing convenient
controls to make adjustments directly
when you're standing in front of the timer,
or from anywhere in the world with the
B-hyve™ app .
Lock and Latch
A
Weather Resistant
B
Cover
Dial
C
Digital Display
D
Swing Door Panel
E
Battery
F
Compartment
Transformer
G
Wiring Terminals
H
Reset Button
I
Line Cord
J
10
B
A
I
E
F
D
E
C
G
J
H
