Vega VEGAPULS 69 Operating Instructions Manual

Radar sensor for continuous level measurement of bulk solids
Hide thumbs Also See for VEGAPULS 69:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Instructions Manual

Operating Instructions

Radar sensor for continuous level
measurement of bulk solids
VEGAPULS 69
Foundation Fieldbus
Document ID: 47251

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGAPULS 69 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vega VEGAPULS 69

Summary of Contents for Vega VEGAPULS 69

  • Page 1: Operating Instructions

    Operating Instructions Radar sensor for continuous level measurement of bulk solids VEGAPULS 69 Foundation Fieldbus Document ID: 47251...

  • Page 2: Table Of Contents

    Parameter adjustment ....................40 Saving the parameterisation data ................... 52 Setup with PACTware ......................53 Connect the PC ......................53 Parameter adjustment ....................53 Saving the parameterisation data ................... 54 Set up with other systems ....................55 VEGAPULS 69 • Foundation Fieldbus...
  • Page 3 11.5 Industrial property rights ....................98 11.6 Trademark ........................98 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions manual. Editing status: 2018-06-25 VEGAPULS 69 • Foundation Fieldbus...

  • Page 4: About This Document

    Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, tip, note This symbol indicates helpful additional information.

  • Page 5: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS 69 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Eu Conformity

    • When installed within 4 to 40 km of a radio astronomy station, the instrument must not be mounted higher than 15 m above the ground. VEGAPULS 69 • Foundation Fieldbus...

  • Page 7: Radio License For Usa

    This device is limited to installation in a completely enclosed container made of metal or concrete to prevent RF emissions, which can otherwise interfere with aeronautical navigation, the maximum approved tilt angel is 10°. From electronics index .-03 VEGAPULS 69 • Foundation Fieldbus...
  • Page 8 émissions RF susceptibles d'interférer avec la navigation aéronautique. L'angle d'inclinaison maximum autorisé est de 10°. De l'indice électronique .-03, l'utilisation dans des conteneurs fabriqués en fibre de verre est également permise. VEGAPULS 69 • Foundation Fieldbus...

  • Page 9: Installation And Operation In The Usa And Canada

    Canadian Electrical Code. 2.11 Environmental instructions Protection of the environment is one of our most important duties. That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- VEGAPULS 69 • Foundation Fieldbus...
  • Page 10 2 For your safety tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 69 • Foundation Fieldbus...

  • Page 11: Product Description

    Go to "www.vega.com", "Instrument search (serial number)". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" VEGAPULS 69 • Foundation Fieldbus...

  • Page 12: Principle Of Operation

    Principle of operation Application area The VEGAPULS 69 is a radar sensor for continuous level measure- ment of bulk solids under different process conditions. It is ideal for level measurement in very high silos, large bunkers and segmented vessels. The very good signal focussing ensures a simple setup and reliable measurement.

  • Page 13: Packaging, Transport And Storage

    PLICSCOM The display and adjustment module PLICSCOM is used for measured value indication, adjustment and diagnosis. It can be inserted into the sensor or the external display and adjustment unit and removed at any time. VEGAPULS 69 • Foundation Fieldbus...
  • Page 14 PACTware with VEGA-DTM is required. You can find further information in the operating instructions "Interface adapter VEGACONNECT" (Document-ID 32628). VEGADIS 81 The VEGADIS 81 is an external display and adjustment unit for VEGA plics sensors. ® For sensors with double chamber housing the interface adapter "VEGADIS adapter"...
  • Page 15 VEGAPULS series 60" (Document-ID 36801). Supplementary elec- The supplementary electronics is a replacement part for sensors with tronics for Foundation Foundation Fieldbus and double chamber housing. Fieldbus You can find further information in the operating instructions "Supple- mentary electronics for Foundation Fieldbus" (Document-ID 45111). VEGAPULS 69 • Foundation Fieldbus...

  • Page 16: Mounting

    Mounting strap The optional mounting strap allows simple mounting of the instrument on a wall, ceiling or boom. Especially in the case of open vessels, this is a simple and effective way to align the sensor to the surface of the bulk solid material. The following versions are available: VEGAPULS 69 • Foundation Fieldbus...
  • Page 17 This allows swivelling the sensor up to 180° for optimal orientation and rotating for optimal connection. Fig. 3: Ceiling mounting via the mounting strap with length 300 mm Mounting strap - Wall As an alternative the strap mounting is carried out horizontally or mounting obliquely. > 200 mm (7.87") Fig. 4: Wall mounting horizontally via the mounting strap with length 170 mm VEGAPULS 69 • Foundation Fieldbus...
  • Page 18 DN 80, ASME 3" and JIS 80. It comes not sealed against the radar sensor and can thus only be used unpressurized. It can be retrofitted on instruments with single chamber housing, retrofitting to a double chamber housing is not possible. Fig. 6: Combi compression flange 1 Combi compression flange Adapter flange The adapter flange is available from DN 100, ASME 4" and JIS 100. It is permanently connected with the radar sensor and sealed. VEGAPULS 69 • Foundation Fieldbus...

  • Page 19: Mounting Preparations, Mounting Strap

    Depending on the selected variant, the sensor can be rotated in the strap: • Single chamber housing – Angle of inclination in three steps 0°, 90° and 180° – Angle of inclination 180°, infinitely variable • Double chamber housing – Angle of inclination in two steps 0° and 90° – Angle of inclination 90°, infinitely variable VEGAPULS 69 • Foundation Fieldbus...

  • Page 20: Mounting Instructions

    In such cases, we recommend repeating the false signal suppression at a later date with existing buildup. Inflowing medium The instrument should not be mounted too close to the inflowing medium, as the radar signal could be disrupted. Silo with filling from top The optimal mounting position is opposite the filling aperture. To avoid heavy soiling, the distance to any filter or dust exhauster should be as large as possible. VEGAPULS 69 • Foundation Fieldbus...
  • Page 21 4 Mounting Fig. 11: Mounting of the radar sensor with inflowing medium Silo with lateral filling In bulk solids silos with lateral pneumatic filling the instrument should not be mounted above the filling stream, as the radar signal will be disrupted. The optimal mounting position is to the side of the filling aperture. To avoid heavy soiling, the distance to any filter or dust exhauster should be as large as possible. VEGAPULS 69 • Foundation Fieldbus...
  • Page 22 For socket mounting, the socket should be as short as possible and its end rounded. This reduces false reflections from the socket. With threaded connection, the antenna end should protrude at least 5 mm (0.2 in) out of the socket. Fig. 13: Recommended socket mounting with different versions of VEGAPULS Metal-jacketed lens antenna Plastic horn antenna Thread with integrated horn antenna VEGAPULS 69 • Foundation Fieldbus...
  • Page 23 4 Mounting If the reflective properties of the medium are good, you can mount VEGAPULS 69 on sockets longer than the antenna. The socket end should be smooth and burr-free, if possible also rounded. Note: When mounting on longer sockets, we recommend carrying out a false signal suppression (see chapter "Parameter adjustment").
  • Page 24 With the help of an optional swivelling holder, the sensor can be easily aligned to the vessel centre. The necessary angle of inclination depends on the vessel dimensions. It can be easily checked with a suitable bubble tube or mechanic's level on the sensor. VEGAPULS 69 • Foundation Fieldbus...
  • Page 25 4 Mounting Fig. 16: Proposal for installation after orientation VEGAPULS 69 The following table shows the necessary angle of inclination. It depends on the measuring distance and the distance "a" between vessel centre and installation position. Distance d 2° 4°...
  • Page 26 Proceed as follows to adjust the angle of inclination with the swivelling holder: 1. Loosen the terminal screws of the swivel holder by one turn. Use a hexagon socket wrench, size 5. Fig. 17: VEGAPULS 69 with swivelling holder Terminal screws (6 pcs.) 2. Align the sensor, check angle of inclination Note: The max.
  • Page 27 4 Mounting Fig. 18: VEGAPULS 69 with swivelling holder on tall, slender sockets Vessel installations The mounting location of the radar sensor should be a place where no other equipment or fixtures cross the path of the radar signals. Vessel installations, such as e.g. ladders, limit switches, heating spi- rals, struts, etc., can cause false echoes and impair the useful echo.
  • Page 28 Electronics housing Spacer Vessel insulation Mounting in multiple The walls of multiple-chamber silos are often made of profile material, chamber silo e.g. profile sheeting, to ensure the required stability. If the radar sen- sor is mounted very close to a heavily structured vessel wall, substan- tial interfering reflections can be generated. Thus the sensor should be mounted at the largest possible distance from the separating wall. VEGAPULS 69 • Foundation Fieldbus...
  • Page 29 To protect the sensor against buildup, particularly in case of strong condensation, air rinsing is recommended. Metal-jacketed lens antenna The VEGAPULS 69 with metal-jacketed lens antenna is equipped with a rinsing air connection as a standard feature, see following graphics.
  • Page 30 4 Mounting Fig. 24: Rinsing air connection on metal-jacketed lens antenna Plastic horn antenna The VEGAPULS 69 with plastic horn antenna is optionally available with a rinsing air connection. The mechanical configuration differs according to the flange version, see following graphics. Fig. 25: Rinsing air connection with compression flange Fig. 26: Rinsing air connection with adapter flange You can find details on the rinsing air connection in chapter "Technical data". VEGAPULS 69 • Foundation Fieldbus...

  • Page 31: Connecting To The Bus System

    Max. torque for all housings, see chapter "Technical data". Cable screening and Make sure that the cable screen and grounding are carried out ac- grounding cording to Fieldbus specification. We recommend to connect the cable screening to ground potential on both ends. VEGAPULS 69 • Foundation Fieldbus...

  • Page 32: Connecting

    6. Insert the wire ends into the terminals according to the wiring plan Information: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver, the terminal opening is then free. When the screwdriver is released, the terminal closes again. VEGAPULS 69 • Foundation Fieldbus...

  • Page 33: Wiring Plan, Single Chamber Housing

    Fig. 28: Electronics and terminal compartment - single chamber housing Voltage supply, signal output 2 Contact pins for the display and adjustment module or interface adapter Simulation switch ("1" = mode for simulation release) For external display and adjustment unit Ground terminal for connection of the cable screen VEGAPULS 69 • Foundation Fieldbus...

  • Page 34: Wiring Plan, Double Chamber Housing

    For external display and adjustment unit Ground terminal for connection of the cable screen Information: Parallel use of an external display and adjustment unit and a display and adjustment module in the terminal compartment is not supported. VEGAPULS 69 • Foundation Fieldbus...

  • Page 35: Double Chamber Housing With Vegadis-Adapter

    Pin 3 Blue Pin 4 Black Switch-on phase After VEGAPULS 69 is connected to the bus system, the instrument carries out a self-test for approx. 30 seconds. The following steps are carried out: • Internal check of the electronics •...
  • Page 36 5 Connecting to the bus system Then the actual measured value is outputted to the signal cable. The value takes into account settings that have already been carried out, e.g. default setting. VEGAPULS 69 • Foundation Fieldbus...

  • Page 37: Set Up With The Display And Adjustment Module

    The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 33: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing VEGAPULS 69 • Foundation Fieldbus...

  • Page 38: Adjustment System

    1 LC display Adjustment keys • Key functions [OK] key: – Move to the menu overview – Confirm selected menu – Edit parameter – Save value • [->] key: – Change measured value presentation – Select list entry VEGAPULS 69 • Foundation Fieldbus...

  • Page 39: Measured Value Indication - Selection Of National Language

    Approx. 60 minutes after the last pressing of a key, an automatic reset to measured value indication is triggered. Any values not confirmed with [OK] will not be saved. Measured value indication - Selection of national language Measured value indica- With the [->] key you move between three different indication modes. tion VEGAPULS 69 • Foundation Fieldbus...

  • Page 40: Parameter Adjustment - Quick Setup

    You can find "Extended adjustment" in the next sub-chapter. Parameter adjustment The instrument is adapted to the application conditions via the pa- rameter adjustment. The parameter adjustment is carried out with an adjustment menu. Main menu The main menu is divided into five sections with the following func- tions: VEGAPULS 69 • Foundation Fieldbus...
  • Page 41 Depending on the type of bulk solids application, material cones and additional echoes from the vessel wall or bottom can become further interfering factors. Through this selection, the sensor is adapted perfectly to the application. VEGAPULS 69 • Foundation Fieldbus...
  • Page 42 6 Set up with the display and adjustment module Vessel height/Measuring range: The VEGAPULS 69 is a bulk solids radar sensor for high, slender vessels. It covers a measuring range up to 120 m. This menu item lets you limit the active measuring range in which the instrument searches for level echoes.
  • Page 43 Since the radar sensor is a distance measuring instrument, the distance from the sensor to the product surface is measured. To indicate the actual level, an allocation of the measured distance to the percentage height must be carried out. VEGAPULS 69 • Foundation Fieldbus...
  • Page 44 2. Prepare the percentage value for editing with [OK] and set the cursor to the requested position with [->]. 3. Set the requested percentage value with [+] and save with [OK]. The cursor jumps now to the distance value. VEGAPULS 69 • Foundation Fieldbus...
  • Page 45 The default setting is a damping of 0 s. Lock/unlock setup - Ad- In the menu item "Lock/unlock adjustment" you safeguard the sensor justment parameters against unauthorized or unintentional modifications. With active PIN, only the following adjustment functions are possible without entering a PIN: VEGAPULS 69 • Foundation Fieldbus...
  • Page 46 • Polish • Czech • Turkish In the delivery status, the VEGAPULS 69 is set to the ordered national language. In the menu item "Display" you can define which measured value Display - Displayed val- ues 1 and 2 should be presented on the display. The sensor delivers the following measured values: •...
  • Page 47 In this menu item you can simulate measured values via the current Diagnosis - Simulation output. This allows the signal path to be tested, e.g. through down- stream indicating instruments or the input card of the control system. VEGAPULS 69 • Foundation Fieldbus...
  • Page 48 In this menu item, the internal clock of the sensor is set to the request- Time ed time and time format. At the time of shipment from factory, the instrument is set to CET (Central European Time). VEGAPULS 69 • Foundation Fieldbus...
  • Page 49 Order-related settings are not taken over into the current parameters after this reset. The following table shows the scope of the reset function and the default values of the instrument: VEGAPULS 69 • Foundation Fieldbus...
  • Page 50 If the data do not match, a fault message is outputted or the function is blocked. The data are saved only after release. Additional settings - Lin- A linearization is necessary for all vessels in which the vessel volume earization does not increase linearly with the level - e.g. a horizontal cylindri- VEGAPULS 69 • Foundation Fieldbus...
  • Page 51 Change the settings of the special parameters only after having con- tacted our service staff. Info In this menu item the following information of the instrument can be read out: • Instrument name and serial number • Hardware and software version VEGAPULS 69 • Foundation Fieldbus...

  • Page 52: Saving The Parameterisation Data

    In the display and adjust- If the instrument is equipped with a display and adjustment module, ment module the parameter adjustment data can be saved therein. The procedure is described in menu item "Copy device settings". VEGAPULS 69 • Foundation Fieldbus...

  • Page 53: Setup With Pactware

    Further setup steps are described in the operating instructions manu- al "DTM Collection/PACTware" attached to each DTM Collection and which can also be downloaded from the Internet. Detailed descrip- tions are available in the online help of PACTware and the DTMs. VEGAPULS 69 • Foundation Fieldbus...

  • Page 54: Saving The Parameterisation Data

    The standard version is available as a download under www.vega.com/downloads and "Software". The full version is avail- able on CD from the agency serving you. Saving the parameterisation data We recommend documenting or saving the parameterisation data via PACTware.

  • Page 55: Set Up With Other Systems

    This software is updated via the Internet and new EDDs are automatically accepted into the device catalogue of this software after they are released by the manufacturer. They can then be transferred to a Field Communicator. VEGAPULS 69 • Foundation Fieldbus...

  • Page 56: Diagnosis, Asset Management And Service

    (non-deletable). Each entry contains date/time, event type, event description and value. Event types are for example: • Modification of a parameter • Switch-on and switch-off times • Status messages (according to NE 107) • Error messages (according to NE 107) VEGAPULS 69 • Foundation Fieldbus...

  • Page 57: Asset Management Function

    Failure: Due to a malfunction in the instrument, a fault message is outputted. This status message is always active. It cannot be deactivated by the user. Function check: The instrument is being worked on, the measured value is temporarily invalid (for example during simulation). VEGAPULS 69 • Foundation Fieldbus...
  • Page 58 Communication • Send instrument for repair error • • F125 Temperature of the electronics Check ambient temperature Bit 7 • in the non-specified range Insulate electronics Impermissible elec- • Use instrument with higher tronics temperature temperature range VEGAPULS 69 • Foundation Fieldbus...
  • Page 59 Text message Diagnosis Bits • • M500 The data could not be restored Repeat reset Bit 15 • during the reset to delivery Load XML file with sensor data Error during the re- status into the sensor set "delivery status" VEGAPULS 69 • Foundation Fieldbus...

  • Page 60: Rectify Faults

    PACTware and the suitable DTM. In many cases, the reasons can be determined in this way and faults rectified. Treatment of measure- The below tables show typical examples of application-related ment errors with bulk measurement errors with bulk solids. A distinction is made between solids measurement errors during: • Constant level VEGAPULS 69 • Foundation Fieldbus...
  • Page 61 Amplitude or position of a false signal has Determine the reason for the changed changed (e.g. condensation, buildup); false signals, carry out false signal sup- false signal suppression no longer pression, e.g. with condensation time matches actual conditions VEGAPULS 69 • Foundation Fieldbus...
  • Page 62 Carry out false signal suppression or jumps sporadically on the antenna increase false signal suppression in the towards 100 % dur- close range by editing • ing emptying With bulk solids use radar sensor with purging air connection or flexible antenna cover time VEGAPULS 69 • Foundation Fieldbus...

  • Page 63: Exchanging The Electronics Module

    24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock.

  • Page 64: Software Update

    You can find an instrument return form as well as detailed informa- tion about the procedure in the download area of our homepage: www.vega.com. By doing this you help us carry out the repair quickly and without having to call back for needed information. In case of repair, proceed as follows: •...

  • Page 65: Dismount

    Pass the instrument directly on to a spe- cialised recycling company and do not use the municipal collecting points. These may be used only for privately used products according to the WEEE directive. VEGAPULS 69 • Foundation Fieldbus...

  • Page 66: Supplement

    Ʋ Adapter flange PP-GF30 black Ʋ Seal, adapter flange FKM (COG VI500), EPDM (COG AP310) Ʋ Focussing lense Thread with integrated antenna Ʋ Process fitting 316L Ʋ Antenna PEEK Ʋ Seal, antenna system FKM, FFKM Ʋ Process seal Klingersil C-4400 VEGAPULS 69 • Foundation Fieldbus...
  • Page 67 2 … 17.2 kg (4.409 … 37.92 lbs) process fitting and antenna) Input variable Measured variable The measured quantity is the distance between the end of the sensor antenna and the product surface. The reference plane for the measurement is the lower side of the flange. VEGAPULS 69 • Foundation Fieldbus...
  • Page 68 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig) Installation reference conditions Ʋ Min. distance to internal installations > 200 mm (7.874 in) Ʋ Reflector Flat plate reflector, surface 1 x 1 m (3.281 x 3.281 ft) Ʋ False reflections Biggest false signal, 20 dB smaller than the useful signal VEGAPULS 69 • Foundation Fieldbus...
  • Page 69 Ʋ Plastic horn antenna 3.5° Ʋ Metal-jacketed lens antenna 4° Already included in the meas. deviation Depending of the reflective properties of the measured media. Time span (after a sudden measuring distance change of max. 2 m in bulk solids applications) until the output signal has taken on 90 % of the final value for the first time (IEC 61298-2). Outside the specified beam angle, the energy level of the radar signal is 50% (-3 dB) less. VEGAPULS 69 • Foundation Fieldbus...
  • Page 70 -40 … +130 °C (-40 … +266 °F) FKM (SHS FPM 70C3 -40 … +80 °C (-40 … +176 °F) GLT) EPDM (COG AP310) -40 … +80 °C (-40 … +176 °F) Derating, ambient temperature EIRP: Equivalent Isotropic Radiated Power VEGAPULS 69 • Foundation Fieldbus...
  • Page 71 0°C / 32°F -40°C 50°C 80°C 100°C 150°C 200°C -40°F 122°F 176°F 212°F 302°F 392°F -40°C / -40°F Fig. 53: Derating, ambient temperature, metal-jacketed lens antenna up to +200 °C (+392 °F) Ambient temperature Process temperature Aluminium housing Plastic housing Stainless steel housing (precision casting) Stainless steel housing (electropolished) VEGAPULS 69 • Foundation Fieldbus...
  • Page 72 42°C / 108°F 0°C / 32°F -40°C 50°C 80°C 100°C 130°C -40°F 122°F 176°F 212°F 266°F -40°C / -40°F Fig. 55: Derating, ambient temperature, thread G1½ with integrated horn antenna up to +130 °C (+266 °F) Ambient temperature Process temperature Aluminium housing Plastic housing Stainless steel housing (precision casting) Stainless steel housing (electropolished) VEGAPULS 69 • Foundation Fieldbus...
  • Page 73 Vibration resistance: thread with inte- 4 g at 5 … 200 Hz according to EN 60068-2-6 (vibration grated horn antenna with resonance) Shock resistance 100 g, 6 ms according to EN 60068-2-27 (mechanical shock) Data on rinsing air connection Recommended max. pressure with con- 1 bar (14.50 psig) tinuous rinsing VEGAPULS 69 • Foundation Fieldbus...
  • Page 74 Ʋ Seal with metal jacketed lens antenna Threaded plug of 316Ti Reflux valve (optional, is absolutely necessary for Ex applications) Ʋ Material 316Ti Ʋ Thread G⅛ Ʋ Seal FKM (SHS FPM 70C3 GLT), EPDM (COG AP310) Ʋ For connection G⅛ Ʋ Opening pressure 0.5 bar (7.25 psig) Ʋ Nominal pressure stage PN 250 VEGAPULS 69 • Foundation Fieldbus...
  • Page 75 Ʋ Colour - Non-Ex version Black Ʋ Colour - Ex-version Blue Display and adjustment module Display element Display with backlight Measured value indication Ʋ Number of digits Adjustment elements Ʋ 4 keys [OK], [->], [+], [ESC] Ʋ Switch Bluetooth On/Off VEGAPULS 69 • Foundation Fieldbus...
  • Page 76 -40 … +85 °C (-40 … +185 °F) Resolution < 0.1 K Accuracy ±3 K Voltage supply Operating voltage Ʋ Non-Ex instrument 9 … 32 V DC Ʋ Ex-ia instrument - Power supply 9 … 17.5 V DC FISCO model VEGAPULS 69 • Foundation Fieldbus...

  • Page 77: Radio Astronomy Stations

    (serial number)" as well as in the download area. 11.2 Radio astronomy stations Certain restrictions on the use of VEGAPULS 69 outside closed vessels result from the radio license. You can find these restrictions in chapter "Radio license for Europe". Some of these restric- tions have to do radio astronomy stations. The following table states the geographic positions of...

  • Page 78: Supplementary Information Foundation Fieldbus

    Output Amplitude 0.8 V P-P Electrical Connection 2 Wire Polarity Insensitive Max. Current Load 10 mA Device minimum operating voltage Transmitter Function Blocks Resource Block (RB) Transducer Block (TB) Standard Block (AI) Execution Time 30 mS VEGAPULS 69 • Foundation Fieldbus...
  • Page 79 Fig. 57: Schematic presentation Transducer Block (TB) Function block Analog Input (AI) The function block "Analog Input (AI)" takes the original measured value selected by a Channel Number and makes it available to additional function blocks on its output. VEGAPULS 69 • Foundation Fieldbus...
  • Page 80 Fig. 59: Schematic presentation function block Discret Input (DI) Function block PID Control The function block "PID Control " is a key component for various tasks in the process automation and is used universally. PID blocks can be cascaded if this is necessary or requested due to differ- ent time constants with the primary and secondary process measurement. Fig. 60: Schematic presentation function block PID Control VEGAPULS 69 • Foundation Fieldbus...
  • Page 81 The function block "Integrator" integrates a continuous input signal over the time and sums the results of an impulse input block. It is used as a totalizer up to a reset or as a subtotalizer up to a reference point at which the integrated and accumulated value is compared with the default values. When these default values are reached, digital output signals will be outputted. The integration func- tion is carried out upwardly starting with zero and downwards with a default value. Two flow values are also available so that the net flow volume can be calculated and integrated. This can be used for calculation of volume and mass changes in the vessel or for optimisation of flow controls. VEGAPULS 69 • Foundation Fieldbus...
  • Page 82 The function block "Arithmetic" allows the simple integration of usual metrological calculation func- tions. The user can select the requested measurement algortihm according to the name without known the formula. The following algorithms are available: • Flow compensation, linear • Flow compensation, square root VEGAPULS 69 • Foundation Fieldbus...
  • Page 83 Selected unit code for "SECONDARY_VALUE_1" UNIT SECONDARY_VALUE_2 This is the distance value ("sensor_value") with the status of the transducer block. The unit is defined in "SECONDARY_VAL- UE_2_UNIT" FILL_HEIGHT_VALUE Filling height. The unit is defined in "FILL_HEIGHT_VALUE_ UNIT" FILL_HEIGHT_VALUE_UNIT Filling height unit CONST_VALUE Constant value SECONDARY_VALUE_1_ Secondary value 1 type TYPE VEGAPULS 69 • Foundation Fieldbus...
  • Page 84 0 % and 100 % curve in near and far range FALSE_SIGNAL_CMD_CON- Gradient of the manual sectors, safety at the end of false echo FIGURATION2 memory and depending on the import range gating out the false signals VEGAPULS 69 • Foundation Fieldbus...
  • Page 85 Min.-/max.- values of electronics temperature, date USER_MIN_MAX_PHYSI- Min.-/max.- distance values, date CAL_VALUE RESET_PEAK_PHYSICAL_ VALUE RESET_LINEARIZATION_ CURVE DEVICE_STATUS_ASCII Device status ECHO_CURVE_PLICSCOM_ Parameters as curve selection and resolution REQUEST ECHO_CURVE_PLICSCOM_ Parameters as start and end LIMITS APPROVAL_WHG Sensor acc. to WHG VEGAPULS 69 • Foundation Fieldbus...

  • Page 86: Dimensions

    TYPE ECHO_MEM_STATE Busy, curve type, error code 11.4 Dimensions The following dimensional drawings represent only an extract of all possible versions. Detailed dimensional drawings can be downloaded at www.vega.com/downloads under "Drawings". Plastic housing ~ 69 mm ~ 84 mm (2.72") (3.31")
  • Page 87 ½ NPT Fig. 68: Housing version with protection rating IP 66/IP 68 (1 bar) - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Aluminium - single chamber Aluminium - double chamber VEGAPULS 69 • Foundation Fieldbus...
  • Page 88 Fig. 70: Housing version with protection rating IP 66/IP 68 (1 bar) - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Stainless steel single chamber (electropolished) Stainless steel single chamber (precision casting) Stainless steel double chamber housing (precision casting) VEGAPULS 69 • Foundation Fieldbus...
  • Page 89 VEGAPULS 69, metal-jacketed lens antenna with rinsing connection 43 mm (1.69") 35 mm (1.38") 43 mm (1.69") 35 mm (1.38") Fig. 72: VEGAPULS 69, metal-jacketed lens antenna with rinsing connection Version up to 130 °C (266 °F) Version up to 200 °C (392 °F) Blind plug 90° angle joint Reflux valve VEGAPULS 69 • Foundation Fieldbus...
  • Page 90 11 Supplement VEGAPULS 69, metal-jacketed lens antenna with swivelling holder Fig. 73: VEGAPULS 69, metal-jacketed lens antenna and swivelling holder Version up to 130 °C (266 °F) Version up to 200 °C (392 °F) VEGAPULS 69 • Foundation Fieldbus...
  • Page 91 11 Supplement VEGAPULS 69, metal-jacketed lens antenna with swivelling holder and rinsing connection Fig. 74: VEGAPULS 69, metal-jacketed lens antenna with swivelling holder and rinsing connection Version up to 130 °C (266 °F) Version up to 200 °C (392 °F) Blind plug 90° angle joint Reflux valve VEGAPULS 69 • Foundation Fieldbus...
  • Page 92 11 Supplement VEGAPULS 69, plastic horn antenna with compression flange ø 107 mm ø 21 mm (4.21") (0.83") ø 75 mm (2.95") ø 115 mm (4.53") ø 156 mm (6.14") ø 200 mm (7.87") Fig. 75: VEGAPULS 69 with compression flange suitable for flanges 3" 150 lbs, DN 80 PN 16 Compression flange VEGAPULS 69 • Foundation Fieldbus...
  • Page 93 11 Supplement VEGAPULS 69, plastic horn antenna with compression flange and rinsing connection ø 107 mm ø 21 mm (4.21") (0.83") ø 75 mm (2.95") ø 156 mm (6.14") ø 200 mm (7.87") Fig. 76: VEGAPULS 69 with compression flange suitable for flanges 3" 150 lbs, DN 80 PN 16 and rinsing connec- tion Compression flange Reflux valve Rinsing connection VEGAPULS 69 • Foundation Fieldbus...
  • Page 94 11 Supplement VEGAPULS 69, plastic horn antenna with adapter flange ø 75 mm (2.95") ø 98 mm (3.86") ø 180 mm (7.09") ø 220 mm (8.66") Fig. 77: VEGAPULS 69 with adapter flange DN 100 PN 16 Adapter flange Process seal VEGAPULS 69 • Foundation Fieldbus...
  • Page 95 11 Supplement VEGAPULS 69, plastic horn antenna mit adapter flange und rinsing connection ø 75 mm (2.95") ø 98 mm (3.86") ø 180 mm (7.09") ø 220 mm (8.66") Fig. 78: VEGAPULS 69, adapter flange DN 100 PN 16 and rinsing connection Rinsing air connection Reflux valve Adapter flange VEGAPULS 69 • Foundation Fieldbus...
  • Page 96 2,5 mm (0.10") ø 75 mm 9 mm (2.95") (0.35") ø 107 mm (4.21") ø 115 mm (4.53") 12 mm (0.47") Fig. 79: VEGAPULS 69, plastic horn antenna, mounting strap in 170 or 300 mm length VEGAPULS 69 • Foundation Fieldbus...
  • Page 97 11 Supplement VEGAPULS 69, thread with integrated horn antenna Fig. 80: VEGAPULS 69, thread with integrated horn antenna TC G1½ (DIN 3852-A) TD 1½ NPT (ASME B1.20.1) Version up to 130 °C (266 °F) Version up to 200 °C (392 °F) VEGAPULS 69 • Foundation Fieldbus...

  • Page 98: Industrial Property Rights

    Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com.
  • Page 99 Vessel insulation 28 – Integrator 81 – Output Splitter 81 – PID Control 80 – Signal Characterizer 81 – Transducer Block (TB) 79 Linearisation 51 Linearisation curve 50 Main menu 40 Measured value memory 56 Mounting – Flange 18 VEGAPULS 69 • Foundation Fieldbus...
  • Page 100 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2018 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
