Page 1: Operating Instructions
Operating Instructions Process assembly VEGAPULS 69 Document ID: 50714... -
Page 2: Table Of Contents
Disposal ......................... 12 Supplement Technical data ........................ 13 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions manual. Editing status: 2015-08-21 Process assembly • VEGAPULS 69... -
Page 3: About This Document
• List The dot set in front indicates a list with no implied sequence. → Action This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Process assembly • VEGAPULS 69... -
Page 4: For Your Safety
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" Process assembly • VEGAPULS 69... -
Page 5: Product Description
Dispose of the packaging material via specialised recycling companies. Transport Transport must be carried out in due consideration of the notes on the transport packaging. Nonobservance of these instructions can cause damage to the device. Process assembly • VEGAPULS 69... - Page 6 Protected against solar radiation • Avoiding mechanical shock and vibration • Storage and transport Storage and transport temperature see chapter "Supplement - temperature Technical data - Ambient conditions" • Relative humidity 20 … 85 % Process assembly • VEGAPULS 69...
-
Page 7: Mounting
2. Unscrew the lid of the electronics compartment 3. Disconnect the connection cables according to the operating instructions manual of the respective sensor 4. Loosen the two holding screws with the screwdriver (Torx size T 10 or slotted screwdriver size 4) Process assembly • VEGAPULS 69... - Page 8 Fig. 5: Position of the screws and locking ring on the example of the plastic housing Screw check angle Screw locking ring Retaining ring 2. Open the locking ring with the pliers and remove it 3. With Aluminium double chamber or stainless steel housing tighten the locking screw on the socket with a flat head screw- driver size 4 Process assembly • VEGAPULS 69...
-
Page 9: Mounting Steps New Process Component
7. Connect the connection cables according to the operating in- structions manual of the respective sensor 8. Screw the housing lid back on The process component exchange is finished. For Ex applications, the process component exchange must be docu- mented in general, internally. Process assembly • VEGAPULS 69... -
Page 10: Setup
5 Setup Setup Setup Setup is carried out according to the operating instructions manual of the respective sensor. Process assembly • VEGAPULS 69... -
Page 11: Maintenance
Clean the instrument and pack it damage-proof • Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Please contact the agency serving you to get the address for the return shipment. You can find the agency on our home page www.vega.com. Process assembly • VEGAPULS 69... -
Page 12: Dismount
WEEE directive. Correct disposal avoids negative effects on humans and the environ- ment and ensures recycling of useful raw materials. Materials: see chapter "Technical data" If you have no way to dispose of the replacement module properly, please contact us concerning return and disposal. Process assembly • VEGAPULS 69... -
Page 13: Supplement
8 Supplement Supplement Technical data Technical data are stated in the operating instructions manual of the respective sensor. Process assembly • VEGAPULS 69... -
Page 14: Process Assembly • Vegapuls
Notes Process assembly • VEGAPULS 69... - Page 15 Notes Process assembly • VEGAPULS 69...
- Page 16 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2015 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
