Quick setup guide
Radar sensor for continuous level
measurement of bulk solids
VEGAPULS 69
Modbus and Levelmaster protocol
Document ID: 47258

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGAPULS 69 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vega VEGAPULS 69

  • Page 1 Quick setup guide Radar sensor for continuous level measurement of bulk solids VEGAPULS 69 Modbus and Levelmaster protocol Document ID: 47258...
  • Page 2: Table Of Contents

    Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available on our homepage. Operating instructions VEGAPULS 69 - Modbus and Levelmas- ter protocol: Document-ID 47252 Editing status of the quick setup guide: 2020-04-21 VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 3: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use VEGAPULS 69 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.
  • Page 4: Eu Conformity

    When installed within 4 to 40 km of a radio astronomy station, the instrument must not be mounted higher than 15 m above the ground. A list of the respective radio astronomy stations can be found in chap- ter "Appendix" of the operating instructions. VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 5: Environmental Instructions

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 6: Product Description

    Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" • Scan the DataMatrix code on the type label of the instrument or •...
  • Page 7: Mounting

    – Angle of inclination in three steps 0°, 90° and 180° – Angle of inclination 180°, infinitely variable • Double chamber housing – Angle of inclination in two steps 0° and 90° – Angle of inclination 90°, infinitely variable Fig. 3: Adjustment of the angle of inclination VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 8: Mounting Instructions

    If you cannot maintain this distance, you should carry out a false signal suppression during setup. This applies particularly if buildup on the vessel wall is expected. In such cases, we recommend repeating the false signal suppression at a later date with existing buildup. VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 9: Connecting To Power Supply And Bus System

    5. Insert the wire ends into the terminals according to the wiring plan Information: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver, the terminal opening is then free. When the screwdriver is released, the terminal closes again. VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 10: Wiring Plan

    (sensor electronics) Connection compartment Electronics compartment Electronics compartment 4...20mA Fig. 9: Electronics compartment - double chamber housing Internal connection to the connection compartment For display and adjustment module or interface adapter VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 11 Fig. 10: Connection compartment USB interface 2 Slide switch for integrated termination resistor (120 Ω) Modbus signal Voltage supply Terminal Function Polarity Voltage supply Voltage supply Modbus signal D0 Modbus signal D1 Function ground when installing ac- cording to CSA (Canadian Standards Association) VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 12: Set Up The Sensor With The Display And Adjustment Module

    To quickly and easily adapt the sensor to the application, select the menu item "Quick setup" in the start graphic on the display and adjustment module. Carry out the following steps with the [->] key in the below sequence. VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 13 In this menu item you enter the height of the vessel and hence the active measuring range. 5. Max. adjustment In this menu item you carry out the max. adjustment. Enter the measuring distance for 100 % filling. 6. Min. adjustment In this menu item you carry out the min. adjustment. Enter the measuring distance for 0 % filling. VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 14: Parameter Adjustment - Extended Adjustment

    To perform the adjustment, enter the distance with full and empty ves- sel, see the following example: VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 15 With the adjustment software PACTware and the PC, the stored echo curves can be displayed with high resolution and used to recognize signal changes over time. In addition, the echo curve saved during setup can also be displayed in the echo curve window and compared with the current echo curve. VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 16 The level would then no longer be detectable in this area. If a false signal suppression has already been saved in the sensor, the following menu window appears when selecting "False signal suppression": VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 17: Menu Overview

    3.8 mA Min./Max. 20.5 mA Lock adjustment Released Display Menu item Default setting Menu language Order-specific Displayed value 1 Filling height in % Displayed value 2 Electronics temperature in °C Backlight Switched on VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 18 4 … 20 mA False signal suppression Linearisation Linear HART mode Address 0 Special pa- rameters Info Menu item Parameter Device name Device name Instrument version Hardware and software version Factory calibration date Date VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 19 5 Set up the sensor with the display and adjustment module Menu item Parameter Sensor characteristics Order-specific characteristics VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 20: Supplement

    0.2 … 2.5 mm² (AWG 24 … 14) Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16) Voltage supply Operating voltage 8 … 30 V DC Power consumption max. 520 mW Reverse voltage protection Integrated VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 21 Notes VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 22 Notes VEGAPULS 69 • Modbus and Levelmaster protocol...
  • Page 23 Notes VEGAPULS 69 • Modbus and Levelmaster protocol...
