- Page 1 Product information Radar Level measurement in bulk solids VEGAPULS 67 VEGAPULS SR 68 VEGAPULS 68 VEGAPULS 69 Document ID: 29427...
-
Page 2: Table Of Contents
Take note of safety instructions for Ex applications Please note the Ex specific safety information that you can find at www.vega.com and that comes with each instrument. In hazardous areas you should take note of the appropriate regulations, conformity and type approval certificates of the sensors and power supply units. The sen- sors must only be operated on intrinsically safe circuits. -
Page 3: Measuring Principle
A special time stretching procedure allows reliable and precise measure- ment of the extremely short times. The VEGAPULS 67, SR 68, 68 radar sensors work with low emitted power in the K-band frequency range. Measuring principle VEGAPULS 69 The instrument emits a continuous radar signal via its lens-shaped antenna. -
Page 4: Type Overview
Type overview Type overview VEGAPULS 67 VEGAPULS SR 68 VEGAPULS 68 Applications Bulk solids Bulk solids under extremely difficult pro- Bulk solids under extremely difficult pro- cess conditions cess conditions Max. measuring range 15 m (49.21 ft) 30 m (98.43 ft) 75 m (246.1 ft) Antenna/Material Completely encapsulated plastic horn an- Horn or parabolic antenna/316L... - Page 5 Type overview VEGAPULS 69 Applications Bulk solids under extremely difficult process conditions Max. measuring range 120 m (393.7 ft) Antenna/Material Horn antenna/PP or lens antenna/PEEK Process fitting/Material Mounting strap/316L, flange/PP, flange/316L Process temperature -40 … +200 °C (-40 … +392 °F) Process pressure -1 …...
-
Page 6: Instrument Selection
Instrument selection Application areas VEGAPULS 67 The VEGAPULS 67 is a sensor for continuous level measurement of bulk solids under simple process conditions. It is suitable for smaller silos and vessels. The VEGAPULS 67 is an economical solution through its versatile and simple mounting options. The encapsulated antenna system ensures maintenance-free permanent operation even with strong contamination. -
Page 7: Selection Criteria
Selection criteria Selection criteria VEGAPULS 67 VEGAPULS VEGAPULS 68 VEGAPULS 69 SR 68 Vessel Small to medium-size vessels ● ● ● ● Medium-size to large vessels – ● ● ● Large vessel – – ● ● Very large vessels – – ● ● Process Simple process conditions ●... -
Page 8: Housing Overview
Housing overview Housing overview Plastic PBT Protection rating IP 66/IP 67 IP 66/IP 67 Single chamber Double chamber Version Application area Industrial environment Industrial environment Aluminium Protection rating IP 66/IP 67, IP 66/IP 68 (1 bar) IP 66/IP 67, IP 66/IP 68 (1 bar) Version Single chamber Double chamber... -
Page 9: Mounting
Clinker is an additive for concrete and is stored in large silos or bunkers. Its abrasive properties as well as extreme dust generation during filling Fig. 16: Level measurement in a plastic granules silo with VEGAPULS 67 place heavy demands on the level measurement. - Page 10 Mounting Cement silo Fig. 19: Level measurement in a cement silo with VEGAPULS 69 Cement is stored in high and very slender silos. The abrasive properties as well as the extreme dust generation during filling make high demand on the level measurement. The VEGAPULS 69 sensor is the optimum solution for level measure- ment.
-
Page 11: Electronics - 4
Electronics - 4 … 20 mA/HART - two-wire Electronics - 4 … 20 mA/HART - two-wire Configuration of the electronics Connection The plug-in electronics is mounted in the electronics compartment of the Single chamber housing instrument and can be exchanged by the user when servicing is required. The electronics is completely encapsulated to protect against vibration and moisture. -
Page 12: Electronics - 4
Electronics - 4 … 20 mA/HART - four-wire Electronics - 4 … 20 mA/HART - four-wire Configuration of the electronics The plug-in electronics is mounted in the electronics compartment of the instrument and can be exchanged by the user when servicing is required. The electronics is completely encapsulated to protect against vibration and moisture. -
Page 13: Electronics - Profibus Pa
Electronics - Profibus PA 9 Electronics - Profibus PA Configuration of the electronics Double chamber housing The plug-in electronics is mounted in the electronics compartment of the instrument and can be exchanged by the user when servicing is required. The electronics is completely encapsulated to protect against vibration and moisture. -
Page 14: Electronics - Foundation Fieldbus
Electronics - Foundation Fieldbus 10 Electronics - Foundation Fieldbus Configuration of the electronics Double chamber housing The plug-in electronics is mounted in the electronics compartment of the instrument and can be exchanged by the user when servicing is required. The electronics is completely encapsulated to protect against vibration and moisture. -
Page 15: Electronics - Modbus, Levelmaster Protocol
Electronics - Modbus, Levelmaster protocol 11 Electronics - Modbus, Levelmaster protocol Configuration of the electronics The plug-in electronics is mounted in the electronics compartment of the instrument and can be exchanged by the user when servicing is required. The electronics is completely encapsulated to protect against vibration and moisture. -
Page 16: Operation
The display and adjustment module with integrated Bluetooth functional- ity allows wireless connection to smartphones/tablets with iOS or Android operating system. The adjustment is carried out via the VEGA Tools app from the Apple App Store or Google Play Store. - Page 17 DD adjustment programs such as, for example, AMS™ and PDM. Connection cable sensor - external display and adjustment unit External display and adjustment unit The files can be downloaded at www.vega.com/downloads under "Soft- Display and adjustment module ware". Field Communicator 375, 475 Device descriptions for the instrument are available as EDD for param- eter adjustment with the Field Communicator 375 or 475.
-
Page 18: Dimensions
Dimensions 13 Dimensions Plastic housing VEGAPULS SR 68 ~ 69 mm ~ 84 mm (2.72") (3.31") ø 79 mm ø 79 mm (3.11") (3.11") M16x1,5 SW 46 mm M20x1,5/ (1.81") ½ NPT M20x1,5/ G1½ A ½ NPT Single chamber housing Double chamber housing Aluminium housing ~ 116 mm ~ 87 mm... - Page 19 Plastic horn antenna with mounting strap Metal jacketed lens antenna with swivelling holder The listed drawings represent only an excerpt of the available process fittings. You can find more drawings at www.vega.com/downloads under "Drawings". Radar - Level measurement in bulk solids...
- Page 20 All statements concerning scope of delivery, application, practical use and operating conditions of the sensors and processing systems correspond to the information available at the time of printing. Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2016 VEGA Grieshaber KG Phone +49 7836 50-0...
