Page 1: Quick Setup Guide
Quick setup guide Radar sensor for continuous level measurement of bulk solids VEGAPULS 69 Profibus PA Document ID: 47256... - Page 2 Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available in the download area of "www.vega.com". Operating instructions VEGAPULS 69 - Profibus PA: Document- ID 47250 Editing status of the quick setup guide: 2017-08-10...
-
Page 3: For Your Safety
During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS 69 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". -
Page 4: Eu Conformity
• When installed within 4 to 40 km of a radio astronomy station, the instrument must not be mounted higher than 15 m above the ground. VEGAPULS 69 • Profibus PA... -
Page 5: Environmental Instructions
The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 69 • Profibus PA... -
Page 6: Product Description
Alternatively, you can access the data via your smartphone: • Download the smartphone app "VEGA Tools" from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or •... -
Page 7: Mounting 3.1 Mounting Preparations, Mounting Strap
The polarization is the direction of the electrical component of these waves. The polarization direction is marked by a nose on the housing, see following drawing: Fig. 3: Position of the polarisation Nose for marking the direction of polarisation VEGAPULS 69 • Profibus PA... - Page 8 If you cannot maintain this distance, you should carry out a false signal suppression during setup. This applies particularly if buildup on the vessel wall is expected. In such cases, we recommend repeating the false signal suppression at a later date with existing buildup. VEGAPULS 69 • Profibus PA...
-
Page 9: Connecting To The Bus System 4.1 Connecting
1 cm (0.4 in) of insulation from the ends of the individual wires 5. Insert the cable into the sensor through the cable entry Fig. 5: Connection steps 5 and 6 - Single chamber housing VEGAPULS 69 • Profibus PA... -
Page 10: Wiring Plan, Single Chamber Housing
10. Reinsert the display and adjustment module, if one was installed 11. Screw the housing lid back on The electrical connection is finished. Wiring plan, single chamber housing The following illustration applies to the non-Ex as well as to the Ex-ia version. VEGAPULS 69 • Profibus PA... -
Page 11: Wiring Plan, Double Chamber Housing
For external display and adjustment unit Ground terminal for connection of the cable screen Information: Parallel use of an external display and adjustment unit and a display and adjustment module in the terminal compartment is not supported. VEGAPULS 69 • Profibus PA... -
Page 12: Set Up With The Display And Adjustment Module 5.1 Insert Display And Adjustment Module
The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 9: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing VEGAPULS 69 • Profibus PA... -
Page 13: Parameter Adjustment - Quick Setup
In the first menu item you assign a suitable measurement loop name. Permitted are names with max. 19 characters. 2. Medium In this menu item you select the type of bulk solid. The selection com- prises different granulate sizes. VEGAPULS 69 • Profibus PA... -
Page 14: Parameter Adjustment - Extended Adjustment
The return to the measured value indication is carried out through the [->] or [ESC] keys or automatically after 3 s Parameter adjustment - Extended adjustment Main menu The main menu is divided into five sections with the following func- tions: VEGAPULS 69 • Profibus PA... - Page 15 Min. level = max. measuring distance Max. level = min. measuring distance Reference plane If these values are not known, an adjustment with the distances of e.g. 10 % and 90 % is possible. Starting point for these distance specifica- VEGAPULS 69 • Profibus PA...
- Page 16 This should be done with the lowest possible level so that all potential interfering reflections can be detected. Proceed as follows: 1. Select with [->] the menu item "False signal suppression" and confirm with [OK]. 2. Confirm again with [OK]. VEGAPULS 69 • Profibus PA...
-
Page 17: Menu Overview
This value can now be changed and the false signal suppression can be extended to this range. Menu overview Setup Menu item Parameter Default setting Instrument ad- dress Measurement Sensor loop name VEGAPULS 69 • Profibus PA... - Page 18 Displayed value 1 Filling height in % Electronics temperature in °C Displayed value 2 Backlight Switched on Diagnostics Menu item Parameter Default setting Sensor status Peak value Distance Meas. certainty Peak values, ad- Temperature ditional VEGAPULS 69 • Profibus PA...
- Page 19 4 … 20 mA False signal suppression Linearization Linear Special pa- rameters Info Menu item Parameter Device name VEGAPULS 6. Instrument version Hardware and software version Factory calibration Date date Profibus ident number Sensor-specific Sensor characteristics Order-specific characteristics VEGAPULS 69 • Profibus PA...
-
Page 20: Technical Data
13.5 … 17.5 V DC FISCO model Ʋ Ex-ia instrument - Power supply 13.5 … 24 V DC ENTITY model Ʋ Ex-d-ia instrument No lighting possible (integrated ia barrier) Number of sensors per DP/PA segment coupler, max. Ʋ Non-Ex VEGAPULS 69 • Profibus PA... - Page 21 6 Supplement Ʋ Ex VEGAPULS 69 • Profibus PA...
- Page 22 Notes VEGAPULS 69 • Profibus PA...
- Page 23 Notes VEGAPULS 69 • Profibus PA...
-
Page 24: Information
Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2017 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
