ABTI-GM4
BLUETOOTH CAR KITS
IThe ABTI-GM4 is designed to integrate a Handsfree Bluetooth Car Kit into General Motors vehi-
cles that have the LAN data system. The OEM radio will mute when a call comes in and the
audio will be heard through the front speakers. The ABTI-GM4 is Plug-N-Play for the Motorola
IHF1000 and Parrot car kits, and it can be used with other car kits with modifications.
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
1-800-221-0932
© COPYRIGHT 2007-2008 METRA ELECTRONICS CORPORATION
ABTI-GM4
GM LAN
INTERFACE
FOR HANDSFREE
A A P P P P L L I I C C A A T T I I O O N N S S : :
CHEVROLET
Cobalt
2007-08
HHR
2006-08
Malibu
2008
PONTIAC
G5
2007-08
Solstice
2006-08
SATURN
Aura
2006-08
Sky
2006-08
www.axxessinterface.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABTI-GM4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Axxess ABTI-GM4

  • Page 1 FOR HANDSFREE BLUETOOTH CAR KITS IThe ABTI-GM4 is designed to integrate a Handsfree Bluetooth Car Kit into General Motors vehi- cles that have the LAN data system. The OEM radio will mute when a call comes in and the audio will be heard through the front speakers. The ABTI-GM4 is Plug-N-Play for the Motorola IHF1000 and Parrot car kits, and it can be used with other car kits with modifications.
  • Page 2 TEMS COULD CAUSE HARM TO PERSONS AS WELL. IF YOU HAVE ANY QUES- TIONS IN THIS REGARD PLEASE CALL THE HELP LINE OR THE METRA AT : 1-800-221-0932 FOR ASSISTANCE. ABTI-GM4 NOWLEDGE IS Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry.
  • Page 3: Tools Required

    1) Tools to remove the OEM radio 2) Wire ties INSTALLING THE ABTI-GM4 WITH THE MOTOROLA IHF1000 Note: 8-Way to 8-Way connector harness is used in this application. NOTE: The ISO to 8 way connector harness will NOT be used in this application.
  • Page 4 ABTI-GM4 3) Insert the 14 pin plug on the ABTI-GM4 cable into the rear of the radio. FROM CAR FROM CAR ABTI-GM4 FROM CAR FROM CAR White 8 pin plug IHF-1000 keypad 4) Insert the 16 pin plug on the ABTI-GM4 cable into the rear of the radio.
  • Page 5 5) Connect the 14 pin cap on the ABTI-GM4 cable to the 14 pin plug connected to the vehicle (the connector that was removed from the back of the radio). FROM CAR FROM CAR FROM CAR FROM CAR 6) Connect the 16 pin cap on the ABTI-GM4 cable to the 16 pin plug connected to the vehicle (the connector that was removed from the back of the radio).
  • Page 6 8) Connect the white 8 pin plug on the IHF-1000 cable to the ABTI-GM4 power cable, and con- nect the other end of the power cable to the ABTI-GM4 module. 9) Install the IHF-1000 keypad on the dashboard of the vehicle, and route the wire to the IHF- 1000 harness.
  • Page 7 Audio from any source will be muted when a call comes in or a call is made. OTHER HANDSFREE KITS Other handsfree kits can be used with the ABTI-GM4. Follow the steps below to wire the handsfree kit: 1) Using the ISO to 8 way connector harness cut the ISO ends off.
  • Page 8 ABTI-GM4 INSTRUCTIONS www.axxessinterface.com 1-800-221-0932 REV. 09/03/08 © COPYRIGHT 2007-2008 METRA ELECTRONICS CORPORATION INSTABTI-GM4...
