ORiNG IGPS-R9084GP Quick Installation Manual

PoE
GIGABIT
SWITCH
Q I
uick nstallation
I N D U S T R I A L
Introduction
The IGPS-R9084GP is a managed industrial Ethernet switch with eight
10/100/1000Base-T(X) ports and four 100/1000Base-X SFP ports. The
eight RJ45 Ethernet ports are P.S.E-enabled, which can transmit electrical
power up to 30 watts per port. With Layer-3 support for higher network
performance on large-scale LANs, the switch is optimized to transmit data
as fast as Layer-2 switches. With complete support of Ethernet redundancy
protocols, O-Ring (recovery time < 30ms for over 250 connected devices)
and MSTP (RSTP/STP compatible) can protect your mission-critical
applications from network interruptions or temporary malfunctions. With a
o
wide operating temperature from -40 C to 70 C, the device
managed centralized via ORing's proprietary Open-Vision platform as
well as via Web-based interfaces, Telnet and console (CLI).
the switch is one of the most reliable choice for highly-managed and fiber
Ethernet applications.
Package Contents
The device is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service representative for
assistance.
Contents Pictures
IGPS-R9084GP
CD
DIN-rail Kit
Wall-mount Kit
Console Cable
QIG
Preparation
Before you begin installing the switch, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Safety & Warnings
Elevated Operating Ambient: If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be
greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
Reduced Air Flow: Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is
not compromised.
Q I G
IGPS-R9084GP
IGPS-R9084GP
G
uide
Mechanical Loading:
hazardous condition is not achieved due to uneven mechanical loading.
Circuit Overloading:
to the supply circuit and the effect that overloading of the circuits might have on overcurrent
protection and supply wiring. Appropriate consideration of equipment nameplate ratings
should be used when addressing this concern.
Dimension
o also
can be
96.4
70.5 15.0 10.9
Therefore,
G12 PWR
PWR1
PWR2
G11
G10
G9
100/1000X
G8 G7
G6 G5
G4 G3
G2 G1
10/100/1000T IGPS-R9084GP
Number
Panel Layouts
X 1
Front View
13
G12
X 1 12 G11
G10
G9
100/1000X
9
X 1
G8 G7
11
G6 G5
10
G4 G3
X 2
G2 G1
10/100/1000T
X 1
Rear View
X 1
1 1
1. Wall-mount screw holes
2. Din-rail screw holes
1907-2-29-IGPSR9084GP-1.0
Mounting of the equipment in the rack should be such that a
Consideration should be given to the connection of the equipment
87.0
58.0
48.0
145.5
1. Reset button
2. PWR status LED
1
2
PWR 3. PWR1 LED
PWR1 3
4 4. PWR2 LED
PWR2
5
6 5. R.M. status LED
7
6. Ring status LED
8
7. Faulty relay indicator
8. Console port
9. Link/action LED for Gigabit PoE
LAN ports (Odd PoE ports)
10. Gigabit Ethernet ports
11. Link/action LED for Gigabit PoE
14
LAN ports (Even PoE ports)
12. SFP port
13. Link/Act LED for SFP port
IGPS-R9084GP
14. PoE LED for LAN ports
Top Panel
PWR-2 Fault PWR-1
1 1A@24V
V2- V2+ V1- V1+ DC 50-57V
2
2
1. Terminal blocks: PWR1, PWR2
, Relay
2. Ground wire.
PRINTED ON RECYCLED PAPER
Industrial Managed PoE Gigabit Switch
Installation
DIN-rail Installation
Step 1: Slant the switch and screw the Din-rail kit onto the back of the switch, right in
the middle of the back panel.
Step 2: Slide the switch onto a DIN-rail from the Din-rail kit and make sure the switch
clicks into the rail firmly.
R2.5
R3.95
87.9
Wall-mounting
Step 1: Screw the two pieces of wall-mount kits onto both ends of the rear panel of the
switch. A total of six screws are required, as shown below.
Step 2: Use the switch, with wall mount plates attached, as a guide to mark the
correct locations of the four screws.
Step 3: Insert four screw heads through the large parts of the keyhole-shaped apertures,
and then slide the switch downwards. Tighten the four screws for added stability.
Network Connection
The switch provides standard Ethernet ports. According to the link type, the switch
uses CAT 3, 4, 5, 5e UTP cables to connect to any other network devices (PCs,
servers, switches, routers, or hubs). Please refer to the following table for cable
specifications.
Cable Types and Specifications:
Cable Type
10BASE-T Cat. 3, 4, 5 100-ohm
100BASE-TX Cat. 5 100-ohm UTP
1000BASE-T Cat. 5 / Cat. 5e 100-ohm UTP
Version 1.0
G12 PWR
PWR1
PWR2
G11
G10
G9
100/1000X
G8 G7
G6 G5
G4 G3
G2 G1
10/100/1000T
IGPS-R9084GP
Max. Length Connector
UTP 100 m (328 ft) RJ-45
UTP 100 m (328 ft) RJ-45
UTP 100 m (328 ft) RJ-45
Quick Installation Guide
