Summary of Contents for Eaton LMS

Page 1 Modular Furniture Technical environment systems Installation manual...
Page 2 Technical Environment Systems I N S T A L L A T I O N M A N U A L Table of Contents INTRODUCTION Full Frame, Open Frame & Upright Assembly ........................A Foundations ..................................B Mobile & Caster Base................................C Hook-on Worksurfaces (All Styles) ............................D Floor Shelf Components ..............................E Hook-on Steel Shelf Components (All Styles)........................F Locking Compartments ..............................G...
Page 3 Technical Environment Systems Introduction Congratulations on your purchase of Wright Line’s Technical Environment Systems. These systems consist of a wide selection of steel uprights, structural support frames, worksurfaces, keyboard holders, steel and laminate shelf components and accessories designed to meet specialized storage requirements in a wide vari- ety of environments in today’s workplace.
Page 4 F u l l F r a m e a n d technical furniture U p r i g h t A s s e m b l y Tools Required -Tape measure -Phillips head screwdriver -5/32” Allen wrench (provided) -1/4”...
Page 5 F u l l F r a m e a n d U p r i g h t A s s e m b l y technical furniture ( c o n t . ) Enhanced Upright Double Upright Full Depth Upright Figure 2 UPRIGHT ASSEMBLY...
Page 6 F u l l F r a m e a n d technical furniture U p r i g h t A s s e m b l y ( c o n t . ) 24”, 30”, 36”, 42” 48”...
Page 7 F u l l F r a m e a n d technical furniture U p r i g h t A s s e m b l y ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 8 F u l l F r a m e a n d technical furniture U p r i g h t A s s e m b l y ( c o n t . ) Parts List Part Number Description Qty.
Page 9 F u l l F r a m e a n d U p r i g h t A s s e m b l y technical furniture ( c o n t . ) 81489...
Page 10 F u l l F r a m e a n d U p r i g h t A s s e m b l y technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 11 T e c h C o r n e r P o s t technical furniture Post Frame The Tech Corner Post enables two or more Full/Open Frames to “L” be configured perpendicular to each other. It can also create “T” or “X”...
Page 12 T e c h C o r n e r P o s t technical furniture ( c o n t . ) Parts List Part Number Description Qty. 3591X 45” Corner Post 2945X 61” Corner Post 2944X 72” Corner Post 2943X 84”...
Page 13 F r a m e L i n k i n g K i t technical furniture Please read these instructions carefully and follow the installation steps in sequence. Tools Required - 3/8” Open end wrench - 7/16” Open end wrench - 1/2”...
Page 14 F r a m e L i n k i n g K i t ( c o n t . ) technical furniture Joint between IMPORTANT two frames When two frames are linked, the center-to-center dimension between the trapezoidal holes at the joint is 1.38”...
Page 15 F r a m e L i n k i n g K i t ( c o n t . ) technical furniture Centering screw LINKING FRAMES (continued) Second pre-assembled 4. Align the second pe-assembled frame section with frame section the first and slide the two frame sections together.
Page 16 F r a m e L i n k i n g K i t ( c o n t . ) technical furniture 36” 27” INSTALLING THE FRONT SUPPORT If worksurfaces are being installed in the linked frame configuration, they must be positioned at the same height and Front Supports must be installed with the Add-On Foot at each frame joint.
Page 17 F r a m e L i n k i n g K i t ( c o n t . ) technical furniture INSTALLING THE FRONT SUPPORT (cont.) 5. Adjust the screw at the bottom of the Front Support assembly with a 1/2”...
Page 18 F r a m e L i n k i n g K i t ( c o n t . ) technical furniture Parts List Part Number Description Qty. 8837X Add-On Foot Assembly 8839X Front Support Assembly 8842X Bearing Plate 8848X 24”...
Page 19 F o o t E x t e n d e r K i t technical furniture Please read these instructions carefully and follow the installation steps in sequence. Tools Required -5/32” Allen wrench (provided) 1. Remove the end cap from the back of the foot and install the Foot Extender.
Page 20 Tool Tracks may be installed on Low Profile Overhead Brackets (MA50-MM) or on High Profile Overhead Brackets (MA51-MM) which are ordered separately. Tool Track Tool Tracks may be installed on LMS Full Frames or TechOrganizer frames. IMPORTANT: Maximum Tool Track loading is 50 lbs. Full frame Tools Required: -5/32”...
Page 21 F o o t E x t e n d e r K i t ( c o n t . ) technical furniture Parts List Part Number Description Qty. 1979X Foot Extender 68681 1/4”-20 x 3/8” Button Head Cap Screw 21333 Leveler 1242X...
Page 22 T o o l T r a c k / T o o l J i b technical furniture ( c o n t . ) BENCH MOUNTED JIB INSTALLATION Bench mounted Jibs may be installed on maple bench tops or laminate particle board tops. IMPORTANT: - Maximum Jib loading is 20 lbs.
Page 23 T o o l T r a c k / T o o l J i b technical furniture ( c o n t . ) BENCH MOUNTED JIB INSTALLATION (cont.) 5. Insert the Balancer Trolley and the End Stop into the Swinging Jib Track and then install the End Cap.
Page 24 T o o l T r a c k / T o o l J i b technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty. Part Number Description Qty. 83631 Tool Track, 48.00” 59588 Lock Washer 85352...
Page 25 R e t r o f i t K i t technical furniture N o v a Please read these instructions carefully and follow the installation steps in sequence. NOTE: The Trim Ring provided with the Nova01 and Nova06 kits can not be used with Linx Worksurfaces. Please discard Trim Ring.
Page 26 R e t o f i t K i t N o v a ( c o n t . ) technical furniture Viewport cutout Worksurface 3. Turn the assembly upright and position it underneath the viewport cutout in the Worksurface. Align the holes in the Top Rails with the corresponding holes in the Worksurface and attach with the #14AB x 3/4”...
Page 27 R e t o f i t K i t N o v a ( c o n t . ) technical furniture #6AB x 5/8” Screws 6. Install Trim Ring by snapping pieces together, lowering Trim ring into cut-out and attaching with four #6AB x 5/8” screws provided.
Page 28 R e t o f i t K i t N o v a ( c o n t . ) technical furniture MONITOR SUPPORT INSTALLATION NOTE: The Monitor Support adjusts three ways - for 3. To make angle adjustments, move either the top height, angle and forward/backward.
Page 29 R e t o f i t K i t N o v a ( c o n t . ) technical furniture Parts List Part Number Description Qty. 1 5001818-02 Side Assembly 2 5001818-03 Cross Brace Keyboard Drawer 4 5001818-06 Monitor Support 5 5001818-07 Viewport Glass 6 5001818-08 Leveler 7 5001818-11 #14AB x 3/4”...
Page 30 R e t o f i t K i t N o v a ( c o n t . ) technical furniture A-27 86270...
Page 31 s u r f a c e f i l l e r technical furniture Tools Required - Phillips head screwdriver - Electric drill - 1/8” Drill bit NOTE: This Surface Filler is designed to be compatible with Standard Uprights only. Surface Filler It is not compatible with Enhanced Up- rights.
Page 32 Tools Required -3/8” Wrench -5/32” Allen wrench -1/8” Allen wrench -Level -Leveling wrench (provided) LMS Foundations Fasteners That You Will Be Using #87551 #87554 1/4”-20 x 2.00” Hex Washer Head 1/4”-20 x 3/4” Hex Washer Head Thread Cutting Screw (Black)
Page 33 L M S F o u n d a t i o n s ( c o n t . ) technical furniture Frame Components Cross Ties Intermediate Intermediate Corner Post With End Upright - L.H. End Upright - R.H. Standards Upright Standards Assembled...
Page 34 L M S F o u n d a t i o n s ( c o n t . ) technical furniture End upright (R.H. shown) FRAME ASSEMBLY - INITIAL SECTION (cont.) 3. With two people, position the second End Upright vertically and attach the previously assembled up- right and Cross Ties to it with eight 1/4”-20 x .75”...
Page 35 FRAME ASSEMBLY - CORNER SECTIONS “L” The LMS Foundations System can be assembled in various corner configurations. See figure 4. 1. Attach the appropriate quantity of Standards to the Corner Post with the 1/4”-20 x 2.00” hex washer head thread cutting screws and tighten securely.
Page 36 L M S F o u n d a t i o n s ( c o n t . ) technical furniture Linear unit 4. Stand the Corner Post assembly up and and attach the Cross Ties to the linear unit with eight 1/4”-20 x 2.00”...
Page 37 L M S F o u n d a t i o n s ( c o n t . ) technical furniture Parts List Part Number Description Qty. 9027X Ass’y, 61” End Upright - L.H. 31” Deep 9029X Ass’y, 72” End Upright - L.H. 31” Deep 9031X Ass’y, 84”...
Page 38 L M S F o u n d a t i o n s ( c o n t . ) technical furniture Parts List Part Number Description Qty. 9039X Ass’y, 61” Intermediate Upright, 31” Deep 9040X Ass’y, 72” Intermediate Upright, 31” Deep 9041X Ass’y, 84”...
Page 39 L M S F o u n d a t i o n s ( c o n t . ) technical furniture Parts List Part Number Description Qty. 9002X 24” Cross Tie 9003X 30” Cross Tie 9004X 36” Cross Tie 9006X 48”...
Page 40 L M S F o u n d a t i o n s technical furniture A c c e s o r i e s Plug Cap BASIC PLUS PLUG CAP ACCESSORY (#3374X) The Plug Cap is a decorative cap for the End Panels of End Panel Tower, Electronics and General Purpose Shelves.
Page 41 L M S F o u n d a t i o n s C a s t e r K i t technical furniture Please read these instructions carefully and follow the installation steps in sequence. Tools Required -1/4” Allen Wrench (provided) Fasteners That You Will Be Using Caster Kit #18950...
Page 42 L M S F o u n d a t i o n s C a s t e r K i t ( c o n t . ) technical furniture Parts List Part Number Description Qty. 9185X L.H. Caster Bracket Assembly 9186X R.H.
Page 43 O p e n M o b i l e B a s e technical furniture Tools Required -5/32” Allen wrench (provided) -1/4” Allen wrench (provided) UPRIGHT /MOBILE BASE ASSEMBLY Note: Place the Mobile Base in an area with adequate floor space for the base and the Full Frame.
Page 44 O p e n M o b i l e B a s e technical furniture ( c o n t . ) FULL FRAME ASSEMBLY Refer to page_ for Full Frame assembly. Enhanced upright Round tubes FRAME TO UPRIGHT ASSEMBLY NOTE: The rear of the Mobile Base has a straight tube and spaced from it, a formed tube.
Page 45 O p e n M o b i l e B a s e technical furniture ( c o n t . ) Parts List Part Number Description Qty. 3511X Mobile Base, 24” x 31” Deep 3512X Mobile Base, 30” x 31” Deep 3513X Mobile Base, 36”...
Page 46 C a s t e r B a s e technical furniture SAFETY INSTRUCTIONS 1. The Frame and Upright Assembly must be unloaded prior to installation to the Caster Base. If the Caster Base is being installed onto a Frame configuration that is in use, the unit must be unloaded Caster Base and partially unassembled.
Page 47 C a s t e r B a s e technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty. Part Number Description Qty. 2457X 24” Caster Base 3275X Foot Cap 2458X 30” Caster Base 57403 5/16”-18 x 2.00”...
Page 48 L i n e a r H o o k - o n technical furniture W o r k s u r f a c e s Linear Hook-On Worksurfaces come in three depths and seven lengths. Different worksurfaces have different reqirements for installation that are outlined below.
Page 49 L i n e a r H o o k - o n W o r k s u r f a c e s technical furniture ( c o n t . ) R.H. upright assembly Tools Required Trapezoid Top support bracket - Phillips head screwdriver - 3/8”...
Page 50 L i n e a r H o o k - o n W o r k s u r f a c e s technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 51 L i n e a r H o o k - o n W o r k s u r f a c e s technical furniture ( c o n t . ) 82354...
Page 52 C o r n e r H o o k - O n technical furniture W o r k s u r f a c e Tools Required -5/32” Allen Wrench (provided) -Phillips head screwdriver -Plastic mallet Important Corner Hook-on Worksurfaces with 36” deep sides require the use of: -40”...
Page 53 C o r n e r H o o k - O n technical furniture W o r k s u r f a c e R.H. Upright assembly 1. Determine what height the Corner Hook-on Worksur- face will be by measuring from the floor to the top Trapezoid Top support bracket of the hook-on Top Support and adding 1”.
Page 54 C o r n e r H o o k - O n technical furniture W o r k s u r f a c e Parts List Part Number Description Qty. 3007X 48” x 48” Corner Worksurface, 27” Sides 3008X 48”...
Page 55 H o o k - O n P e n i n s u l a technical furniture W o r k s u r f a c e Please read these instructions carefully and follow the installation steps in sequence. Tools Required - 5/32 Hex Key - Phillips Head Screwdriver...
Page 56 H o o k - O n P e n i n s u l a technical furniture W o r k s u r f a c e ( c o n t . ) 3. With two people, turn the Peninsula upright and place it onto the Hook-on Support Brackets.
Page 57 H o o k - O n P e n i n s u l a technical furniture W o r k s u r f a c e ( c o n t . ) Parts List Part Number Description Qty.
Page 58 H o o k - O n P e n i n s u l a technical furniture W o r k s u r f a c e ( c o n t . ) 83523 D-11...
Page 59 A l u m i n u m T o p technical furniture S u p p o r t s Tools Required -5/32” Allen wrench -Phillips head screwdriver Top Bracket NOTE: The Aluminum Top Supports are constructed of two die cast aluminum parts and are designed to attach to Enhanced Uprights using front to back Aluminum Top Support tubular stabilizers.
Page 60 A l u m i n u m T o p technical furniture S u p p o r t s ( c o n t . ) Parts List Part Number Description Qty. 3098X Support Half, L.H. 3099X Support Half, R.H. Upper 3100X Support Clamp 3101X...
Page 61 W o r k s u r f a c e F i l l e r technical furniture Tools Required -Phillips head screwdriver -Electric drill -1/8” Drill bit PLEASE NOTE: • Worksurface Fillers can only be used on Worksurfaces located 29” or more from the floor. •...
Page 62 Part Number Description Qty. Part Number Description Qty. 59103 #10AB x .75 Philips Pan Head 6045X Worksurface Filler, 27” LMS Thread Forming screw 6048X Worksurface Filler, 30” LMS 3098X Support Half, L.H. 6046X Worksurface Filler, 36” LMS 3099X Support Half, R.H. Upper 6047X Worksurface Filler, 42”...
Page 63 W o r k s u r f a c e technical furniture B a c k s t o p Tools Required -Tape Measure -Electric Drill -9/32”(.281) Drill -Phillips head Screwdriver 1. Accurately measure, locate and drill the correct number of .281 diameter holes in the back of the Worksurface.
Page 64 W o r k s u r f a c e technical furniture B a c k s t o p ( c o n t . ) Parts List Part Number Description Qty. 8969X 24” Backstop 8970X 30” Backstop 8971X 36”...
Page 65 T o w e r S h e l f technical furniture Tools Required -None 1. Position the Tower Floor Shelf between the Upright Feet of the Full Frame or Slotted Posts of a Basic system. See Figure 1. 2. Adjust the leveler/glides, on the bottom of the shelf, as necessary to level the Floor Shelf prior to loading.
Page 66 S h e l f ( c o n t . ) technical furniture Parts List Part Number Description Qty. 2596X 24” LMS Tower Roll-Out 2597X 30” LMS Tower Roll-Out 2598X 36” LMS Tower Roll-Out 2600X 48” LMS Tower Roll-Out 2601X 60”...
Page 67 T o w e r R o l l - o u t S h e l f technical furniture Tools Required -Phillips head screwdriver -5/32 Allen wrench Note: The Tower Roll-Out can be connected to the Full Frame, Open Frame, Basic, or Basic Plus prior to use to prevent forward creep during repeated use.
Page 68 One with each 12” Tower roll out. Note: Additional holes are provided in the Base Pan of the 24” thru 72” wide Tower Roll-Outs to facilitate installing units in a back-to-back configuration on LMS Frames with double up- Tower roll-out Foot rights.
Page 69 T o w e r R o l l - o u t S h e l f ( c o n t . ) technical furniture Installing the Retention Brackets (Foundations) 5. Install Bracket “C” by sliding the Bracket over the Cross tie as shown in Figure 3.
Page 70 T o w e r R o l l - o u t S h e l f ( c o n t . ) technical furniture Parts List Parts List Part Number Description Qty. Part Number Description Qty. 18977 External Lock Washer LA28-XX 12”...
Page 71 H o o k - o n S h e l v i n g technical furniture C o m p o n e n t s Mini Electronics/Telephone Shelf Tools Required Upper Shelf -Phillips head screwdriver Tower Shelf -Plastic mallet -5/33”...
Page 72 H o o k - o n S h e l v i n g technical furniture C o m p o n e n t s ( c o n t . ) General Purpose Electronics Shelf - 16.7” Deep Tower Shelf - 22”...
Page 73 H o o k - o n S h e l v i n g technical furniture C o m p o n e n t s ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 74 H o o k - o n S h e l v i n g technical furniture C o m p o n e n t s ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 75 h o o k - o n H o o k - o n s h e l v i n g S h e l v i n g technical furniture c o m p o n e n t s C o m p o n e n t s ( c o n t .
Page 76 S t e e l S h e l v i n g technical furniture Please read these instructions carefully and follow the installation steps in sequence. Tools Required -Phillips head screwdriver -Plastic mallet -3/8” Wrench Steel Shelving 1. Determine the desired location of the Steel Shelf and attach the Brackets to the frame as shown in figure 1.
Page 77 S t e e l S h e l v i n g ( c o n t . ) technical furniture Parts List Part Number Description Qty. 8580X 24”W x 18”D Shelf 8581X 30”W x 18”D Shelf 8582X 36”W x 18”D Shelf 8583X 42”W x 18”D Shelf 8584X...
Page 78 D e e p e r T o w e r technical furniture C o m p u t e r S h e l f NOTE: The 28" Deep Tower Shelf consists of a rear Shelf Extension and Slotted Filler used in conjunction with a 22" Tower Shelf.
Page 79 D e e p e r T o w e r C o m p u t e r S h e l f technical furniture ( c o n t . ) 4. With two people, position the Shelf Extension End Panels opposite the End Panels of the already Slotted standard positioned Tower Shelf.
Page 80 24” Filler. 2.2” Frame 2590X 30” Filler. 2.2” Frame 2591X 36” Filler. 2.2” Frame 2592X 42” Filler. 2.2” Frame 3260X 24” Filler, LMS Basic 7064X 30” Filler, LMS Basic 7065X 36” Filler, LMS Basic 7066X 42” Filler, LMS Basic 3261X 48”...
Page 81 H e a v y D u t y S h e l f technical furniture S u p p o r t Tools Required -Phillips head screwdriver -Plastic mallet Heavy Duty Shelf Supports may be installed with Tower, Electronics and General purpose shelves Heavy Duty Shelf Support to increase their load capacity.
Page 82 F o r m s T r a y technical furniture Tools Required - Plastic mallet NOTE: Fully welded Forms Tray includes integrated hooks at the back of the shelf which attach the component to a Full Frame. A removable Shelf Divider is also included.
Page 83 F o r m s T r a y ( c o n t . ) technical furniture Parts List Part Number Description Qty. 3774X 24” Forms Tray 5051X 30” Forms Tray 5052X 36” Forms Tray 3775X Divider LB14 F-13...
Page 84 U n i v e r s a l T a p e S h e l f technical furniture Tools Required -Plastic mallet 1. Stand the Uprights apart at approximately the width of the component. 2. Place the Tape Shelf in position at the top of the up- rights by inserting the hooks at each end of the com- Universal Tape Shelf ponent into the slotted standards and pushing down.
Page 85 U n i v e r s a l T a p e S h e l f ( c o n t . ) technical furniture Parts List Part Number Description Qty. 2863X 24” Universal Tape Shelf 1919X 30” Universal Tape Shelf 4288X 36”...
Page 86 L o c k i n g technical furniture C o m p a r t m e n t Tools Required -Phillips head screwdriver -Plastic mallet NOTE: Some assembly may require assistance. Locking Compartment REAR AND END PANEL INSTALLATION 1.
Page 87 L o c k i n g technical furniture C o m p a r t m e n t Receeding door mounting holes TOP INSTALLATION 1. Before installing the Top, make sure that the three screws at the top of each End Panel is backed out 1/8”(3mm) as shown in Figure 3.
Page 88 L o c k i n g technical furniture C o m p a r t m e n t Parts List Parts List Part Number Description Qty. Part Number Description Qty. 8204X Receeding Door, 24” 2614X Rear Panel, 24” 8205X Receeding Door, 30”...
Page 89 H i g h C a p a c i t y L a m i n a t e H o o k - o n technical furniture S h e l v e s Tools required -Plastic mallet 1.
Page 90 H i g h C a p a c i t y L a m i n a t e H o o k - o n technical furniture S h e l v e s ( c o n t . ) Parts List Parts List Part Number...
Page 91 L a m i n a t e H o o k - o n S h e l v e s technical furniture Tools required -Plastic mallet 1. Determine the location of the Shelf. Position the Shelf Supports as shown in Figure 1. Insert the hooks on the back of the supports into the trapeziod shaped slots in the upright posts and push down.
Page 92 L a m i n a t e H o o k - o n S h e l v e s ( c o n t . ) technical furniture Parts List Parts List Part Number Description Qty. Part Number Description Qty.
Page 93 O p e n P r i n t e r S h e l f technical furniture Tools Required -Phillips head screwdriver -Plastic mallet Open Printer Shelf Slotted standard 1. Determine the location of the Open Printer Shelf. and insert the rear hooks into the slotted standards #10 x 3/8”...
Page 94 O p e n P r i n t e r S h e l f technical furniture ( c o n t . ) Parts List Part Number Description Qty. 5399X 24” Open Printer Shelf 5400X 30” Open Printer Shelf 5546X 24”...
Page 95 F o r m s F e e d a n d technical furniture R e c e i v e r R a c k s Tools Required -None NOTE: The Forms Feed and Receiver Rack may be installed on the Linx Open Printer Shelves, Electronics Shelves and General Purpose Shelves.
Page 96 L i n e a r I n c l i n e technical furniture H o o k - o n S h e l v e s Tools Required -Plastic Mallet -Phillips head screwdriver -Flat blade screwdriver 1. Assemble the Front Stop to the shelf, using the #10AB 1-3/4”...
Page 97 L i n e a r I n c l i n e technical furniture H o o k - o n S h e l v e s ( c o n t . ) 3. Align the pre-drilled holes in the bottom surface of the shelf with the holes in the left hand and right hand shelf supports.
Page 98 L i n e a r I n c l i n e H o o k - o n S h e l v e s technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 99 C o r n e r L a m i n a t e H o o k - o n S h e l v e s technical furniture Tools Required -Plastic mallet -Phillips head screwdriver 1. Determine the location of the Corner Laminate Hook-on Shelf.
Page 100 C o r n e r L a m i n a t e H o o k - o n S h e l v e s technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 101 B a s i c P l u s C o r n e r technical furniture L a m i n a t e S h e l f Tools Required -Plastic mallet -Phillips head screwdriver 1. Determine the location of the Corner Corner Laminate Shelves Laminate Hook-on Shelf.
Page 102 B a s i c P l u s C o r n e r L a m i n a t e S h e l f technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 103 B a s i c P l u s C o r n e r technical furniture L a m i n a t e S h e l f ( c o n t . ) Parts List Part Number Description Qty.
Page 104 R a c k M o u n t M o d u l e technical furniture Tools Required -Phillips head screwdriver -5/32” Allen wrench (provided) -Plastic mallet NOTE: Two people are required for the assembly of the larger 61”(1549mm), 72”(1829mm) and 84” high (2134mm) Rack Mount Modules.
Page 105 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) INSTALLING THE SIDE PANELS 1. Position the Side Panel in the desired location . Insert the hooks in the Side Panel into the Slotted Standard and push down.
Page 106 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) 20” Edge protector 4. For larger amounts of cable, remove the 8” x 20” Center (four screws). Taped to the Top/Bottom panel are two 20”...
Page 107 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) 7. #10-32 Clip Nuts and #10-32 x 1/2” Phillips head machine screws are included to allow easy in- stallation of electronic equipment.
Page 108 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) ASSEMBLING THE OPTIONAL EXHAUST FAN Packaged with the Fan Kit is the required hardware for attachment. NOTE: The Top Panels have two screw hole patterns.
Page 109 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) Parts List Part Number Description Qty. 2716X 10” End Panel, 19” Rack Mount Module 2717X 17” End Panel, 19” Rack Mount Module 2718X 24”...
Page 110 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) Parts List Part Number Description Qty. 7846X Perforated Top, 19” Rack Mount Module 7750X Top w/ Fan, 19” Rack Mount Module 7848X Bottom, Cable Access, 19”...
Page 111 R a c k M o u n t M o d u l e technical furniture ( c o n t . ) 82021...
Page 112 R a c k M o u n t M o d u l e technical furniture F r o n t S u p p o r t ( c o n t . ) INSTALLING THE FRONT SUPPORT A Front Support is provided with all 84”...
Page 113 R a c k M o u n t M o d u l e technical furniture F r o n t S u p p o r t ( c o n t . ) Parts List Part Number Description Qty.
Page 114 R a c k M o u n t M o d u l e P l e x i g l a s s D o o r technical furniture Tools Required -Phillips head screwdriver NOTE: Instructions show assembly of a Left Door Swing module.
Page 115 R a c k M o u n t M o d u l e P l e x i g l a s s D o o r technical furniture ( c o n t . ) Rack module 2.
Page 116 r a c k R a c k m o d u l e M o u n t M o d u l e d o o r ( c o n t . ) P l e x i g l a s s D o o r technical furniture ( c o n t .
Page 117 R a c k M o u n t M o d u l e P l e x i g l a s s D o o r technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 118 R a c k M o u n t M o d u l e P l e x i g l a s s D o o r technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 119 R a c k M o u n t M o d u l e P l e x i g l a s s D o o r technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 120 R a c k M o u n t R e a r S e r v i c e D o o r s technical furniture NOTE: Rear Service Doors are available in five heights (24”, 38”, 61”, 72”, and 84”) and in the two Full Frame Module widths (24”...
Page 121 R a c k M o u n t R e a r S e r v i c e D o o r s technical furniture ( c o n t . ) DOOR INSTALLATION (cont.) Door frame However, the two shorter units, 38” and 24” high, may be assembled in any position along the height Filler of the Full Frame.
Page 122 R a c k M o u n t R e a r S e r v i c e D o o r s technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 123 R a c k M o u n t S h e l f technical furniture Tools Required -11/32” Combination wrench -3/8” Combination wrench -Flat blade screwdriver -Phillips head screwdriver -Tape measure NOTE: These instructions cover installation of the Stationary Shelf, and Roll-out Shelf.
Page 124 R a c k M o u n t S h e l f technical furniture ( c o n t . ) Rail ROLL-OUT SHELF INSTALLATION Clip nut NOTE: The Roll-Out is equipped with “Lock Out Screw Slides” and a “Front Disconnect” chassis member for head your convenience during assembly to the Rack Module.
Page 125 R a c k M o u n t S h e l f technical furniture ( c o n t . ) STATIONARY SHELF INSTALLATION Rail 1. Position the Stationary Shelf with the four brackets on the correct side of the clip nuts See Figure 2. Clip nuts 2.
Page 126 R a c k M o u n t S h e l f technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty. Part Number Description Qty. 3150X X-Deep Shelf 81868 4mm x 6mm Phillips Phillister Head Screw 3432X Rack Mount Shelf, 16.6”...
Page 127 V e r t i c a l A d a p t e r R a i l / H o r i z o n t a l technical furniture C h a s s i s B r a c k e t Tools Required -Phillips head screwdriver VERTICAL ADAPTER RAIL...
Page 128 V e r t i c a l A d a p t e r technical furniture R a i l / H o r i z o n t a l C h a s s i s B r a c k e t ( c o n t .
Page 129 P a t c h P a n e l technical furniture B r a c k e t s Tools Required -Plastic mallet 1. Determine the desired location of the Patch Panel Brackets on the Full Frame. NOTE: If multiple lev- els are being used, install the lowest level first.
Page 130 P a t c h P a n e l technical furniture B r a c k e t s ( c o n t . ) Parts List Part Number Description Qty. 2406X 7” Patch Panel Bracket, L.H. 2404X 14”...
Page 131 T e c h W a l l technical furniture Full frame slotted standard Tools Required -Phillips head screwdriver -Plastic mallet -Flat file Mounting channel Tech Walls are available as fabric covered or perforated steel partitions. These instructions are applicable for both types of panels. Panels are provided in various widths and heights, #8-32 x 3/8”...
Page 132 T e c h W a l l technical furniture ( c o n t . ) Important - For proper panel installation, the Mounting Channels must attach flat against the Slotted Standards. If a weld joining the two halves of the intermediate standard exceeds a height of approximately .03”(.8mm), it may be Intermediate necessary to carefully file the weld.
Page 133 T e c h W a l l technical furniture ( c o n t . ) Panel Installation with Components Pre-installed on One Side of Frame Tech Walls may be installed onto Full Frames that have other components on one side. If the Frames Full frame standards have components installed on both sides, they must be removed from one side prior to panel installation.
Page 134 T e c h W a l l technical furniture ( c o n t . ) Parts List Parts List Part Number Description Qty. Part Number Description Qty. 83563 Fabric Panel, 25.84” x 19.88” 3400X Corner Connector, L.H. 83564 Fabric Panel, 25.84”...
Page 135 T e c h W a l l technical furniture ( c o n t . ) 83646...
Page 136 H o r i z o n t a l C a b l e technical furniture M a n a g e m e n t Tools Required - Plastic Mallet 1. Install the Horizontal Cable Management component(s) in the desired location on the back of the frame by inserting the hooks at each end of the component into the slots in the Slotted Standards.
Page 137 H o r i z o n t a l C a b l e technical furniture M a n a g e m e n t ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 138 T o p A c c e s s C a b l e M a n a g e m e n t technical furniture B r a c k e t s Tools Required - None NOTE: The Top Access Cable Management Brackets are used to reposition standard Horizontal Cable Management kits for top access into duct.
Page 139 C o r n e r C o n n e c t o r - T o p A c c e s s technical furniture H o r i z o n t a l C a b l e M a n a g e m e n t Please read these instructions carefully and follow the installation steps in sequence.
Page 140 C o r n e r C o n n e c t o r - T o p A c c e s s technical furniture H o r i z o n t a l C a b l e M a n a g e m e n t ( c o n t .
Page 141 -5/32" Allen wrench (provided) -36" Carpenters level Tech Corner Post 1. The Tech Corner Post enables LMS units and MediaLinx to turn 90 degrees. Dissimilar height units may be used around the Tech Corner Post, provided it is equal to the tallest frame.
Page 142 H o r i z o n t a l C a b l e technical furniture M a n a g e m e n t C o n n e c t o r ( c o n t . ) Corner Cable Management Connector 1.
Page 143 H o r i z o n t a l C a b l e technical furniture M a n a g e m e n t C o n n e c t o r ( c o n t . ) Parts List Part Number Description...
Page 144 I n n e r C a b l e technical furniture M a n a g e m e n t Tools Required -Plastic mallet 1. Install the Right Hand Inner Cable Management Assembly in the desired location on the inside of the Tech Corner by inserting the hooks on each end of the assembly into the slotted standards.
Page 145 I n n e r C a b l e technical furniture M a n a g e m e n t ( c o n t . ) Parts List Part Number Description Qty. 5227X 48” Inner HCM Assembly, R.H. 5226X 48”...
Page 146 4 ” 3 ” V e r t i c a l technical furniture C a b l e M a n a g e m e n t Please read these instructions carefully and follow the installation steps in sequence. Tools Required -Plastic Mallet -Phillips head screwdriver...
Page 147 4 ” 3 ” V e r t i c a l C a b l e M a n a g e m e n t technical furniture ( c o n t . ) INSTALLATION BETWEEN TWO HORIZONTAL 2.
Page 148 4 ” 3 ” V e r t i c a l C a b l e M a n a g e m e n t technical furniture ( c o n t . ) INSTALLATION FOR BOTTOM CABLE FEED 1.
Page 149 4 ” 3 ” V e r t i c a l C a b l e M a n a g e m e n t technical furniture ( c o n t . ) Parts List Part Number Description Qty.
Page 150 B a s i c P l u s technical furniture C a b l e M a n a g e m e n t Mounting channel Cable management duct Tools Required -Phillips Head Screw Driver -Plastic mallet Upright post ATTACHING TO BASIC PLUS (BACK...
Page 151 B a s i c P l u s C a b l e M a n a g e m e n t technical furniture ( c o n t . ) Parts List Part Number Description Qty. 5899X 72”...
Page 152 B a s i c P l u s C a b l e M a n a g e m e n t technical furniture ( c o n t . ) BASICP3 M-17...
Page 153 Tools Required duct -Phillips Head Screw Driver -Plastic mallet APPLYING TO LMS BASIC Post 1. The rear of the Post has a row of small holes. Align holes (every other hole) in the Mounting Channel with the Post holes and attach with the #8 screws.
Page 154 LA34-MM CABLE STRAP, SET OF 25 1. These Cable Ties can be screwed (recommended) Bonding tape to the rear of the LMS Basic Vertical Posts, using Screw the small vertical holes, or Cable ties can be attached to the rear of Tower and Electronic shelves.
Page 155 L M S B a s i c technical furniture C a b l e M a n a g e m e n t K i t ( c o n t . ) Parts List Part Number Description Qty.
Page 156 C a b l e T r o u g h technical furniture C a b l e M a n a g e m e n t Tools Required -Phillips head screwdriver INSTALLATION OF THE CABLE TROUGH 1. To install the Cable Trough, insert the wire tabs located at the top of the Trough into the trapezoid holes in the Full Frame.
Page 157 C a b l e T r o u g h technical furniture C a b l e M a n a g e m e n t ( c o n t . ) Clamp-inner Cable trough INSTALLATION OF THE CABLE TROUGH corner CORNER Straight cable...
Page 158 C a b l e T r o u g h technical furniture C a b l e M a n a g e m e n t ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 159 24”/30” LMS Frame Modules and Rack Mount Rails. 2. LA38-MM may be attached to 36” Tower Roll-out shelves when installing on LMS Frames with 36” Modules. *Note: 36” Tower Roll-outs manufactured before 10/97 may not have the appropriate cable mounting holes, in which case drilling may be required.
Page 160 C a b l e M a n a g e m e n t technical furniture A r m ( c o n t . ) “Width” Slide to adjust Adjustable frame bracket “Width” Application 23.79”(23-25/32”) 24” Full Frame model Phillips head adjustment screws 29.79”(29-25/32”)
Page 161 C a b l e M a n a g e m e n t technical furniture A r m ( c o n t . ) Clip nuts Rack mount rail 3. Attach the Frame Bracket by either screwing it to the Clip Nuts on the rack mount rails OR by hooking it on- to the slotted Full Frame.
Page 162 C a b l e M a n a g e m e n t technical furniture A r m ( c o n t . ) Plastic cable 6. Attach the Cable Arm Bracket to the back of the roll-out Short arm using two #10 x 3/8”...
Page 163 C a b l e M a n a g e m e n t technical furniture A r m ( c o n t . ) Clip nuts Roll-out bracket Rack mount rail Figure 9 Multi-hole washer Rack mount rail Multi-hole washer #10-32 x 1/2”...
Page 164 C a b l e M a n a g e m e n t technical furniture A r m ( c o n t . ) Parts List Part Number Description Vertical Cable 36”W Vertical Cable Extra Cable Management Arm Management Arm Management Arm #LA36-MM...
Page 165 L o w P r o f i l e technical furniture ( 1 5 a m p ) Tools Required -Electric drill -.149” Drill bit -Phillips head bit or screwdriver -Center punch HORIZONTAL INSTALLATION 1. Install the Mounting Clip onto the Base Plate by first slipping one end of the Clip under the tab marked “X”...
Page 166 L o w P r o f i l e technical furniture ( 1 5 a m p ) 3. Install the Power Strip assembly into the Cable Manage- Power strip ment Component as shown in Figure 3. The Mounting assembly Clip/Plate assembly will snap into place at the bottom of the Component as shown in Figure 3 (detail).
Page 167 L o w P r o f i l e technical furniture ( 1 5 a m p ) 3. Next, install the Power Strip into the Clips by engaging one side of the Strip with the Clips and the pushing down to engage the other side.
Page 168 A m p P o w e r technical furniture S t r i p 20A Power strip Tools Required #LPS700, #LPS799, - Power drill #LPS2420, #LPS2420T - .149 inch drill bit - Philips head bit or screwdriver - Center punch Mounting clip INSTALLATION #8-32 Self tapping screws...
Page 169 S u r g e S u p p r e s s o r technical furniture w i t h R e m o t e Tools Required - Phillips head screwdriver - Blade screwdriver Packaged with your Surge Suppresser with Remote are the manufacturers installation and safe usage instructions.
Page 170 K e y b o a r d technical furniture A c c e s s o r i e s NOTE: For non-standard application, use the Track Tools Required as a drill template. Keeping the Track per- - Phillips head screw driver pendicular to both edges, position it 1/2”...
Page 171 K e y b o a r d technical furniture S u p p l e m e n t Tools Required - Phillips head screw driver NOTE: For non-standard application, use the Track as a drill template. Keeping the Track per- pendicular to both edges, position it 1/2”...
Page 172 K e y b o a r d technical furniture A c c e s s o r i e s ( c o n t . ) MOUNTING TO UNDERSIDE OF UPPER SHELF 1. Slide the Articulating Arm into the Track. * Front and Rear Center Screws/Bumpers are not required since the Track is contained inside the 2.
Page 173 K e y b o a r d technical furniture A c c e s s o r i e s ( c o n t . ) LA09-MM Retractable Keyboard with Mouse Tray This Keyboard Platform mounts to the Tray Brackets with four Machine screws.
Page 174 K e y b o a r d technical furniture A c c e s s o r i e s ( c o n t . ) Tools Required -Phillips head screwdriver MOUNTING TO UNDERDSIDE OF WORKSURFACE Pre-drilled holes 1.
Page 175 K e y b o a r d technical furniture A c c e s s o r i e s ( c o n t . ) Parts List Parts List Part Number Description Qty. Part Number Description Qty. 2673X Keyboard Platform w/ Mouse 57488...
Page 176 I n t e r a c t i v e M o n i t o r technical furniture A r m Tools Required -5mm Allen wrench -Phillips screwdriver -Plastic mallet There are two ways to attach a Monitor Arm to a Full Post Mount Beam Mount Frame;...
Page 177 I n t e r a c t i v e M o n i t o r technical furniture A r m ( c o n t . ) ATTACHING THE MONITOR PLATFORM 5. The Monitor Platform drops into the end of the arm. 3.
Page 178 I n t e r a c t i v e M o n i t o r technical furniture A r m ( c o n t . ) Parts List Part Number Description Qty. 3153X Post Mount Assembly 82367 Arm Mount Asembly 3161X...
Page 179 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s Articulating Arm/Components IMPORTANT SAFETY INSTRUCTIONS 1. Do Not exceed the maximum weight load capacity for any component. Component Maximum Capacity Monitor Platform...
Page 180 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s ( c o n t . ) ATTACHING COMPONENTS TO ARM (cont.) Articulating arm 2.
Page 181 ( c o n t . ) INSTALLING THE COMPONENT The Articulating Components may be installed on TechOrganizers or LMS Frames. 1. Determine the desired location on the Organizer/ Frame and insert the hooks on the back of the Articulating Arm mounting bracket into the slotted standard.
Page 182 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s ( c o n t . ) OPTIONAL KEYBOARD TRAY 1. Remove the three plastic hole plugs from the front of the Monitor Platform.
Page 183 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s ( c o n t . ) OPTIONAL FLAT SCREEN MONITOR 1. Assemble the Flat Screen Monitor as shown in figure 8.
Page 184 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s ( c o n t . ) Parts List Parts List Part Number Description Qty.
Page 185 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s ( c o n t . ) 86427 P-10...
Page 186 A r t i c u l a t i n g A r m / technical furniture C o m p o n e n t s ( c o n t . ) 86427 P-11...
Page 187 T a s k L i g h t technical furniture Tools Required -Phillips head screwdriver Task Lights are available in (4) sizes and can be installed on various size shelves per the following matrix. The holes for installation are pre-punched. Shelf Task Light 24”...
Page 188 T a s k L i g h t technical furniture ( c o n t . ) Task light housing Bulb Mounting socket 2. Remove the lens and bulb from the Task Light . To remove the lens, push it up near the front edge of the Task Light fixture.
Page 189 O v e r h e a d L i g h t i n g technical furniture Tools Required - Plastic mallet - 5/32 Hex Wrench (provided) - 1/2” Wrench or socket - Phillips head screwdriver There are three types of Overhead Lighting Support Brackets.
Page 190 O v e r h e a d L i g h t i n g technical furniture ( c o n t . ) Mounting 1/4”-20 x 1/2” Button head spacer screws Spacer flange Figure 2 Overhead light #10-24 x 3/8” Pan head screw Figure 2 Overhead light...
Page 191 O v e r h e a d L i g h t i n g technical furniture ( c o n t . ) Parts List Part Number Description Qty. 3807X Light Support, Low Profile 3808X Light Support, High Profile 5143X Rear Mount Support Bracket 3821X...
Page 192 L a m i n a t e H o o k - o n S h e l v e s w i t h technical furniture O v e r h e a d L i g h t Tools Required -Plastic mallet -Phillips head screwdriver...
Page 193 L a m i n a t e H o o k - o n S h e l v e s w i t h technical furniture O v e r h e a d L i g h t ( c o n t .
Page 194 L a m i n a t e H o o k - o n S h e l v e s w i t h technical furniture O v e r h e a d L i g h t ( c o n t .
Page 195 L a m i n a t e H o o k - o n S h e l v e s w i t h technical furniture O v e r h e a d L i g h t ( c o n t .
Page 196 L a m i n a t e H o o k - o n S h e l v e s w i t h technical furniture O v e r h e a d L i g h t ( c o n t .
Page 197 E S D L a m i n a t e technical furniture Top of ESD worksurface Grounding bolt WARNING: Electro static discharge can be dangerous to equipment and to persons if not properly dissipated. Read this supplement thoroughly for information on grounding precautions as well as general care and main- tenance.
Page 198 E S D L a m i n a t e technical furniture ( c o n t . ) Parts List Part Number Description Qty. 84008 #8-32 x 1.00” Socket Flat Head Cap Screw 86274 Brass Insert 54225 Plain Type A Washer 18244 Keps Lock Nut 84007...
Page 199 G r o u n d i n g B u s B a r technical furniture Tools Required -Electric drill with 7/32” drill bit -3/8” Wrench NOTE: The Grounding Bus Bar can be located anywhere on a Full Frame, but the recom- mended location is on top of the Frame bot- tom rail.
Page 200 7 2 ” B i n R a i l technical furniture Tools Required -Phillips head screwdriver -Plastic mallet 1. Select the desired height for the Bin Rail. Attach the Bin Rail to the frame by inserting the hooks on the back of the Bin Rail into the trapeziodal slots in the Full Frame.
Page 201 7 2 ” B i n R a i l technical furniture ( c o n t . ) Parts List Part Number Description Qty. 5952X 72” Bin Rail 66714 #10-24 x 3/8” Phillips Pan Head Screw MF40...
Page 202 Installation Manual Eaton is a registered trademark. Eaton 1000 Eaton Boulevard * All trademarks are property Cleveland, OH 44122 of their respective owners. United States Eaton.com Eaton 160 Gold Star Boulevard Follow us on social media to get the © 2018 Eaton Worcester, MA 01606 latest product and support information.

Eaton LMS Installation Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton LMS

Summary of Contents for Eaton LMS
