Free standing corner type and linear type. powered adjustable height modular office furniture system

Advertisement

Quick Links

Compass sit-to-stand
Modular Office Furniture
Compass sit-to-stand (STS)
powered adjustable height
modular office furniture system
Installation manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compass sit-to-stand and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eaton Compass sit-to-stand

  • Page 1 Compass sit-to-stand Modular Office Furniture Compass sit-to-stand (STS) powered adjustable height modular office furniture system Installation manual...
  • Page 2: Table Of Contents

    CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES� In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to damage or...
  • Page 3: Before You Begin

    Compass sit-to-stand Installation Manual Before You Begin Before installing Eaton’s Compass sit-to-stand desk, it is recommended that you do the following: • R ead and understand the instruction herein before attempting to • T he use of personal protective equipment such as safety glasses, unpack, assemble, operate or service the sit-to-stand desk�...
  • Page 4: Electrical Ratings

    2CHANNEL - 120V AC, 60Hz - 200 W to-stand Desks 3CHANNEL - 100V-240V AC, 50Hz-60Hz - 300 W A heavily loaded un-attached linear Compass sit-to-stand desk, Desk Capacities with its work surface in an elevated position, can be unstable when subjected to a lateral load that exceeds 20 pounds� Stability...
  • Page 5: Section Ii -Parts Identification

    Compass sit-to-stand Installation Manual SECTION II –Parts Identification Free Standing Linear Type Cable Worksurface Grommet Lift Column Foot Control Box Warning Control Pad Labels Filler Strip Worksurface Support Cable Chain Levelers COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 6: Free Standing Corner Type

    Compass sit-to-stand Installation Manual Free Standing Corner Type Cable Grommet Worksurface Lift Column Foot Control Pad Warning Labels Cable Filler Strip Control Box Worksurface Cable Support Chain Levelers COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 7: Integrated Linear Type

    Compass sit-to-stand Installation Manual Integrated Linear Type Worksurface Cable Grommet Upper Lift Bracket Lift Bracket Lift Column and Cover Assembly Control Pad Filler Strip Control Box Worksurface Support Back Panel (Stretcher) Levelers Cable Chain COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 8: Integrated Corner Type

    Integrated Corner Type Cable Grommet Worksurface Upper Lift Bracket Lift Column Lift Bracket and Cover Assembly Control Pad Warning Control Box Filler Strip Labels Worksurface Bracket Back Panel (Stretcher) Worksurface Support Levelers Cable Chain Corner Foot COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 9: Assembly Hardware

    # 8-32 x ⁄ " Phillips head thread forming screw ⁄ "-20 Acorn nut (silver) ⁄ "-20 Locking nut (silver) ⁄ " Lock washer (silver) #8 Flat washer Leg top cap set (color matches painted steel) Cable grommet (black) COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 10: Section Iii - Assembling The Desk

    (A)� Use only the round holes to attach the support� The slotted holes are reserved for the control box� #10 x 1" phillips All Linear Type head wood screws Support Free Standing Support Corner Type Worksurface Integrated Corner Support Type Bracket COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 11: B� Install The Lift Control System And Cables

    Lift cables must connect to channel number 1 and go in sequence� Orient the control box to best suit the route of the AC power cable and attach with (2) #10 x 1- ⁄ " Phillips head wood screws (B) at the center of the stiffener� COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 12: C� Free Standing Desks

    Loosen each lift motor’s (4) M6 x 20mm screws� • Cycle lift motors to 18" twice and return to lowest position - tighten all screws� • Cycle lift system to 18" twice and return to lowest position - tighten all screws� COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 13 "-20 strap #10 x 1" channel Acorn Nut screws ⁄ -20 Button head screws Tab slot Cable channel inner section Cable chain Rubber flap Cable channel outer section Foot Large hole in channel COMPLETED ASSEMBLY COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 14: D� Integrated Desks

    Key holes Stretcher panels Corner leg assembly Short corner foot assembly Upper lift brackets Note left / right hand orientation Leg assembly ⁄ -20 x .75 Hex head screws (3) per leg COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 15 • Replace each base bracket cover� NOTICE Ensure all desk components are level, square and plum before moving to next step� Leg assembly Base bracket COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 16 The kit parts are designed to allow attachment to either the left or right stretcher of the assembled desk� Cable chain • Mount cable chain directly to worksurface using (2) #10 x 1" Phillips head screws (A). • M ount to stretcher using (2) #8-32 X ⁄ " thread forming screws (H) and (2) #8 flat washers (L). COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 17 Connect AC cord to AC outlet� #10 x 1" • Initialize lift system - per page 18� wood screws • Cycle lift system to 18" twice� • Tighten all lift motor screws� Install Cable Chain Kit • See page 16� COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 18: Section Iv - Operation

    • INSPECT ALL CABLES TO ENSURE THAT THEY ARE NOT DAMAGED. • DO NOT PLUG THE UNIT IN AGAIN. CONTACT TECHNICAL ASSISTANCE FOR HELP USING THE CONTACT INFORMATION IN SECTION 1 OF THE INSTALLATION GUIDE. COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 19 THE CONTACT INFORMATION IN SECTION 1 OF THE • Press the down button on the control pad to reinitialize INSTALLATION GUIDE. the lift system� This may require multiple attempts� (see SECTION IV – C for initialization of the lift system) COMPASS SIT-TO-STAND INSTALLATION MANUAL Eaton.com/compass...
  • Page 20: Care And Cleaning

    PERIODIC VISUAL INSPECTION SHALL BE PERFORMED with a soft bristled brush� Light scrubbing for 10 to 20 BY AN EATON AUTHORIZED SERVICE REPRESENTATIVE. strokes should remove most stains� Excessive scrubbing or exerting too much force could damage the decorative THIS DESK’S ELECTRICAL LIFT SYSTEM HAS DOUBLE-...
