- Page 1 Compass Compass modular office furniture system Installation manual...
-
Page 2: Before You Begin
Compass Installation Manual Before You Begin Before installing Eaton’s Compass desk, it is recommended that you do the following: • Read and understand the instruction herein before attempting to • The use of personal protective equipment such as safety glasses, unpack, assemble, operate or service the sit-to-stand desk. -
Page 3: Table Of Contents
CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to damage or... -
Page 4: About This Guide
Precautions • Step-by-step instructions appear in the installing compass components section. Compass is a modular office furniture system. Do not use Compass components for any other purpose. Document Conventions Do not connect components in configurations that are not described in this document. -
Page 5: Introduction
• Overhead Storage Overhead Compartment Shell Flipper Doors Cabinet Doors Linear Storage Shelf Corner Storage Shelf Transaction Shelf • Accessories For a complete list of Compass components, see the modular design section COMPASS INSTALLATION MANUAL COMPASS INSTALLATION MANUAL www.eaton.com/compass www.eaton.com/compass... -
Page 6: Sample Configuration
Compass Installation Manual Sample Configuration This sample configuration show how Compass components can be combined to form a variety of workspaces. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 7: Space Planning
Compass components each have unique item numbers. The item number specifies component type, size, and orientation. For example, CWL4830 is Compass worksurface linear 48 inches wide and 30 inches deep. Corner worksurfaces attach between a corner leg and two legs supported by two included stretchers. -
Page 8: Components
30 inches deep on right end, and 24 inches deep on left end. • CWLT4824L is linear transition worksurface 48 inches wide, 24 inches deep on left end, and 18 inches deep on right end. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 9: Corner Worksurface
24 inches deep on left end. • CWCC6048L is corner transition worksurface 60 inches wide on left side, 48 inches wide on right side, 18 inches deep on right end and 24 inches deep on left end. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 10: Peninsula Worksurface
(D) is half width (W). • Conference end worksurface item numbers describe width (W) which is equal to combined depth of two adjoining worksurfaces. For example, CWCE48 is 48 inches wide and 24 inches deep. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 11: Standard Leg
65 inches in height, and attaches to the right side of a worksurface. • CLH2429L is an H leg that supports a 24 inch wide worksurface, is 29 inches in height, and attaches to the left side of a worksurface. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 12: Full Leg
CLLT3065 support a 30 inch wide worksurfaces, is 65 inches in height, and attaches to adjoining worksurfaces. • CLLT2429 is a joined transition leg that supports a 24 inch worksurfaces, is 29 inches in height, and attaches to adjoining worksurfaces. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 13: Non-Joined Transition Leg
• CLT2429L is a non-joined transition leg that supports a 24 inch wide worksurface, is 29 inches in height, and attaches to the left side of a worksurface. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 14: Corner Leg
20 inch organizer panels and transaction shelves. • COU36 is a pair of uprights that extend 36 inches above legs to support 20 inch organizer panels (bottom) and 16 inch organizer panels (top), storage shelves, and overhead storage compartments. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 15: Organizer Panel
(L -linear and C=corner). For example, CM72L is a modesty panel that extends below the stretcher of a 72 inch linear worksurface. • CM48C is a modesty panel that extends below the stretcher of a 48 inch corner worksurface. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 16: Overhead Compartment Shell
72 inch linear shell. • CDF48C is a flipper door that attaches to a 48 inch corner shell. Corner applications can use only one overhead compartment shell and one set of flipper doors on the left or right side. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 17: Cabinet Doors
CSL48C is a 48 inch shelf for one side of a corner. Corner applications can use a linear shelf on the left or right side designated by a “C” , or a corner shelf as described in the following section. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 18: Corner Storage Shelf
(R=rectangular and D=domed), width, and location (L=linear and C=corner). For example, CRTR72L specifies a 72 inch wide rectangular transaction shelf for a linear application. • CRTD48C is a 48 inch wide domed transaction shelf for a corner application. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 19: Finish Trim Pieces
Compass Installation Manual Finish Trim Pieces Compass components include wire way covers, top caps, and Eaton logos. Wire Way Covers Wire way covers attach to the open channel on the interior side of legs and uprights. Wire way covers have left and right versions. The flared side of the wire way cover aligns to the rear of the assembly. -
Page 20: Installing Compass Components
Components can be combined without modification or additional fasteners. NOTICE Note: If two or more Compass components do not fit together seamlessly, check the orientation of the parts. Double-check the part numbers and instructions to make sure the components are intended to connect. -
Page 21: Order Of Installation
“anchor” and work outward from that location. • To maintain structural integrity do not use transition legs at the end of unsupported worksurfaces. WARNING Components can become unstable during assembly. Use caution when installing overhead compartments and shelves. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 22: Preparing To Install
Take an inventory of all components and component kits. Compare the inventory with the list of components required for this installation. Notify your Eaton Sales Representative or Compass Technical Support of any damaged or missing parts. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 23: Assemble Legs
Full leg assembly is complete. 4. Repeat these steps until all full legs needed in this stage of the installation are assembled, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 24 3. Tighten the hex screws. Corner leg assembly is complete. NOTICE Note: Do not over-tighten. 4. Repeat these steps until all corner legs needed in this stage of the installation are assembled, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 25: Install Linear Legs And Stretchers
2. Align the keyholes on the end of the stretcher with the partially inserted hex screws in the leg as shown. Slide the stretcher down to seat the keyholes on the hex screws. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 26 5. Tighten all screws installed to this point. The stretcher installation is complete. 6. Repeat these steps until all the legs and stretchers are connected for this stage of the installation, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 27: Install Corner Legs And Stretchers
2. Align the keyholes on the end of one stretcher with the partially inserted hex screws in the leg as shown. Slide the stretcher down to seat the keyholes on the hex screws. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 28 Tighten all screws installed to this point. The stretcher installation is complete. Repeat these steps until all the legs and stretchers needed in this stage of the installation are connected, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 29: Connect Transition Legs
2. Insert a hex head bolt through each hole. Attach a hex head nut to each bolt and tighten. 3. Repeat these steps until all non-joined transition legs needed in this stage of the installation are connected, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 30: Install Modesty Panels
Complete this procedure to attach modesty panels to installed legs and stretchers. Remove the plastic plugs from the threaded holes at the bottom of the interior side of the legs. Partially insert two hex screws, one in each threaded hole COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 31 4. Tighten all screws installed to this point. 5. Repeat these steps for all modesty panels needed in this stage of the installation, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 32: Install Uprights
Orient the upright to match the leg, with the wire way channel facing inward. Note that both legs and uprights have left and right versions. Insert the bottom of the upright into the top of the leg. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 33 Note: IOrganizer uprights of 20 and 36 inches in height use alignment connectors, as described in the next section Install Alignment Connectors. 3. Repeat these steps for all uprights needed in this stage of the installation, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 34: Install Organizer Panels
Remove the panel insert from the steel back panel if included. Panel inserts are pre-assembled for shipping and must be temporarily removed for installation. 2. Partially insert four hex screws, two per side, into the threaded holes in the uprights. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 35 Press the bottom of the insert into the panel and slide down into the bottom channel. 5. Repeat these steps for all organizer panels needed in this stage of the installation, then continue to the next section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 36: Install Storage Shelves
Remove top caps from the uprights if installed. Align the end support brackets with the shelf support flange down. Insert the rear tab of the support bracket into the slot near the seam between the organizer panels. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 37 3. For corner shelves only: align the corner bracket with the shelf support flange down, at the lowest threaded holes in the corner upright. Insert two hex screws through the bracket flanges into the threaded holes in the corner upright and tighten. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
- Page 38 NOTICE Note: Worksurface tie plates are required between all flanking worksurfaces. Install tie plates during the Install Worksurfaces section. 6. Repeat these steps for all shelves needed in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 39: Install Linear And Corner Overhead Compartment Shells
Tools required (not included) • Powered driver • ⁄ hex socket • Socket extension • #2 Phillips screwdriver CAUTION Note: Components can become unstable during assembly. Use caution when installing overhead compartments and shelves. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 40 Push the panel in and down to seat the screws in the slots. Tighten the screws. NOTICE Note: The top of the back panel must be below the top of the uprights for proper top cap alignment. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
- Page 41 4. Position the overhead compartment side panels with the key holes over the hex screws. Push the panels down to seat the keyholes on the screws. Tighten the screws. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
- Page 42 Note: If this configuration includes under-shelf lighting accessories, install lighting before installing the compartment shelf. 6. From underneath the shelf, insert two screws per side, horizontally through the holes in the side panels into the compartment shelf flange and tighten. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
- Page 43 11. Tighten all overhead compartment screws installed to this point. Repeat these steps for all overhead compartments in this stage of the installation. Worksurface tie plates are required between all flanking worksurfaces. Install tie plates during the Install Worksurfaces section. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 44: Install Flipper Doors
Align the holes in the hinges with the holes in the front side of the top panel and insert three screws per hinge. Do not tighten. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 45 Note: Do not attempt to adjust or fine-tune doors at this time. Complete all door adjustments during the Level and Align Installed Components section. Repeat these steps for all flipper doors in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 46: Assemble Cabinet Doors
Tools required (not included) • Powered driver • #2 Phillips bit • #1 Phillips bit Complete this procedure to assemble cabinet doors and hinge brackets. Insert two hinges into the round cutouts in the back of each door. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 47 Cabinet door assembly is complete except for door handles and locks, which are assembled in the Install Cabinet Doors section. Repeat these steps to assemble all cabinet doors in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 48: Assemble Cabinet Door Hinge Brackets
Note: Make sure the hinge plates are oriented to be on the front edge of the hinge bracket or shell partition when installed in the overhead compartment. Repeat steps 1 and 2 to assemble each required stiffener COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 49: Install Cabinet Door Hinge Brackets
If the compartment is 42 to 54 inches wide, an additional partition is included to accommodate three cabinet doors. The extra partition must be installed during the Install Overhead Compartment Shells section COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 50: Install Cabinet Doors
Suggested top, middle, and bottom handle locations are partially pre-drilled. The customer must specify the location of the door handles. Handle location can be customized in the field to meet customer requirements. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 51 Level and Align Installed Components section. The cabinet door installation is complete. Repeat these steps to install all cabinet doors in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 52: Install Worksurfaces
Align the holes in the worksurface with the holes in the support surfaces. Hold the worksurface in place by hand until all screws are installed. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 53 Repeat these steps for all worksurfaces needed in this stage of the installation. NOTICE Note: Some worksurfaces, such as those with LCD Lifts, require additional assembly. For installation details, see the instruction sheet included with any specialty components. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 54: Install Corner Worksurfaces
Repeat these steps for all worksurfaces needed in this stage of the installation. NOTICE Note: Some worksurfaces, such as those with LCD Lifts, require additional assembly. For installation details, see the instruction sheet included with any specialty components. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 55: Install Peninsula And Jetty Worksurfaces
Insert screws through the leg support flanges into of the worksurface. Tighten all screws. Repeat these steps for all peninsulas and jetties needed in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 56: Install Conference End Worksurfaces
4. From underneath the conference end, align the four tie plates and insert screws into the pre-drilled holes in the bottom of the worksurfaces. Tighten all screws. Repeat these steps for all conference ends needed in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 57: Install Transaction Shelves
5. From underneath the shelf, insert two screws per side through the shelf support into the pre-drilled holes in the bottom of the shelf. Tighten all screws. Repeat these steps for all transaction shelves needed in this stage of the installation. COMPASS INSTALLATION MANUAL www.eaton.com/compass... -
Page 58: Level And Align Installed Components
4. For large installations, sight down the length of the connected workspaces. The edges of connected components should form a straight line. Adjust components as needed to align connected workspaces. COMPASS INSTALLATION MANUAL www.eaton.com/compass... - Page 59 Door spacing should be 3mm on each side and between doors. Adjust the hinge screws as needed to change the horizontal door alignment. Repeat these steps for all components installed to this point. COMPASS INSTALLATION MANUAL www.eaton.com/compass...
-
Page 60: Install Trim Components
Install Trim Components After installing and aligning all major components, complete the installation by adding wire way covers, top caps, and the Eaton logo. Install Wire Way Covers Wire way covers attach to the inner rails of legs and uprights. -
Page 61: Install Top Caps
Do not apply the logo to all stretchers. Apply the logo to a representative sample of the installed workspaces. Install Accessories Compass offers an extensive set of accessories to complete a workspace. Accessories must be installed after the basic installation is complete. COMPASS INSTALLATION MANUAL... - Page 62 Eaton.com/compass Follow us on social media to get the © 2018 Eaton latest product and support information. All Rights Reserved Eaton is a registered trademark. Printed in USA Publication No. IB211001EN CIM-18 All trademarks are property April 2017 of their respective owners.
