Heatmaster Enviro Quick Step Installation Manual

f
c
Minimum clearances required for balanced flue terminals or the flue terminals of outdoor appliances
1
(according to AS5601-2004[AGA gas installation code] or NZS 5261 [New Zealand]
1
a Bellow eaves, balconies or other projections
2
b From the ground or above a balcony
3 2
c From a return wall or external corner
4
1
d From a gas meter (M)
3
e From an electricaity meter or fuse box (P) 4
2
f From a drain or soil pipe
3
g Horizontal from an building structure
4
h From any other flue terminal, cowl or combustion air intake 500 mm
Using your flexible flue pipe
The Enviro's revolutionary flue system incorporates one
65mm diameter pipe and one 58mm diameter pipe.
Do...
Use 3 bends only
Our flexible flue has the ability to bend
2
3 times between the heating unit and
3
the cowl. This includes the bend
straight out of the heater if you're
1
fluing through the ceiling or floor.
Do...
Make the flue pipe go over
the bearers and joists.
You may bend the flue over joists and bearers.
It is recommended that a 20mm clearance be
maintained between the smaller gas exhaust
flue and combustible materials.
Never Do...
Fluing where the pipe had a spot
lower than the rest.
Never allow a low spot in the flue.
Installing the flue with a dip or "goose
neck" can result in reduced efficiency or
even prevent the fire from working.
A 20mm clearance is recommended from the extraction (smaller) flue to combustibles.
Key Information – Quick step check list
Plumber Incoming gas connection provided – 1/2 inch BSP male connector
Gas input – 44MJ high
23MJ low
Manifold pressure
High (Nat gas) 0.69 Kpa
Low (Nat gas) 0.22 Kpa
High (LPG) 2.25 KPA
Low (LPG) 0.63 KPA
Electrician Standard flex 2m, 3 pin plug provided. Requires power point with
double pole isolation switch.
Addition literature
Supplements for flue installation and heat transfer can be obtained by contacting your Heatmaster dealer.
4
*All information contained in this mini summary is correct at the time of publication. This is only a summary and should be read in conjunction with the full installation
instructions. Pictures are representative only and are not drawn to scale. Installation should be carried out by a licensed gas fitter and any electrical work carried out by a
licensed electrician.
l
m
a
j
j j
h
c
Openable
Window
M
h
Door
P
k
d
h
c
b
T Flue Terminal Indicates areas for flue terminals
300 mm j Horizontally from an openable window, door, or non-mechanical
300 mm air inlet, or any other opening into a building, with the exception of
500 mm sub-floor ventilations
1000 mm k Vertically below an openable widow, door,or non-mechanical
500 mm air inlet, or any other opening into a building, with the exception of
150 mm sub-floor ventilation
500 mm l Minimum horizontal clearance to any surface
(such as an exterior wall) for vertical terminations
m Minimum height above roof line for vertical termination
Configure triangle
Using up to three bends, use this triangle to
work out measurements for your 4.5 mtr
4m
flue. Remember, the first bend out of the
Heater is counted as one. The Enviro
can be flued through the roof, wall
Example 1
or floor. *See your Heatmaster
3m
dealer for full details.
2m
Example 2
✘
1m
Page 2
Page 2
Manifold pressure is factory set.
To check pressure and adjust
refer to page 8 of the customer
operation information & Installation
instructions.
Page 2
a
c
d
g
500 mm
150 mm
610 mm
600 mm
Example 3
Do...
www.heatmaster.com.au
