Heatmaster Enviro remote Manual

Enviro remote summary guide.
MODES
There are 3 different operational MODES you can select on your Enviro remote.
*To change MODES, press the MODE button which will display the mode you are operating to at the bottom of
the LCD screen 'MANUAL' 'FLAME' or 'AUTO'
MODE
FLAME
(Preferred Setting)
MANUAL
(Thermostat)
AUTO
(Automatic program)
Flame & Fan LEVELS
There are three set LEVELS (flame and fan combinations) the enviro operates at:
LEVEL
1
2
3
*Fans cannot be turned off
Description
The unit will operate on your preferred LEVEL 1, 2 or 3 (boost).
•
To change LEVEL, use the up and down arrow buttons.
•
LEVELS are indicated by the number 1, 2 or 3 next to the fan icon.
The unit will work towards your desired temperature set on your thermostat
remote.
•
When desired temperature is greater than 10°C of the room
temperature the unit will operate on level 3 (boost).
•
When desired temperature is within 2°- 9° of the room temperature
the unit will operate on level 2
•
When desired temperature is within 2° of the room temperature the
unit will operate on level 1
•
When desired temperature is 1° over room temperature the unit will
turn off
•
When room temperature drops 1° below desired temperature the unit
will turn back on and go through the above steps again
The unit will operate to a set LEVEL at a set time. See remote manual for
programming your own set times, alternatively the remote comes pre-
programmed with the following settings:
Time Period Start Time
Period 1 6.00 am
Period 2 8.30 am
Period 3 5.00 pm
Period 4 10.30 pm
Flame
1 low
2 high
2 high
Heatmaster Pty Ltd
Email: sales@heatmaster.com.au
Website: www.heatmaster.com.au
ACN 006 442 717 ABN 64 641 709 587
Main Showroom & Display
Address: 2/9 Nicole Close
Bayswater Victoria 3153
Telephone: (03) 9761 7130
Facsimile:(03) 9761 7134
Desired Temperature.
20 °C
15 °C
21 °C
15 °C
Fan
1 low
2 high
3 (boost)
