Heatmaster Oak Ridge Creek 24” Manual

Download this manual

FOR BEST RESULTS WE RECOMMEND THAT YOU PLACE YOUR GLOWING EMBERS ON THE BURNER BE-

FORE SETTING UP YOUR LOG SET. SEE THE INSTRUCTION MANUAL THAT WAS SUPPLIED WITH THE

BURNER HEARTH KIT.

Step 1. Place back log H-1054. Then place front log H-1053

H-1053

Step 2. Place log H-01033 & H-1055

H-1033

Step 3. Place log H-1031

Oak Ridge Creek 24"

H-1054

H-1055

H-1031

3/22/2011

Page 1 Oak Ridge Creek 24” FOR BEST RESULTS WE RECOMMEND THAT YOU PLACE YOUR GLOWING EMBERS ON THE BURNER BE- FORE SETTING UP YOUR LOG SET. SEE THE INSTRUCTION MANUAL THAT WAS SUPPLIED WITH THE BURNER HEARTH KIT. Step 1. Place back log H-1054. Then place front log H-1053 H-1054 H-1053 Step 2.
Page 2 Oak Ridge Creek 24” Step 4. Place log H-0852 H-0852 Step 5. Place log H-1035.Place lower front logs H-1056 & H-1057 as shown below. Place pine cone ( A-380) in front of the controls. H-1035 A-0380 H-1056 H-1057...
Page 3 Oak Ridge Creek 24” H-1054 H-1053 H-1033 H-1055 H-1031 H-0852 H-1035 A-0380 H-1056 H-1057 3/22/2011...
Page 4 Oak Ridge Creek 30” FOR BEST RESULTS WE RECOMMEND THAT YOU PLACE YOUR GLOWING EMBERS ON THE BURNER BEFORE SETTING UP YOUR LOG SET. SEE THE INSTRUCTION MANUAL THAT WAS SUPPLIED WITH THE BURNER HEARTH KIT. Step 1. Place back log H-1034. Then place front log H-1027 H-1034 H-1027 Step 2.
Page 5 Oak Ridge Creek 30” Step 3. Place log H-1032 & H-1031 H-1032 H-1031 Step 4. Place log H-1035.Place logs H-1028 & H-1029 as shown below. Place pine cone (A-0380) in front of the controls. H-1035 A-0380 H-1028 H-1029...
Page 6 Oak Ridge Creek 30” H-1034 H-1027 H-1031 H-1033 H-1032 H-1030 H-1035 H-1028 A-0380 H-1029 3/22/2011...
