HEATMASTER, LLC
AMERICAN GAS LOG
Models:
SBS-18,24,30NG
SBSIII-18,24,30NG
For use with Natural gas only.
Check with your local building code agency before you begin installation to ensure compliance with local codes, including
the need for permits and follow-up inspections. If you encounter any problems regarding code approvals, or if you need
clarification of any of the instructions contained here, contact the Technical Services Dept., Heatmaster/American Gas Log,
LLC. 99-33-0078 or 99-33-0079.
•Important operating and maintenance instructions included. Read, understand and
follow these instructions for safe installation and operation.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
CAUTION
DO NOT DISCARD THIS MANUAL
INSTALLER:Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
Heatmaster/American Gas Log, LLC. 6-02ML REV D 03/208
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
•
Keep children away.
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high
temperatures.
•
Keep clothing, furniture, draperies and other
combustibles away.
In the Commonwealth of Massachusetts:
•
This appliance must be installed by a licensed plumber
or gas fitter.
•
The chimney flue damper, when used with gas logs, will
be welded open or completely removed.
•
A CO detector shall be installed in the room where the
appliance is installed.
Installation
Instructions
Installation and service of this
appliance should be performed by
qualified personnel. Heatmaster/
American Gas Log, LLC. suggests
NFI certified or factory-trained
professionals, or technicians
s u p e r v i s e d b y
an NFI certified
professional.
